F72G Series NORGREN Air Source F72G-2GN-AL1

F72G Series NORGREN Air Source F72G-2GN-AL1

  • F72G Series NORGREN Air Source F72G-2GN-AL1
  • F72G Series NORGREN Air Source F72G-2GN-AL1
  • F72G Series NORGREN Air Source F72G-2GN-AL1
  • F72G Series NORGREN Air Source F72G-2GN-AL1
F72G Series NORGREN Air Source F72G-2GN-AL1
Product Details:
Place of Origin: CHINA
Brand Name: Norgren
Certification: CE
Model Number: F72G-2GN-AL1
Document: en_8_160_100_F72G.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Carton /As The Clients Require
Delivery Time: 1-7Work Days After Payment
Payment Terms: T/T,Western Union,Paypal
Supply Ability: 5000PCs Per Month
Contact Now
Detailed Product Description
Medium: Compressed Air Series: F72G Series
Model Number: F72G-2GN-AL1 Filter Element: 5 μm
Port Size: G1/4 Thread Type: G
Highlight:

NORGREN F72G pneumatic filter

,

F72G-2GN-AL1 air regulator

,

pneumatic filter regulator lubricator

Product Description:

F72G Series Filters Features

Modular Design: The F72G series filters are designed to be part of the Excelon modular system, enabling easy installation in a tubular or modular manner with other Excelon products like pressure regulators and oil misters. This design makes assembly and maintenance very convenient.

Efficient Filtration Capacity: These filters use sintered polypropylene filter cartridges to effectively remove moisture and particulate pollutants from compressed air. They offer multiple filtering accuracies, with common options including 5μm, 25μm, 40μm, and 75μm.

Various Drainage Methods: Depending on the model, manual (such as 1/4 turn knob), semi-automatic, or automatic drainage options are provided.

Flexible Selection of Filter Cups: Users have the choice between transparent polycarbonate filter cups (with a liquid level indicator for easy observation of water accumulation) or metal filter cups (usually made of zinc alloy or aluminum).

Wide Working Temperature Range: The working temperature range varies depending on the type of filter cup: Transparent cup with a protective cover has a range of approximately -20°C to +50°C, while the metal cup can reach -20°C~+65°C (F72G) or even -20°C~+80°C (F73G/F74G).

Optional Filter Life Indicator: Users can opt for a filter life indicator that provides a visual indication (changing from green to red when the filter needs to be replaced) or an electrical indicator for timely understanding of the filter status and preventive maintenance.

Durable Material Construction: The F72G model features a shell made of zinc alloy, transparent cup made of polycarbonate, metal cup made of zinc alloy, and sealing elastomer made of nitrile rubber or chloroprene rubber, while the F73G/F74G models have housings made of aluminum alloy.


Applications:

The F72G series filters are extensively utilized in various industrial sectors where high-quality compressed air is needed, owing to their dependable performance.

Rail Transit: In rail transit applications, these filters are employed in pneumatic circuits for functions like train braking systems and door controls to ensure a clean air supply and the reliable operation of systems.

Marine Engine: In marine settings, the filters are utilized to treat compressed air for starting and control systems, eliminating potential moisture and contaminants to maintain optimal performance.

Industrial Automation: These filters find wide application in pneumatic equipment, including cylinders, pneumatic valves, and vacuum generators across industries such as petroleum, chemical, power, textile, coal, packaging, medical, automotive, metallurgy, food, and beverage. They serve to safeguard precision pneumatic components from pollution and wear.

General Manufacturing Industry: They contribute by supplying clean air sources to various pneumatic tools and equipment on production lines, thereby prolonging equipment lifespan and minimizing downtime caused by malfunctions.

F72G Series NORGREN Air Source F72G-2GN-AL1 0

F72G Series NORGREN Air Source F72G-2GN-AL1 1

F72G Series NORGREN Air Source F72G-2GN-AL1 2

Media Compressed air
Operating Temperature -34 ... 50 °C, -29 ... 122 °F
Port Size 1/4" ISO G
Drain Type Auto drain
Filter Element 5 μm
Maximum Inlet Pressure 10 bar, 145 psi
Flow 28 dm3/sec, 59 scfm
Materials - Body Zinc alloy
Materials - Bowl Polycarbonate
Materials - Elastomers NBR, Chloroprene Rubber
Materials - Filter Element Polypropylene

Support and Services:

The Product Technical Support and Services for the Pneumatic Filter Regulator Lubricator product include:

- Installation guidance and instructions

- Troubleshooting assistance for operational issues

- Maintenance recommendations for optimal performance

- Warranty coverage and support

- Product training and resources for users


Packing and Shipping:

Product: Pneumatic Filter Regulator Lubricator

Description: This product helps maintain clean, regulated, and lubricated air supply for pneumatic systems.

Packaging: The Pneumatic Filter Regulator Lubricator is securely packaged in a sturdy cardboard box to prevent any damage during transit.

Shipping: We offer fast and reliable shipping services to ensure your product reaches you in a timely manner. The product will be carefully packed and shipped to your address.
