Product Description:
The PARKER P1F series cylinders boast a range of key technical features and design highlights. First and foremost, these cylinders adhere to the ISO 15552 standard, with diameters spanning from Ø 32mm to Ø 125mm. The smooth contour design and elegant appearance of the P1F series make it stand out. It is equipped with aluminum sandblasted front and rear end caps, stainless steel piston rods, pneumatic buffers, and magnetic pistons for easy position detection.
One of the core technological advantages of the P1F series lies in its sealing technology, which leverages Parker Prädifa's expertise. Multiple sealing materials are available to meet diverse application requirements. Additionally, the cylinders feature adjustable pneumatic buffering as a standard offering, effectively reducing impact at the end of the stroke, ensuring smooth braking, minimizing noise, and enhancing longevity.
Moreover, the P1F series offers a wide array of options to cater to different needs. These include a selection of piston rod materials like hard chrome-plated carbon steel or stainless steel, various types of dust seals (standard, FKM, Polon), metal dust scraper rings, as well as a range of installation accessories and sensors such as the P8S series installation parts and CPS sensors with IO Link functionality.
Applications:
The PARKER P1F series cylinders , with their robust design and diverse options, can adapt to many demanding industrial environments:
Factory Automation and Material Handling: In automated production lines, the P1F series cylinders are commonly used to push objects, accurately position (stop/hold/advance), and control flow separation and merging (changing lanes, directions) on the assembly line.
Clamping and fixing: In fields such as machine tool machining and vehicle assembly, it can be used to clamp workpieces or components, ensuring stability and safety during the machining or assembly process.
Packaging Machinery: In the packaging industry, these cylinders can perform push/pull actions for sorting, conveying, and packaging operations of items.
Special environment:
- Food and pharmaceutical industry: optional Polon/UHMW-PE material sealing and dust removal rings that meet FDA requirements, suitable for areas that require frequent cleaning or avoid lubricant contamination (such as food industry zones 2 and 3)
- High temperature and low temperature scenarios: High temperature models (-10 ° C to +150 ° C) can be used for baking equipment, while low temperature models (-40 ° C to +80 ° C) are suitable for cold storage, refrigerated transportation, or outdoor cold environments.
- Adverse working conditions: In the face of situations such as wood processing and cement industry where hard abrasives such as resin, ice, cement, and sugar crystals are prone to accumulate on the piston rod, a combination of metal dust scraper rings and hard chrome plated piston rods can be selected to effectively prevent damage and extend the service life.
- Potential explosive environment: Some models in the series offer ATEX certified versions (temperature limit -20 ° C to +60 ° C), which can be used in certified potential explosive environments.
Support and Services:
Our company offers comprehensive Product Technical Support and Services for the Piston Pneumatic Cylinder product. Our team of experts is dedicated to providing assistance with installation, troubleshooting, and maintenance of the cylinders. We also provide training programs to ensure proper usage and optimization of the product. In addition, we offer repair services and spare parts to ensure the longevity and efficiency of your Piston Pneumatic Cylinder.
Packing and Shipping:
Product: Piston Pneumatic Cylinder
Description: High-quality pneumatic cylinder with a durable piston design.
Package Contents:
- 1 x Piston Pneumatic Cylinder
- Instruction Manual
Shipping Information:
- Shipping Method: Standard Shipping
- Estimated Delivery Time: 5-7 business days
- Shipping Cost: $10.00
- Shipping Restrictions: This product can only be shipped within the continental United States.
