Airtac 4V230E-08: Solenoid Air Valve - 4V230E08B AC220V DC24V

Product Description:

Product Structure and Principle Related Attributes

Pilot Mode: There are internal or external guidance options available, which can be selected according to actual application scenarios and needs.

Action Modes: Mainly including direct action and pilot action. The direct acting type relies on electromagnetic force to directly drive the valve core action, with a simple structure and no need for medium pressure assistance. It is suitable for low flow and low pressure drop scenarios and has a fast response speed. The pilot type uses the pilot air path to control the action of the main valve core, requiring a certain medium pressure difference to work, suitable for high flow and high pressure difference scenarios, with low power consumption.

Sliding Column Structure: Good sealing, sensitive response, able to quickly and accurately achieve the on/off and switching of gas paths.

Number of Valve Positions: There are various types such as two position three-way, two position five way, and three position five way to meet different pneumatic control circuit requirements.

Memory Function: The dual head two position solenoid valve has a memory function, which can maintain the previous state after power failure, helping the system to operate stably.

Product Performance Related Attributes

Working Pressure Range: Generally 0.15-0.8MPa, different models may vary, and can adapt to various pneumatic systems with different pressure requirements.

Temperature Range: Usually -20 ℃ to 70 ℃, special models support a wider range and can work normally at different ambient temperatures.

Response Time: Short, usually in milliseconds, can quickly switch gas paths and improve system efficiency.

Switching Frequency: High, able to meet the working requirements of frequent actions, suitable for fast cycling pneumatic control processes.

Power Consumption: Low power design, energy-saving and reducing heat generation, helps to reduce system operating costs and improve safety.

Product Material and Specification Related Attributes

Valve Body Material: Made of aluminum alloy or stainless steel, it has strong corrosion resistance and can adapt to different working environments, such as humid, acidic and alkaline corrosive environments.

Sealing Material: Mostly NBR (nitrile rubber) or FKM (fluororubber), can adapt to different media such as air, inert gases, etc., ensuring good sealing performance.

Nominal Diameter: Common sizes include DN50mm - DN300mm (NPS2-12), as well as interface sizes such as 1/8 ", 1/4", and 3/8 ", which can meet different flow requirements and pipeline connection requirements.

Voltage: Multiple standard voltage levels such as DC12V/24V, AC110V/220V are available for selection, making it convenient to match with different electrical control systems.

Product Features and Application Related Attributes

Function Type: There are normally open (NO), normally closed (NC), bidirectional control, etc., and the appropriate function type can be selected according to specific control requirements.

Application Areas: Widely used in industries such as packaging, papermaking, printing, electrical, biotechnology, petroleum, energy, electronics/batteries, as well as pneumatic control circuits in automation control systems.

Product Protection Related Attributes: The standard product protection level reaches IP65, dustproof and waterproof, suitable for harsh industrial environments, can effectively protect the internal components of the solenoid valve from external dust and moisture erosion, and improve the reliability and service life of the product.

Technical Parameters:

Applications:

AIRTAC solenoid valves are versatile and reliable products designed for a wide range of applications in various industries. With its superior quality and performance, this solenoid valve is a popular choice for many customers.

The ASCO solenoid valve is suitable for a multitude of occasions and scenarios due to its robust construction and efficient operation. Whether it's controlling the flow of air in pneumatic systems, automating industrial processes, or regulating fluid in HVAC systems, this electromagnetic valve excels in providing precise and reliable performance.

Manufactured in China, this solenoid valve bears the CE certification, ensuring compliance with international quality standards. Customers can order a minimum quantity of 1 unit, with pricing available for negotiation. The packaging details include carton packaging or customized options as per the clients' requirements.

With a swift delivery time of 1-7 work days after payment, customers can rely on prompt fulfillment of their orders. Payment terms are flexible, including options such as T/T, Western Union, and Paypal. The supply ability of 5000 pieces per month ensures a steady availability of this high-quality solenoid valve.

Constructed with durable aluminum alloy, this solenoid valve can withstand operating pressures ranging from 0.15 to 0.8 MPa (21 to 114 Psi) and a proof pressure of 1.2MPa (175psi). It is specifically designed for use with air as the fluid medium.

The ASCO solenoid valve offers various voltages options including 12VDC, 24VDC, 24VAC, 110VAC, and 220VAC, catering to different power requirements across applications. Whether it's for industrial automation, pneumatic control systems, or HVAC applications, this electron magnetic valve provides efficient and precise control.
