CQ2A12-50DM SMC Air Piston Cylinder For Heavy-Duty Industrial Applications

Product Description:

The SMC CQ2A Series ultra-compact cylinders deliver high-precision linear motion in space-constrained applications. Featuring a 12mm bore size with stroke options of 5/10/15/20/25/30/35/40/45/50mm , these double-acting single-rod cylinders combine 30% shorter length than standard cylinders with robust performance.

Constructed from aerospace-grade aluminum with hard anodization, they operate at 0.05-1.0MPa (7-145 psi) to generate 90N maximum thrust. Pre-lubricated seals enable maintenance-free operation while integrated magnetic fields support sensor mounting.

Compatible with SMC's modular accessory system including guides, valves, and mounting brackets.

Features:

Ultra-Compact: With a width of only 24mm, these cylinders are 40% shorter than traditional ISO cylinders (e.g., 82mm @50mm stroke).

Lightweight: Constructed with a topology-optimized aluminum body, they weigh just 0.15kg @50mm stroke.

Modular Integration: These cylinders can be directly mounted with MXS guides/VQ valves.

Balanced Thrust: They provide a bidirectional force of 90N±3% @1.0MPa.

High Speed: Operating at speeds of 500mm/s, they offer a quick 0.15s response time @50mm stroke.

Adjustable Cushioning: An optional hydraulic damper is available for absorption of 0.043J.

Wide Temp. Option: Equipped with -XB6 seals, these cylinders can operate in temperatures ranging from -40~150°C (-40~302°F).

Corrosion Resistance: They feature a -XC6 stainless steel kit with a SUS304 rod, providing excellent resistance to corrosion.

IP65 Protection: With -XC4 dual wipers, these cylinders are safeguarded from dust/dirt environments.

4-Side Sensor Slots: Working with D-M9N sensors, these cylinders offer compatibility with Φ3.5mm slot sensors.

8 Mounting Styles: They come with pre-loaded screws for A/L/D-type configurations, providing flexibility in mounting.

Stroke Adjustment: An -XC8 module allows for ±5mm travel modification.

Hard Anodized Bore: Featuring a 25μm coating, offering three times the wear resistance of standard cylinders.

Hard Chrome Plated Rod: With a 0.02mm thickness and a friction coefficient of μ≤0.15, ensuring smooth operation.

Zero-Leakage Seals: Utilizing X271 FKM compound, these cylinders exhibit less than <0.1mL/min leakage @0.5MPa.

Applications:

For diagnostic sample transfer, we offer 35-50mm stroke variants with -XC6 stainless steel kits that effectively handle biological samples in analyzers. This configuration helps prevent contamination in FDA-compliant environments.

Our reagent dispensing systems operate at low pressure (0.05MPa) and achieve precise 0.1mL fluid dosing accuracy in IVD instruments using 10mm stroke units.

Our compact automation cells feature 40mm stroke cylinders that position AOI cameras at speeds ranging from 50-200mm/s. These adjustable speeds help minimize vibration during high-magnification imaging.

Integrated with collaborative robots, our robotic end-effectors with 25mm stroke and M3 rod threads enable lightweight part insertion under 0.5s cycle times.

Models with a 50mm stroke are designed for high-speed cutting applications, such as actuating blades in film-sealing systems. Cuts can be completed in just 0.2s at 1.0MPa with hydraulic cushioning for shock reduction.

Our label alignment solutions include 15mm stroke versions with -DZ mounting ears that correct label position deviations of ≤0.3mm in pharmaceutical blister packaging lines.

A medical device manufacturer successfully reduced machine thickness by 42% using the CQ2A12-30DMZ model with 4-side sensors. This upgrade resulted in a 70% decrease in downtime for cartridge loading systems.
