P1F-S032MC-0050-0000 P1F Series Parker Pneumatic Cylinder

Product Description:

The PARKER P1F series cylinders are characterized by several key features:

• Standard Compliance and Design: The P1F series adheres to the ISO 15552 standard, with cylinder diameters ranging from Ø 32mm to Ø 125mm. Its smooth contour design and natural appearance make it stand out. The cylinder is equipped with aluminum sandblasted front and rear end caps, stainless steel piston rods, pneumatic buffers, and magnetic pistons for easy position detection.
• Core Technological Advantages:
• Sealing Technology: Utilizes Parker Pr ä difa's advanced sealing technology, offering various sealing materials based on application requirements.
• Buffer Capability: Comes with adjustable pneumatic buffering to reduce impact at the end of the stroke, ensuring smooth braking, lower noise levels, and prolonged lifespan.
• Rich Options: Offers multiple piston rod materials (e.g., hard chrome plated carbon steel, stainless steel) and various dust seals (standard, FKM, Polon®), metal dust scraper rings, along with a range of installation accessories and sensors (P8S series parts, CPS sensors with IO Link capability).

Applications:

The PARKER P1F series cylinders, known for their sturdy design and wide range of options, are well-suited for various challenging industrial settings:

Factory Automation and Material Handling: In automated production lines, the P1F series cylinders are commonly utilized for pushing objects, accurately positioning (stopping/holding/advancing), and controlling flow separation and merging (e.g., changing lanes, directions) on the assembly line.

Clamping and Fixing: In fields such as machine tool machining and vehicle assembly, these cylinders can be employed to clamp workpieces or components, ensuring stability and safety during the machining or assembly process.

Packaging Machinery: Within the packaging industry, these cylinders can execute push/pull actions for sorting, conveying, and packaging operations of items.

Special Environment:

• Food and Pharmaceutical Industry: Optional Polon/UHMW-PE material sealing and dust removal rings that adhere to FDA requirements, suitable for areas requiring frequent cleaning or to avoid lubricant contamination (e.g., food industry zones 2 and 3).
• High Temperature and Low Temperature Scenarios: High temperature models (-10°C to +150°C) can be utilized for baking equipment, while low temperature models (-40°C to +80°C) are suitable for cold storage, refrigerated transportation, or outdoor cold environments.
• Adverse Working Conditions: For situations like wood processing and the cement industry where hard abrasives such as resin, ice, cement, and sugar crystals may accumulate on the piston rod, a combination of metal dust scraper rings and hard chrome plated piston rods can effectively prevent damage and prolong the service life.
• Potential Explosive Environment: Certain models within this series offer ATEX certified versions (temperature limit -20°C to +60°C), suitable for use in certified potential explosive environments.

Order Codes:
