Product Description:
Norgren air preparation systems offer comprehensive conditioning solutions for compressed air used in industrial pneumatic applications. Their product range features essential components such as filters, pressure regulators, lubricators, and combination units. These are available in various body sizes and modular configurations, including notable series like Olympian Plus, Excelon, and Excelon Plus.
The system components are designed to effectively remove contaminants such as water, oil, and solid particles from compressed air. Additionally, they ensure consistent downstream pressure and provide precise lubrication to pneumatic tools, cylinders, and other air-powered equipment, enhancing performance and reliability.
This product family supports port sizes ranging from G1/8 up to G1-1/2 and beyond, with filtration options rated at 5 µm, 25 µm, and 40 µm. The bodies are constructed from durable materials like zinc alloy and aluminium, while bowls can be selected in either polycarbonate or aluminium. The modular design facilitates rapid assembly of tailored combination units through the use of plug-in yoke systems and Quikclamp connections.
Typical operating pressures reach up to 10 bar when using transparent bowls and up to 17 bar with metal bowls. These systems can operate efficiently within a wide ambient temperature range from -20°C to +80°C. The range also includes specialized variants such as the miniature 07 series, the standard modular 72/73/74 series, and high-flow large-port 17/18 series units.
Features:
Complete Air Preparation Solution
Our comprehensive air preparation system includes filters, regulators, lubricators, as well as combination units, all integrated into a single modular setup. This cohesive approach ensures efficient airflow management tailored to various industrial applications.
Modular Plug-In Design
The system features a modular plug-in design that allows for quick assembly and easy maintenance. Utilizing plug-in yoke systems and Quikclamp connections, the setup process is streamlined, reducing downtime and simplifying component replacement.
Diverse Filtration Options
To meet different air quality requirements, the product line offers filter elements with multiple ratings including 5 μm, 25 μm, and 40 μm. This variety enables precise filtration control depending on the specific application needs.
Wide Range of Port Sizes
Ports are available in sizes ranging from G1/8 up to G1-1/2 and beyond, accommodating various flow capacities. This versatility ensures compatibility with a broad spectrum of pneumatic systems.
Multiple Bowl Configurations
Choose from transparent polycarbonate bowls that allow visual monitoring of fluid levels, or metal bowls designed for use in higher pressure environments. This selection caters to both operational safety and performance requirements.
Stable Pressure Regulation
The balanced valve design minimizes the impact of inlet pressure fluctuations on outlet pressure, providing consistent and stable regulation essential for precision applications.
Lubrication Options: Micro-Fog and Oil-Fog
Our lubrication models include micro-fog options suited for multi-point lubrication systems, as well as oil-fog models ideal for lubricating single tools or devices, ensuring optimal operational longevity.
Optimized Airflow Performance
The internal design is optimized to deliver high flow rates while maintaining a low pressure drop, enhancing overall system efficiency and reducing energy consumption.
Enhanced Safety Features
Safety is prioritized with features such as detent action that prevents removal of bowls or units while under pressure. Additionally, tamper-resistant covers are available to secure the system against unauthorized adjustments.
Wide Operating Temperature Range
The equipment operates reliably across a broad temperature spectrum, from -20°C to +50°C for transparent bowls, and from -20°C to +80°C for metal bowls, suitable for various environmental conditions.
Flexible Drain Options
Multiple drain mechanisms are offered, including manual, semi-automatic, and fully automatic drains, allowing users to select the most convenient method for condensate removal.
Integrated Monitoring Accessories
Optional pressure gauges and switches can be integrated into the system, featuring gauge ports and porting block mounted pressure switches to facilitate real-time system monitoring.
High-Capacity Units
For applications demanding high flow rates, the F17 and F18 series models provide capacity up to 1620 SCFM, ensuring sufficient performance in large-scale operations.
Pilot-Operated Regulators
The R18 series offers pilot-operated regulators that deliver high-precision pressure control along with an exceptionally high relief flow, ideal for demanding pneumatic systems.
Technical Parameters:
| Medium |
Compressed Air Only |
| Elastomers |
Nitrile Rubber, Neoprene |
| Filtration Ratings |
5 μm, 25 μm, 40 μm |
| Bowl Materials |
Polycarbonate (transparent), Aluminium (metal) |
| Body Materials |
Zinc Alloy, Aluminium |
| Ambient Temperature |
-20°C To +50°C (transparent Bowl) / -20°C To +80°C (metal Bowl) |
| Drain Options |
Manual, Semi-automatic, Automatic |
| Maximum Inlet Pressure |
10 Bar (transparent Bowl) / 17 Bar (metal Bowl) |
Applications:
In the realm of process control, maintaining stable pressure and providing a clean air supply is essential for the smooth operation of automated process equipment. This ensures high precision and reliability in various industrial processes.
When it comes to material handling, dependable air preparation plays a crucial role in powering conveyors, pick-and-place units, and handling systems. This reliability supports efficient movement and management of materials throughout manufacturing facilities.
The food and beverage industry demands clean compressed air for their packaging, filling, and processing machinery. Using purified air helps maintain hygiene standards and product quality during production.
Agricultural equipment benefits from proper air preparation to support pneumatic controls found on tractors and implements. This facilitates efficient operation and durability in demanding outdoor environments.
Industrial automation requires a consistent air supply to operate cylinders, valves, and actuators within manufacturing lines. This contributes to seamless automation and improved productivity across various production stages.
Pneumatic tools such as air tools, screwdrivers, and impact wrenches rely on lubrication and pressure regulation to function effectively. Proper air treatment enhances tool performance and extends their service life.
In packaging machinery, a steady and reliable air supply is necessary for equipment like form-fill-seal machines and labelling systems, ensuring accuracy and efficiency in packaging processes.
Textile machinery used for weaving, knitting, and yarn processing also depends on optimized air preparation. This supports consistent operation and high-quality textile production.
Automotive assembly lines utilize air supply systems for various applications including paint shops, assembly tools, and testing equipment. Clean and regulated air aids in maintaining production quality and operational safety.
Finally, general pneumatic applications often require compressed air that is clean, regulated, and lubricated. Ensuring such quality air supply is fundamental for the reliable operation of diverse pneumatic systems.
Customization:
Introducing the Norgren Pneumatic Filter Regulator Lubricator, model number L07-100-MPQG, designed and manufactured in CHINA with CE certification to ensure quality and reliability. This product offers excellent customization services to meet diverse industrial needs.
We provide filtration ratings options of 5 μm, 25 μm, and 40 μm, allowing you to select the appropriate level of filtration for your application. The elastomers used in our product include Nitrile Rubber and Neoprene, ensuring durability and resistance to wear. Customers can choose between bowl materials of Polycarbonate (transparent) for easy visual inspection or Aluminium (metal) for enhanced strength and higher ambient temperature tolerance.
The pneumatic filter regulator lubricator body materials are available in Zinc Alloy and Aluminium, providing robustness and longevity. The product operates effectively within an ambient temperature range of -20°C to +50°C for the transparent bowl and -20°C to +80°C for the metal bowl variant.
We understand the importance of compatibility and convenience; thus, our product is comparable and compatible with the FESTO oil mist filter and Pressure Reducer systems, offering seamless integration into your existing setups. Whether you require a Pressure Reducer or a combined filter regulator lubricator, Norgren delivers high performance tailored to your needs.
Minimum order quantity is just 1 piece, with pricing available upon negotiation. Packaging is flexible, shipped in cartons or as per client requirements. Delivery time ranges from 1 to 7 working days after payment confirmation, ensuring prompt supply. Payment terms include T/T, Western Union, and Paypal to accommodate your preferences. Our supply ability is 5000 pieces per month, ensuring steady availability for large-scale projects.
Packing and Shipping:
Product Packaging: The Pneumatic Filter Regulator Lubricator is securely packaged to ensure safe delivery and optimal protection during transit. Each unit is individually packed in a sturdy, high-quality cardboard box with custom foam inserts to prevent movement and damage. The packaging includes clear labeling with product specifications, handling instructions, and a barcode for easy inventory management.
Shipping: We offer reliable and fast shipping options worldwide. The product is shipped through trusted carriers with tracking information provided for each order. All shipments are handled with care to prevent damage, and we ensure timely delivery according to the chosen shipping method. For bulk orders, additional protective packaging and palletizing are available to maintain product integrity during transport.
