Product Description:
Material and Structure: The PARKER filter element comprises filter material and stainless steel frame, providing excellent breathability and low resistance to the filter element.
Performance characteristics:
- Large filtration area: With a large filtration area, it can handle a significant amount of pollutants, suitable for large-scale filtration needs.
- Large pollutant capacity: Able to accommodate a vast amount of pollutants, the filter element's service life is extended.
- Good high temperature and corrosion resistance: Suitable for use in high temperature or corrosive environments, ensuring stable filtration performance.
- Application areas: PARKER's filter cartridges are widely used in various fields, including petroleum, chemical, metallurgical, water treatment, and pharmaceutical, catering to the needs of multiple industrial applications.
- Filtering accuracy and working pressure:
- The filter element's filtering accuracy range is from 1-100 μm, providing multiple filtering options tailored to meet varying applications' needs.
- The filter element can withstand a maximum working pressure of 21Mpa, making it suitable for filtering needs in high-pressure environments.
- Design Features: The FBO series filter element is explicitly designed to cater to modern high-pressure common rail diesel injection systems' filtering needs. It is commonly used in fuel distribution pumps or large diesel engines as the primary fuel filter/water separator.
In summary, PARKER filters' excellent performance and wide range of applications make them the preferred product in the industrial filtration field.
Technical Parameters:
| O.D. |
1.97" |
| I.D. Top |
0.96" |
| I.D. Bottom |
NA |
| Length Overall |
8.24" |
| Construction Type |
Optimized Microglass, Single Open End |
| Efficiency |
12 Micron; Beta12 = 1000 per ISO 16889 |
| Gasket Material |
Viton |
| Wire Support |
Yes |
| Max Operating Pressure |
300 PSID Collapse |
| Max Temp |
250 Degress F |
| Weight Each |
3.5 |
| Carton Qty |
1 |
| Condition |
New |
| R630-H-1325H |
R650-H-2612H |
R880-H-1303A |
R951-H-0812A |
R980-Z-0412A |
| R630-H-1603A |
R650-H-2625A |
R880-H-1303H |
R951-H-0812H |
R980-Z-0412H |
| R630-H-1603H |
R650-H-2625H |
R880-H-1306A |
R951-H-0825A |
R980-Z-0425A |
| R630-H-1606A |
R650-Z-0803A |
R880-H-1306H |
R951-H-0825H |
R980-Z-0425H |
| R630-H-1606H |
R650-Z-0803H |
R880-H-1312A |
R951-H-1603A |
R980-Z-0803A |
| R630-H-1612A |
R650-Z-0806A |
R880-H-1312H |
R951-H-1603H |
R980-Z-0803H |
| R630-H-1612H |
R650-Z-0806H |
R880-H-1325A |
R951-H-1606A |
R980-Z-0806A |
| R630-H-1625A |
R650-Z-0812A |
R880-H-1325H |
R951-H-1606H |
R980-Z-0806H |
| R630-H-1625H |
R650-Z-0812H |
R880-H-1603A |
R951-H-1612A |
R980-Z-0812A |
| R630-H-2603A |
R650-Z-0825A |
R880-H-1603H |
R951-H-1612H |
R980-Z-0812H |
| R630-H-2603H |
R650-Z-0825H |
R880-H-1606A |
R951-H-1625A |
R980-Z-0825A |
| R630-H-2606A |
R650-Z-1303A |
R880-H-1606H |
R951-H-1625H |
R980-Z-0825H |
| R630-H-2606H |
R650-Z-1303H |
R880-H-1612A |
R951-Z-0803A |
R981-Z-0403A |
| R630-H-2612A |
R650-Z-1306A |
R880-H-1612H |
R951-Z-0803H |
R981-Z-0403H |
| R630-H-2612H |
R650-Z-1306H |
R880-H-1625A |
R951-Z-0806A |
R981-Z-0415A |
| R630-H-2625A |
R650-Z-1312A |
R880-H-1625H |
R951-Z-0806H |
R981-Z-0415H |
| R630-H-2625H |
R650-Z-1312H |
R890-H-1303A |
R951-Z-0812A |
R981-Z-0803A |
| R630-Z-0803A |
R650-Z-1325A |
R890-H-1303H |
R951-Z-0812H |
R981-Z-0803H |
| R630-Z-0803H |
R650-Z-1325H |
R890-H-1306A |
R951-Z-0825A |
R981-Z-0815A |
| R630-Z-0806A |
R650-Z-1603A |
R890-H-1306H |
R951-Z-0825H |
R981-Z-0815H |
| R630-Z-0806H |
R650-Z-1603H |
R890-H-1312A |
R951-Z-1603A |
R981-Z-1303A |
| R630-Z-0812A |
R650-Z-1606A |
R890-H-1312H |
R951-Z-1603H |
R981-Z-1303H |
| R630-Z-0812H |
R650-Z-1606A |
R890-H-1325A |
R951-Z-1606A |
R981-Z-1315A |
| R630-Z-0825A |
R650-Z-1606H |
R890-H-1325H |
R951-Z-1606H |
R981-Z-1315H |
| R630-Z-0825H |
R650-Z-1612A |
R890-H-1603A |
R951-Z-1612A |
R985-H-0403A |
| R630-Z-1303A |
R650-Z-1612H |
R890-H-1603H |
R951-Z-1612H |
R985-H-0403H |
| R630-Z-1303H |
R650-Z-1625A |
R890-H-1606A |
R951-Z-1625A |
R985-H-0406A |
| R630-Z-1306A |
R650-Z-1625H |
R890-H-1606H |
R951-Z-1625H |
R985-H-0406H |
| R630-Z-1306H |
R650-Z-2603A |
R890-H-1612A |
R960-H-0403A |
R985-H-0412A |
| R630-Z-1312A |
R650-Z-2603H |
R890-H-1612H |
R960-H-0403H |
R985-H-0412H |
| R630-Z-1312H |
R650-Z-2606A |
R890-H-1625A |
R960-H-0406A |
R985-H-0425A |
| R630-Z-1325A |
R650-Z-2606H |
R890-H-1625H |
R960-H-0406H |
R985-H-0425H |
| R630-Z-1325H |
R650-Z-2612A |
R890-H-2603A |
R960-H-0412A |
R985-H-0803A |
| R630-Z-1603A |
R650-Z-2612H |
R890-H-2603H |
R960-H-0412H |
R985-H-0803H |
| R630-Z-1603H |
R650-Z-2625A |
R890-H-2606A |
R960-H-0425A |
R985-H-0806A |
| R630-Z-1606A |
R650-Z-2625H |
R890-H-2606H |
R960-H-0425H |
R985-H-0806H |
Applications:
The Parker Filter R980-Z-0812A Hydraulic Filter Element is made with high-quality filtration materials, such as glassfiber, and an inner mesh made of stainless steel wire. It is a hydraulic oil filter element that can handle pressures ranging from 21-210bar and has a temperature range of -4°F~212°F. This makes it ideal for use in a wide range of hydraulic systems, including those with high pressure or temperature requirements.
The Parker Filter R980-Z-0812A Hydraulic Filter Element is suitable for many different product application occasions and scenarios. It can be used in hydraulic systems for industrial machines, such as hydraulic presses, injection molding machines, and hydraulic power packs. It is also suitable for use in hydraulic systems for mobile machinery, such as excavators, cranes, and agricultural equipment. Additionally, it can be used in hydraulic systems for marine applications, such as shipboard hydraulic systems and offshore drilling equipment.
Overall, the Parker Filter R980-Z-0812A Hydraulic Filter Element is a reliable and high-quality hydraulic filter element that provides superior filtration performance for a wide range of hydraulic systems. Whether you need to filter hydraulic oil in an industrial machine, mobile machinery, or marine application, this hydraulic filter element is an excellent choice.
Packing and Shipping:
Product Packaging:
The Hydraulic Filter Element product will be packaged in a sturdy cardboard box with internal padding to prevent damage during shipping. The product will be sealed in a plastic bag to protect it from dust and moisture.
Shipping:
The Hydraulic Filter Element product will be shipped via courier service. The estimated delivery time is 3-5 business days. Shipping fees will be calculated based on the destination and weight of the product.
