Product Description:
The NORGREN RM series cylinders are innovative pneumatic actuators created by Norgren in the UK. These high-performance cylinders are specifically engineered for industrial automation , complying with the ISO 6432 standard and suitable for use in a variety of harsh environments .
This series of cylinders offers double-acting or single-acting drive methods, with examples such as the RM/28000/M as a single-acting spring-return type and the RM/8025/M as a double-acting type . Equipped with magnetic pistons and supporting precise control by magnetic switches , these cylinders meet the flexible system integration requirements .
Technical Parameters:
| Medium: |
Compressed air, filtered, lubricated or non-lubricated |
| Standard: ISO 6432 |
ISO 6432 |
| Operation: |
Double acting with magnetic piston and buffer or adjustable cushioning |
| Operating pressure: |
1 ... 10 bar (14 ... 145 psi) |
| Cylinder diameters: |
10, 12, 16, 20, 25 mm (buffer) |
| Strokes: |
See page below |
| Non-standard strokes: |
Up to 1000 mm max. on request |
| Operating temperature: |
5 ... +80°C max. (+23 ... +176°F) |
| Materials: |
Barrel: stainless steel (austenitic) |
| End covers: clear anodised aluminium alloy |
| Piston rod: stainless steel (austenitic) |
| Buffer: PUR |
| Wiper: PUR |
| Seals: NBR |
Applications:
Typical applications span across various fields, including food packaging, pharmaceutical equipment, and chemical automation. These applications are especially well-suited for environments that demand resistance to corrosion, effortless cleaning, or frequent operation.
