GOYEN CA50T Baghouse Diaphragm Pulse Valve 2'' 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	GOYEN
Certification:	CE
Model Number:	CA50T

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	Plastic bag, Box, Carton, Pallet
Delivery Time:	1-7Work Days After Payment
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	5000 pieces/1Month

Contact Now

Detailed Product Description

Model No:	GOYEN	Voltages:	DC24V, AC24V, AC110V, AC220V
Port Size:	2 Inch	Temperature Range:	-5 To +55℃
Diaphragm Number:	1	Pressure Range:	0.3 To 0.8Mpa
Thread Type:	NPT, G, Rc	Diaphragm Material:	Nitrile (Buna)
Highlight:	220V Diaphragm Pulse Valve , 2'' Diaphragm Pulse Valve , 24V Diaphragm Pulse Valve

Product Attributes

Model No.: CA50T

Brand: GOYEN

Diaphragm Material: NBR

Voltages: 24VDC, 220VAC

Flanged Pulse Jet Valve: CAC25FS, CAC45FS

Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA89MM

Working Pressure Range: 0.3 To 0.8MPa

Port Size: 1/2'',3/4'',1'',1 1/2'',2'',2 1/2'',3''

Dresser Nut Pulse Jet Valve: CA25DD, CA45DD

Remote Pilot Pulse Jet Valve: RCA3D2, RCA25DD, RCA45T, RCA50T

Right Angle Pulse Jet Valve: CA15T,CA20T,CA25T,CA35T,CA45T,CA50T.....

Product Name: CA50T Pulse Jet Valve

CA50T Baghouse Diaphragm Pulse Valve 2'' 24V 220V

Goyen Type Pulse Jet Valve:
1. Threaded Pulse Jet Valve: CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T
2. Dresser Nut Pulse Jet Valve: CA25DD, RCA25DD, CA45DD
3. Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA89MM
4. Flanged Pulse Jet Valve: CAC25FS, CAC45FS
5. Remote Pilot Pulse Jet Valve: RCA3D2, RCA25DD, RCA45T, RCA50T

Main dimension of CA50T Pulse Jet Valve:

GOYEN CA50T Baghouse Diaphragm Pulse Valve 2'' 24V 220V 0

Technical parameters of Goyen Type Pulse Jet Valve:

Model No	CA15T	CA20T	CA25T	CA35T	CA40T	CA50T	CA62T	CA76T
Nonimal size	φ15	φ20	φ25	φ35	φ40	φ50	φ62	φ76
Port Size	G1/2''	G3/4''	G1''	G1 1/4''	G1 1/2''	G2''	G2 1/2''	G3''
Working pressure	0.3-0.8mpa
Temp. range	-5℃ - 55℃
Relative humidity	≤85%
Working medium	Compressed air
Service life	Over 1000000 times
Voltage	DC24V, AC24V, AC110V, AC220V

Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Coil and Solenoid Valve Armature Assembly.

List of All Goyen Type Pulse Jet Valve:

Thread Valve	1/2''	3/4''	1''	1.5''	1.5''	2''	2.5''	3''
	CA15T	CA20T	CA25T	CA35T (Single Diaphragm)	CA45T (Double Diaphragm)	CA50T	CA62T	CA76T
Dresser Nut Valve	1''				1.5''
	CA25DD				CA45DD
Flange Valve	1.5'' Inlet				2'' Inlet
	CAC25FS				CAC45FS
Immersion Valve	φ60 Outlet		φ75 Outlet		φ89 Outlet		φ86 Outlet
	CA50MM		CA62MM		CA76MM		CA89MM
Remote Pilot Valve	1/8''		1''		1.5''		2''
	RCA3D2		RCA25DD		RCA45T		RCA50T
