Product Description:
Model and Specifications:
Norgren air source filters are available in two models - F72G-2GN-AT3 and F64G-NN-AD3. The F72G-2GN-AT3 has a pressure regulating range of 10MPa and can withstand a maximum operating pressure of 1.6MPa. Its diameter is 1/2mm, and it is recommended to use 5% oil and 1% aluminum alloy material. On the other hand, the F64G-NNN-AD3 has a filtration area of 40 μ m, automatic drain type, port connection of G 3/8, and can handle a maximum operating pressure of 17 bar with a maximum flow rate of 75 dm ³/s2.
Filter Media and Filter Element:
The Norcrown gas source filter's filter element material is usually polypropylene, with its main material being zinc alloy, the collection cylinder being aluminum, and it has an angular observation hole. These design features help improve the filtration efficiency and prevent detachment under pressure.
Working Principle and Application Scenarios:
The Norcrown gas source filter is composed of a housing, a multi-element filter element, a backwash mechanism, and a differential pressure controller. Turbid liquid enters the lower chamber of the filter and is filtered by the filter element, and the clean liquid is sent out from the outlet. This design effectively filters out impurities and water vapor, making it suitable for industrial applications that require high-purity gas sources.
Brand Background:
Norgren is a wholly-owned subsidiary of IMI Group in the UK. It has sales and service networks in 75 countries worldwide and over 16,000 employees. Norgren's products are renowned for their high quality and reliability and are widely used in the fields of aerodynamics and fluid control.
Technical Parameters:
| Media |
Compressed air |
| Operating Temperature |
-34 ... 50 °C, -29 ... 122 °F |
| Port Size |
3/8" ISO G |
| Filter Element |
5 μm |
| Maximum Inlet Pressure |
10 bar |
| Flow |
74 scfm |
| Materials - Body |
Diecast aluminum |
| Materials - Bowl |
Polycarbonate |
| Materials - Elastomers |
Neoprene |
| Materials - Filter Element |
Sintered polypropylene |
| Country of Origin |
Mexico |
| Range |
F73G |
| Series |
Excelon |
| Brand |
IMI Norgren |
Applications:
Designed with a maximum inlet pressure of 10 Bar, the NORGREN Pneumatic Filter Regulator Lubricator has a flow rate of 74 Scfm and can operate in temperatures ranging from -34 to 50 °C (-29 to 122 °F). This makes it ideal for a variety of applications, including air compressors, pneumatic tools, and air-powered machinery.
One of the key features of this product is its ability to filter, regulate, and lubricate compressed air all in one unit. This makes it an efficient and cost-effective solution for managing compressed air, reducing downtime and maintenance costs.
The NORGREN Pneumatic Filter Regulator Lubricator is suitable for use in a range of industries, including automotive, manufacturing, construction, and more. It can also be used for personal hobbies and DIY projects, such as airbrushing, painting, and inflating tires.
With a supply ability of 5000 PCs per month, the NORGREN Pneumatic Filter Regulator Lubricator is readily available to meet your needs. Payment terms include T/T, Western Union, and PayPal, and delivery time is typically between 1-7 work days after payment.
Overall, the NORGREN Pneumatic Filter Regulator Lubricator is a versatile and reliable product that offers a range of benefits for managing compressed air. Whether you're a professional or a hobbyist, this product is sure to meet your needs and exceed your expectations.
Packing and Shipping:
Product Packaging:
- 1 x Pneumatic Filter Regulator Lubricator unit
- Mounting brackets and hardware
- User manual and installation guide
Shipping Information:
- Shipping weight: 3 lbs
- Shipping dimensions: 10 in x 8 in x 6 in
- Shipping carrier: UPS or FedEx
- Shipping time: 3-5 business days
