Name: 532897 DNCB-100-25-PPV-A Economical Standard Cylinder Standard Cylinder DNCB ISO 15552 FESTO
Brand: YW DKE TRADING COMPANY
SKU: DNCB-100-25-PPV-A
Availability: InStock

Home Products Piston Pneumatic Cylinder

532897 DNCB-100-25-PPV-A Economical Standard Cylinder Standard Cylinder DNCB ISO 15552 FESTO

Product Details:

Brand Name:	Festo
Certification:	CE
Model Number:	DNCB-100-25-PPV-A

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	Carton /As The Clients Require
Delivery Time:	1-7Work Days After Payment
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	5000 Pieces/1Month

Contact Now

Detailed Product Description

Constructional Design:	Piston	Cushioning:	Pneumatic Cushioning Adjustable At Both Ends
Operating Pressure:	0.6-12bar	Ambient Temperature:	–20-+80°C
Operating Medium:	Filtered Compressed Air Lubricated Or Unlubricated	Mounting Position:	Any
Highlight:	filtered compressed air pneumatic cylinder , double acting cylinder for extreme temperatures , lubricated unlubricated piston pneumatic cylinder

Product Description:

The FESTO DNCB series is an economical standard cylinder that fully complies with the international ISO 15552 standard. It is designed as a robust and reliable pneumatic automation solution for a vast range of industrial applications.

Featuring a profile cylinder barrel, this series offers a cost-effective solution without the need for variants, covering approximately 90% of all standard cylinder applications.

Key design features include a dedicated profile slot for proximity sensors and air connections positioned on one side, significantly simplifying installation, maintenance, and system integration.

With a comprehensive selection of mounting accessories and a stroke range of up to 2,000 mm, the DNCB cylinder provides exceptional flexibility for machine design and layout.

Applications:

The FESTO DNCB Cylinder Applications

The FESTO DNCB cylinder is a versatile workhorse suitable for numerous automation tasks across various industries, including:

Automotive Manufacturing: Used in welding fixtures, part handling, clamping, and positioning applications on assembly lines.
Packaging Machinery: Ideal for actuating stops, gates, doors, and pushers in packaging and palletizing systems.
Material Handling: Employed in conveyor line diverters, lift-and-place units, and sorting systems.
General Industrial Automation: A perfect fit for clamping, pressing, lifting, and feeding applications in machine building and factory automation.
Printing and Paper Processing: Used for paper guiding, cutting, and stack lifting mechanisms.

532897 DNCB-100-25-PPV-A

532898 DNCB-100-40-PPV-A

532899 DNCB-100-50-PPV-A

532900 DNCB-100-80-PPV-A

532901 DNCB-100-100-PPV-A

532902 DNCB-100-125-PPV-A

532903 DNCB-100-160-PPV-A

532904 DNCB-100-200-PPV-A

532905 DNCB-100-250-PPV-A

532906 DNCB-100-320-PPV-A

532907 DNCB-100-400-PPV-A

532908 DNCB-100-500-PPV-A

532897 DNCB-100-25-PPV-A Economical Standard Cylinder Standard Cylinder DNCB ISO 15552 FESTO 0

532897 DNCB-100-25-PPV-A Economical Standard Cylinder Standard Cylinder DNCB ISO 15552 FESTO 1

532897 DNCB-100-25-PPV-A Economical Standard Cylinder Standard Cylinder DNCB ISO 15552 FESTO 2

532897 DNCB-100-25-PPV-A Economical Standard Cylinder Standard Cylinder DNCB ISO 15552 FESTO 3

Support and Services:

Our Piston Pneumatic Cylinder product comes with comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction.

Our technical support team is available to assist with installation, troubleshooting, and maintenance of the product. We also offer training programs to help customers better understand the product and maximize its benefits.

In addition, our service team provides repair and maintenance services to keep your Piston Pneumatic Cylinder in top condition. We use genuine parts and follow industry best practices to ensure the quality and longevity of your equipment.
