Airtac 4V230P-08: Solenoid Air Valve - 4V230P08B-W

Product Description:

Pilot mode: There are internal or external guidance options available, which can be selected according to actual application scenarios and needs.

Action modes: mainly including direct action and pilot action. The direct acting type relies on electromagnetic force to directly drive the valve core action, with a simple structure and no need for medium pressure assistance. It is suitable for low flow and low pressure drop scenarios and has a fast response speed; The pilot type uses the pilot air path to control the action of the main valve core, requiring a certain medium pressure difference to work, suitable for high flow and high pressure difference scenarios, with low power consumption.

Sliding column structure: good sealing, sensitive response, able to quickly and accurately achieve the on/off and switching of gas paths.

Number of valve positions: There are various types such as two-position three-way, two-position five-way, and three-position five-way to meet different pneumatic control circuit requirements.

Memory function: The dual head two-position solenoid valve has a memory function, which can maintain the previous state after power failure, helping the system to operate stably.

Working pressure range: generally 0.15-0.8MPa, different models may vary, and can adapt to various pneumatic systems with different pressure requirements.

Temperature range: usually -20 ℃ to 70 ℃, special models support a wider range and can work normally at different ambient temperatures.

Response time: Short, usually in milliseconds, can quickly switch gas paths and improve system efficiency.

Switching frequency: high, able to meet the working requirements of frequent actions, suitable for fast cycling pneumatic control processes.

Power consumption: Low power design, energy-saving and reducing heat generation, helps to reduce system operating costs and improve safety.

Valve body material: Made of aluminum alloy or stainless steel, it has strong corrosion resistance and can adapt to different working environments, such as humid, acidic and alkaline corrosive environments.

Sealing material: mostly NBR (nitrile rubber) or FKM (fluororubber), can adapt to different media such as air, inert gases, etc., ensuring good sealing performance.

Nominal diameter: Common sizes include DN50mm - DN300mm (NPS2-12), as well as interface sizes such as 1/8 ", 1/4", and 3/8 ", which can meet different flow requirements and pipeline connection requirements.

Voltage: Multiple standard voltage levels such as DC12V/24V, AC110V/220V are available for selection, making it convenient to match with different electrical control systems.

Function type: There are normally open (NO), normally closed (NC), bidirectional control, etc., and the appropriate function type can be selected according to specific control requirements.

Application areas: Widely used in industries such as packaging, papermaking, printing, electrical, biotechnology, petroleum, energy, electronics/batteries, as well as pneumatic control circuits in automation control systems.

The standard product protection level reaches IP65, dustproof and waterproof, suitable for harsh industrial environments, can effectively protect the internal components of the solenoid valve from external dust and moisture erosion, and improve the reliability and service life of the product.

Technical Parameters:

Model 4V210-06 4V230C-06 4V210-08 4V230C-08 4V220-06 4V230E-06 4V220-08 4V230E-08   4V230P-06   4V230P-08 Working Medium Filtered air (40 μm or finer) Actuation Type Internal or external pilot type Port Size Inlet/Outlet = PT1/8 Inlet/Outlet = PT1/4 Inlet/Outlet = PT1/4 Inlet/Outlet = PT1/4 Exhaust = PT1/8 Exhaust = PT1/8 Exhaust = PT1/8 Exhaust = PT1/8 Effective Area (Cv) 17.0mm² (Cv=1.0) 13.6mm² (Cv=0.8) 17.0mm² (Cv=1.0) 13.6mm² (Cv=0.8) Position & Ports 5/2 way 5/3 way 5/2 way 5/3 way Operating Pressure Range 0.15–0.8MPa (21–114 psi) Max Pressure Resistance 1.2 MPa (175 psi) Operating Temperature –20 to 70°C Body Material Aluminum alloy Lubrication Not required Max. Actuation Frequency 5 cycles/sec 3 cycles/sec 5 cycles/sec 3 cycles/sec Weight (g) 220g 360g 220g 360g

Applications:

AIRTAC Solenoid Valve, a high-quality electromagnetic valve product originating from China, is designed to meet various industrial needs with its reliable performance and durable construction. This Solenoid valve has obtained the CE certification, ensuring its compliance with international quality standards.

The AIRTAC Solenoid Valve is suitable for a wide range of product application occasions and scenarios, making it a versatile choice for different industries. Its minimum order quantity is 1, and the price is open for negotiation, providing flexibility for customers.

Packaged in carton or as per clients' requirements, the delivery time for the AIRTAC Solenoid Valve is quick, ranging from 1 to 7 working days after payment. Customers can choose from payment options such as T/T, Western Union, and Paypal, enhancing convenience in transactions.

With a supply ability of 5000 pieces per month, the AIRTAC Solenoid Valve is available in various voltages including 12VDC, 24VDC, 24VAC, 110VAC, and 220VAC. It operates within a pressure range of 0.15 to 0.8 MPa (21 to 114 Psi) and has a proof pressure of 1.2 MPa (175psi), ensuring reliable performance in different conditions.

Designed for use with air as the fluid, the AIRTAC Solenoid Valve can withstand temperatures ranging from -20 to +70℃, making it suitable for a wide range of environments. Whether in industrial automation, pneumatic systems, or other applications requiring an electron magnetic valve, the AIRTAC Solenoid Valve proves to be a dependable and efficient choice.

Packing and Shipping:

Product Packaging:

The ASCO Solenoid Valve is carefully packaged in a sturdy cardboard box to ensure safe transportation. The valve is cushioned with protective materials to prevent any damage during shipping.

Shipping Information:

Once your order is confirmed, the ASCO Solenoid Valve will be shipped within 1-2 business days. We offer standard and expedited shipping options to meet your needs. You will receive a tracking number to monitor the delivery status of your package.
