Hydraulic Filter Element Precision P-3μm Filtration HC8314FCP39H

Product Description:

PALL filters are a crucial product in Pall's portfolio, with applications in various fields such as biopharmaceuticals, food and beverage, chemical, electronics, aerospace, and more. The extensive range of PALL filters caters to different application scenarios, with each filter cartridge made up of high-quality glass fiber filter material and metal mesh, ensuring its effective filtering performance. For instance, the HC2207FKP6H filter element is part of the HC2207 series and has a filtration accuracy of 6um, showcasing the accuracy and specifications that are maintained in the brand's products.

PALL filter cartridges are versatile and can be installed in various hydraulic systems, including on the pump's outlet oil circuit, suction port, system's return oil circuit, branch oil circuit, or used as a standalone filtration system. In hydraulic systems, PALL filters play a vital role in protecting hydraulic pumps from impurities, filtering out contaminants that enter valve components, and ensuring the smooth operation of essential components, like servo valves and throttling valves.

Moreover, the model specifications of PALL filter cartridges depend on their filtration accuracy and size, which are critical parameters for their optimal performance. The filtration accuracy of the filter element must comply with the specific needs and working conditions of the system. For example, the filter element set up at the pump's outlet oil circuit needs to have a filtration accuracy of 10-15 μm and be able to bear the oil circuit's working pressure and impact pressure. Similarly, the height of the filter element, usually measured in inches, is a notable size parameter. For some models, the filter element's height is 8 inches, equivalent to 203.2mm in millimeters.

In conclusion, PALL filter cartridges are available in different models with technical specifications that incorporate details of their versatile applications, diverse filter material, and precise filtration accuracy and size. The technical specifications and application guidelines of PALL filters illuminate their importance, ensuring optimal performance in various hydraulic systems and applications.

Features:

When it comes to PALL filter cartridges, there are several model attributes that are worth noting.

1. Serial number: To identify different filter cartridge models, the PALL filter cartridge model begins with HC and is followed by a series of numbers and letter combinations, such as HC2207FKP6H and HC8314KFF11H. For instance, 8314 in HC8314KFF11H represents the serial number of the filter element, while 2207FKP6H in HC2207FKP6H refers to the specific model of the filter element.

2. Filtration ratio: The PALL filter element has a filtration ratio of β ≥ 200, and it is equipped with a metal mesh inside to enhance the filtration effect and protect the filter element.

3. Height: The height of the filter element is typically expressed in inches. For instance, an 8-inch height is equivalent to 203.2mm in millimeters. This number is also reflected in the model and is used to indicate the specific size of the filter element.

4. Seal material: The seal of PALL filter elements can use different rubber materials, such as nitrile rubber (H mark), ethylene or propylene (J), chloroprene rubber (P), fluororubber (Z), etc., to meet various working conditions and medium requirements.

Aside from the model attributes, the performance indicators of PALL filter cartridges include filtration accuracy, working pressure, working medium, and working temperature, covering a wide range of applications. These filters are suitable for various hydraulic oils, phosphate hydraulic oils, emulsions, and water ethylene glycol media. Furthermore, the working temperature range of these filter cartridges is from -30 ℃ to +110 ℃.

Technical Parameters:

Applications:

The product is suitable for many occasions and scenarios, including:

• Industrial hydraulic systems: PALL HC8314FCP39H Hydraulic Filter Elements can be used in various hydraulic systems of industrial machinery, such as petrochemical, metallurgical, textile, and mining machinery.
• Construction machinery: PALL HC8314FCP39H Hydraulic Filter Elements are widely used in various construction machinery, such as excavators, bulldozers, loaders, and cranes.
• Agricultural machinery: PALL HC8314FCP39H Hydraulic Filter Elements can be used in various agricultural machinery, such as tractors, harvesters, and irrigation systems.
• Marine equipment: PALL HC8314FCP39H Hydraulic Filter Elements are suitable for various marine equipment, such as ships, offshore platforms, and dock machinery.
• Aerospace equipment: PALL HC8314FCP39H Hydraulic Filter Elements can be used in various aerospace equipment, such as satellites, rockets, and aircraft.

The product has many advantages, such as:

• High filtration accuracy: The filtration accuracy of PALL HC8314FCP39H Hydraulic Filter Elements can reach Z-1 μ M, P-3 μ M, N-6 μ M, S-10 μ M, T-25 μ M, which can filter out most impurities in the working medium.
• Wide range of applications: PALL HC8314FCP39H Hydraulic Filter Elements can be used in various hydraulic systems and working media, such as general hydraulic oil, phosphate grease, hydraulic oil emulsion, water hexanediol, etc.
• Excellent sealing performance: PALL HC8314FCP39H Hydraulic Filter Elements are made of fluorine ring Ding Qing rubber, which has excellent sealing performance and can effectively prevent oil leakage.
• Wide operating temperature range: PALL HC8314FCP39H Hydraulic Filter Elements can work normally in the temperature range of -30 ℃~+110 ℃, which can meet the needs of different environments.

The product has obtained CE certification, and the minimum order quantity is 1. The price is negotiable, and the packaging details are carton or as the clients require. The delivery time is 1-7 work days after payment, and the payment terms are T/T, Western Union, and Paypal. The supply ability is 5000PCs per month. The work pressure of the product is 21bar-210bar.

Packing and Shipping:

Product Packaging:

The Hydraulic Filter Element is carefully packaged in a sturdy cardboard box with cushioning material to prevent any damage during shipping. Each filter element is individually wrapped in plastic to protect it from dust and moisture.

Shipping:

Orders for the Hydraulic Filter Element are processed within 24 hours and shipped via a reliable courier service. Shipping times may vary depending on the destination, but customers can expect to receive their order within 3-5 business days. Shipping fees are calculated based on the destination and weight of the order.
