YW DKE TRADING COMPANY

|
| Place of Origin: | China |
| Brand Name: | HYDAC |
| Certification: | CE |
| Model Number: | 0055-D-010-V |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Carton /As The Clients Require |
| Delivery Time: | 1-7Work Days After Payment |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 5000PCs per month |
| Pression Difference Range: | 30~200 Bar | Operating Temperature: | -30~100℃ |
|---|---|---|---|
| Filter Element Core: | Metal Fibre | Filter Type: | Cartridge |
| Filter Medium: | Air Or Liquid | Filter Element Diameter: | 55mm |
| Filter Element Length: | Multiple Lengths | Flow Rate: | 10-100m³/h |
| Highlight: | HYDAC Cartridge Precision Filter Elements,Metal Fibre HYDAC Filter Elements,Metal Fibre Precision Filter Elements |
||
Precision Filter Elements are engineered to meet the highest standards for filtration performance, offering a wide range of pressure difference and pressure ranges. These filter elements are constructed with a 20μm filter rating, Wire Mesh filter element media, and stainless steel material for superior filtration performance. With its high precision design, Precision Filter Components are capable of handling a wide range of applications, from 30~200 Bar, making them ideal for a variety of industrial filtration needs. High Precision Filter Elements are designed to provide superior filtration performance with a Wire Mesh Filter Element, making them an ideal choice for industries that require reliable, precise filtration solutions.
Features:
HYDAC Filter Elements are designed to protect vital and expensive hydraulic components from any harm that could be caused by dust, impurities and other particles present in fluids. The top-notch quality of these elements stands above the rest.
HYDAC Filter Elements are best suited for filtration of mineral oils, non-flam fluids, and rapidly biodegradable fluids. These are available in disposable elements and cleanable elements, making it easier to cater to different requirements. The key features of these elements are: High contamination retention capacity,Supreme adsorption of finest particles over a wide differential pressure range,Remarkably consistent beta value stability over a wide differential pressure range,Good fluid compatibility due to the use of epoxy resins for impregnation and bonding,Element protection due to high collapse burst pressure resistance (during cold start and differential pressure surges),Exceptional flow fatigue stability due to solid filter material supports,The filtration ratings of HYDAC Filter Elements are 3µm, 5µm, 10µm, and 20µm absolute.
| Approx. filter surface area (cm²) | |||
| Size | V | W | W/HC |
| 30 | 268 | 256 | – |
| 60 | 318 | 330 | 418 |
| 110 | 648 | 672 | 910 |
| 140 | 852 | 884 | 1200 |
| 160 | 1082 | 857 | 1144 |
| 240 | 1702 | 1348 | 1911 |
| 280 | 3615 | 2862 | 4264 |
| 330 | 2260 | 1795 | 3133 |
| 500 | 3640 | 2891 | 5207 |
| 660 | 4770 | 3795 | 6958 |
| 990 | – | – | 10091 |
| 1320 | – | – | 13916 |
Our filters can be used with a variety of different hydraulic media such as mineral oils, lubrication oils, non-flam fluids, synthetic, and rapidly biodegradable oils.However, for any use involving water, please contact our technical sales department for compatibility advice. Our filter material supports on both sides, as well as its high inherent stability, make our filters resistant to flow fatigue, meeting even the highest standards set by ISO 3724.
Customization:
We provide custom-made Precision Filter Assembly, High Accuracy Filter and Precision Filter Elementry with superior quality and competitive price.
FAQ:
Q: Could you add our logo on your products?
A: Yes, if your quantity more than 50pcs. we could add your logo on the products.
Q: Do you provide samples ?
A:Yes, we could offer the sample for free charge, but do not pay the cost of express freight.
Q: What is your payment term and payment way?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shipment. Payment ways are : T/T, Western Union, Paypal Alipay.
Q:Can we buy 1 piece for quality testing?
A:Yes, no problem.
