Product Details:
|
| Ambient And Fluid Temperature : | - 5 To 150°C | Material: | SS316 |
|---|---|---|---|
| Application: | Power Industry | Brand: | SMC |
| Operating Pressure Range: | -100 KPa To 1 MPa | Connection Type: | Threaded |
| Proof Pressure: | 3.0 MPa | Tubing O.D.: | Ø10 |
| High Light: | Plugs Tubing Pneumatic Hose Fittings,3.0 MPa Pneumatic Hose Fittings,Quick Connect Air Line Fittings |
||
The SMC KQG2 series of stainless steel one-touch pneumatic fittings provide engineers with a collection of advantages like reliable performance, excellent protection against corrosion, chemicals, and high temperatures.
Their unique quality comes from their compact design, manifests in them being 30% smaller and 62% lighter than traditional fittings and a wide range of tubing diameters from 3.2mm to 16mm.
Moreover, the KQG2 series can be used with various compressed air, water, and steam systems, having an operating pressure range of (-100kPa to 1MPa) and temperature conditions (-5°C to +150°C).
Manufactured from SUS316 stainless steel, a higher grade than SUS304 stainless steel, they offer improved pitting and corrosion resistance abilities, particularly in chloride environments.
This product is an ideal choice for applications which require high portability, as it is highly compact and light, with approximately 30% shorter dimensions and around 62% lighter weight when compared to the KQGL06-01S.
It is constructed using a combination of alloy materials, such as stainless steel 316 for its metal components and FKM as its special seal parts, to ensure its robustness and extended service life.
In terms of its operation, this product can be up for a variety of uses with different tubing materials like FEP, PFA, nylon, soft nylon, polyurethane and polyolefin, all at temperatures from -5 to 150°c. Plus, its grease-free design makes it perfect for operations involving steam.
| Features | Specifications |
|---|---|
| Connection Type | Threaded |
| Operating pressure range | -100 KPa To 1 MPa |
| Proof pressure | 3.0 MPa |
| Application | Aerospace Industrial |
| Ambient and fluid temperature | -5 To 150°C |
| Material | SS316 |
| Brand | SMC |
| Tubing 0.D. | Ø3.2, Ø4, Ø6, Ø8, Ø10, Ø12, Ø16 |
| Product Type | Plugs, Pneumatic Fittings, Joints, Connections |
The KQG2 series one-touch fittings are an excellent choice for those looking for a simple-to-use, cost-effective solution. They are extremely versatile and suitable for a broad variety of tubing, such as FEP, PFA, nylon, soft nylon, polyurethane, and polyolefin.
Moreover, these fittings can also be utilized for air, water, and steam, together with FKM seals for stronger protection. Besides, their grease-free design provides an effortless installation and is an ideal choice for those steam applications.
To sum up, the KQG2 series one-touch fittings are an ideal option for anyone who needs an effective and dependable solution.
We offer technical support and service for Pneumatic Hose Fittings. Our team of experienced technicians is available to answer any questions you may have about installation, operation, and maintenance of your Pneumatic Hose Fittings. We can help you troubleshoot any issues you may have so that you can get the most out of your product.
We also offer a range of services to ensure your Pneumatic Hose Fittings are working properly and efficiently. Our services include inspection, testing, and replacement of any components that may be malfunctioning. We will also provide regular maintenance and check-ups to keep your system running smoothly.
If you have any questions or would like to schedule a service appointment, please contact us at anytime. We look forward to helping you get the most out of your Pneumatic Hose Fittings.
Pneumatic Hose Fittings are shipped in boxes or on pallets depending on the size of the order. The boxes are labeled with the customer's name, order number, and the quantity of pieces inside. The pallets are also labeled with the same information. The boxes are secured to the pallets with shrink wrap and straps to ensure that the items do not shift during shipping.
Q1: What is the brand name of the Pneumatic Hose Fittings?
A1: The brand name of the Pneumatic Hose Fittings is SMC.
Q2: What is the model number of the Pneumatic Hose Fittings?
A2: The model number of the Pneumatic Hose Fittings is KQG2L10-01S.
Q3: Where is the Pneumatic Hose Fittings made?
A3: The Pneumatic Hose Fittings is made in China.
Q4: What is the minimum order quantity of the Pneumatic Hose Fittings?
A4: The minimum order quantity of the Pneumatic Hose Fittings is 20 pieces.
Q5: What is the supply ability of the Pneumatic Hose Fittings?
A5: The supply ability of the Pneumatic Hose Fittings is 5000 pieces/1Month.
