SMC Hydraulic Oil Cylinder TRH1.50MF2LT14X6.00 Adjustable Heavy Duty

Hydraulic Oil Cylinder TRH1.50MF2LT14X6.00

3000 Psi Temperature -10°F To 165°F Industrial

Product Description:

Parker Series 2H Heavy Duty Hydraulic Cylinder sets the standard for performance, durability, and trouble free operation. The superior design and high quality materials provide all customers with long lasting service life and reduced operating costs.

Featuring the "Jewel" rod gland, hard chrome plated piston rods, and stepped cushions, Parker Series 2H cylinder offers improved machine productivity, with reduced downtime, faster cycle times, and improved system efficiency. Each cylinder is tested individually before leaving the plant, ensuring proper performance and leak free operation.

When looking for a hydraulic cylinder, choose the Parker Series 2H for your industrial hydraulic application demands. Guaranteed with its high performance, Parker Series 2H will deliver the value you need.

Features:

The TS-2000 Rod Seal is a well-known design and provides a reliable leakproof system. In addition, it can self-adjust and is resilient to any mechanical deflection that may occur.

The "Jewel" Rod Gland Assembly can be removed from the exterior without the need to take apart the cylinder. The long bearing surface is inside the seal, ensuring lubrication from within. An o-ring is used to create a seal between the gland and head, as well as providing prevailing torque-type lock.

The Double-Service Wiperseal™ is used as a secondary seal, wiping away any oil film from the rod on the extend stroke. On the reverse stroke, it cleans the rod. For piston rods with a diameter of 2.000 inches or less, a piston rod stud is included for no extra charge, featuring strong rolled threads made from high strength steel. This is then permanently secured using anaerobic adhesive.

Piston rods are crafted from medium carbon steel and various sizes ranging from 0.625 to 4.000 inches are available. Bigger sizes are made from minimum yield materials, depending on the rod diameter. SAE ¨O¨ ring ports are included as a standard, although clients can ask for NPTF ports without additional cost. Oversize ports from any of the two systems available can be offered for an extra fee.

Adjustable Floating Stepped Cushions are offered as an option. They provide improved performance when it comes to shock reduction and the same envelope and mounting dimensions can be kept regardless of where they are placed. For even better performance, they come with a one-piece nodular iron piston, with a large surface area that contacts the cylinder bore, thus reducing bearing loads. This is then secured with anaerobic adhesive.

Applications:

The Parker TRH1.50MF1LT14X6.00 Hydraulic Force Cylinder is an industrial-grade, hydraulically powered cylinder designed for high-performance applications. With a stroke of 13~15mm, rod diameter of 0.625" through 4.000" and cylinder diameter of 36mm, it is ideal for both high-pressure and low-pressure applications. Manufactured in China and certified with CE, the Parker TRH1.50MF1LT14X6.00 Cylinder is made from steel and is available in minimum orders of 1. It is sold at a competitive price, and delivery takes place within 1-7 working days of payment. With a supply capacity of up to 5000pcs a month, the Parker TRH1.50MF1LT14X6.00 Hydraulic Force Cylinder is the perfect choice for industrial applications, providing reliable power, strength and durability

Flange Mountings – J, JB, JJ, H, HB, and HH

Application:

• Straight line force transfer

• Compression loads (push) – use H, HB or HH

• Tension loads (pull) – use J, JB, or JJ

Advantages:

• Rigid base mounting due to large flange area

• Force is transferred along the centerline of the cylinder

Technical Parameters:

Customization:

The hydraulic oil cylinder is powered by hydraulic pressure, and can be used in a variety of applications. Our custom-made hydraulic oil cylinders come with the Parker brand. The key features are as follows:

• Brand Name: Parker
• Model Number: TRH1.50MF1LT14X6.00
• Place of Origin: China
• Certification: CE
• Minimum Order Quantity: 1
• Price: Negotiation
• Packaging Details: Carton /As The Clients Require
• Delivery Time: 1-7Work Days After Payment
• Payment Terms: T/T, Western Union, Paypal
• Supply Ability: 5000PCs per month
• Standard Construction: Square Head
• Cushion Type: Adjustable
• Stroke: 13~15mm
• Rod Diameter: 0.625" Through 4.000"
• Cylinder Diameter: 36mm

We provide customized services for the hydraulic oil cylinder. The product is of high quality and has passed the CE certification. We have a large inventory and can provide a fast delivery. If you have any needs, please contact us.

Packing and Shipping:

Hydraulic oil cylinders are usually packaged in wooden cases or steel frames, and then padded with foamed plastic to protect the oil cylinders from bumps and collisions. The packaging should be able to withstand the weight of the cylinder as well as any external forces that may be encountered during transport.

Shipping of hydraulic oil cylinders should be done in accordance with the regulations of the country that the cylinders are being shipped to. In most cases, the cylinders will have to be transported by a professional freight company. The freight company should also provide insurance coverage in case the cylinders are damaged during transit.

It is important to ensure that the hydraulic oil cylinders are properly packaged and shipped to prevent any damage or loss. Proper packaging and shipping of hydraulic oil cylinders can help ensure that the cylinders get to their destination safely and on time.
