Name: LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′
Brand: YW DKE TRADING COMPANY
SKU: LF-3/4-D-MAXI-A
Availability: InStock

Home Products Pneumatic Filter Regulator Lubricator

LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′

Product Details:

Place of Origin:	China
Brand Name:	Festo
Certification:	CE
Model Number:	LF-3/4-D-MAXI-A

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	Carton /As The Clients Require
Delivery Time:	1-7Work Days After Payment
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	5000PCs per month

Contact Now

Detailed Product Description

Specification:	1/2′′ 3/4′′ 1′′	Grade Of Filtration:	5 μm Or 40 μm
Proof Pressure:	1.6Mpa	Material:	Stainless Steel
Type:	Filter Regulator Lubricator	Operating Pressure:	0.5-12 Bar
Filter Element:	5 Micron	Temperature Range:	-10-+60 °C
Highlight:	1′′ Air Pneumatic Filter , 3/4′′ Air Pneumatic Filter , 1/2′′ Air Pneumatic Filter

Festo LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′

Product Description

1.Good particle and condensate separation.

2. With manual, semiautomatic, or fully automatic condensate drain.

3. High flow rate with minimal pressure drop.

4. Choice of filter cartridges: 5 µm or 40µm

General technical data
Size		Micro	Mini			Midi			Maxi
Pneumatic connection		1/8"	1/8"	1/4"	3/8"	3/8"	1/2"	3/4"	3/4"	1"
Operating medium		Compressed air
Design		Sintered filter with centrifugal separation
Type of mounting		Via accessories
		In-line installation
Assembly position		Vertical ±5°
Grade of filtration [µm]		5	5 or 40
Max. condensate volume [cm3]		3	22			43			80
Input pressure [bar]
Condensate drain	manual	0~10	0~16
	semiautomatic	1~10	-
	fully automatic	-	2~12

Size	Micro		Mini	Midi	Maxi
	Female thread	Port block			Connection 3/4NPT	Connection 1NPT
LF-…	44	64	250	700	1340	1440

Pneumatic filter regulator lubricator (FRL) is used to deliver clean air, at a fixed pressure, and lubricated (if needed) to ensure proper pneumatic component operation and increase their operation lifetime. Filters, regulators, and lubricators can be bought individually or as a package.

1. Filter: remove water, dirt and other harmful debris from an air system. This is often the first step in improving the air quality.

2. Regulator: adjust and control the air pressure of a system to ensure that down-line components do not exceed their maximum operating pressures. This is the second step in the FRL system.

3. Lubricator: reduce the internal friction in tools or equipment by releasing a controlled mist of oil into the compressed air. This is often done last and/or right before the component needing lubrication.

LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′ 0

LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′ 1

LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′ 2

Packing and Shipping:

Packaging and Shipping

Our Pneumatic Filter Regulator Lubricator is carefully packaged in a sturdy cardboard box to ensure safe delivery to our customers. Each unit is individually wrapped in protective materials and placed in the box with ample cushioning to prevent any damage during shipping. The box is then sealed and labeled with the product name, model number, and any other necessary information.

We offer a variety of shipping options to accommodate the needs of our customers. For domestic orders, we use reputable courier services such as UPS, FedEx, and USPS. International orders are shipped via air freight with reliable carriers. We also offer expedited shipping options for urgent orders.

Our packaging materials are recyclable and eco-friendly, in line with our commitment to sustainability. We take great care in ensuring that our products are delivered to our customers in good condition and in a timely manner.

For bulk orders, we can arrange for customized packaging and shipping solutions to meet specific requirements. Please contact our customer service team for more information and pricing.

Thank you for choosing our Pneumatic Filter Regulator Lubricator. We strive to provide the best products and services to our customers, and we are confident that you will be satisfied with your purchase.

LF Series Compressed Air Pneumatic Filter 1/2′′ 3/4′′ 1′′ 3
