Product Description:
The core advantages of DSM series cylinders are reflected in the following aspects:
Flexible swing angle and high precision: The DSM series offers a continuously adjustable swing angle of up to 270 °. Thanks to the fixed metal stopper design, it can achieve high-precision terminal position positioning, ensuring the accuracy of repeated movements.
Compact structure and high torque output: Adopting a rotating blade structure, the compressed air energy is directly converted into swinging motion, with a compact and lightweight structure. Some models (such as DSM-T) adopt a double force blade design, which can double the torque and reach up to 80 Nm.
Diverse buffering and sensing options: The DSM series offers elastic buffering pads and adjustable buffering, with basic models equipped with elastic buffering rings/plates. Users can choose a more powerful hydraulic buffer to effectively absorb the impact generated by high moment of inertia. At the same time, it supports proximity switch sensing position detection, and some models have built-in magnetic rings for easy sensor installation.
Rich derivative models and high-performance bearings: The DSM series offers multiple derivative models. For example, the DSM-HD model is equipped with heavy-duty bearings that can withstand higher axial and radial forces. The DSM-I model also integrates a rotatable potentiometer, which can be used to build a complete servo pneumatic positioning system.
Wide adaptability to working conditions: The DSM series has a wide range of working pressures, such as 2-10 bar or 0.35-0.8 MPa (depending on the model), allowing stable operation at various pressures. Its design emphasizes reliability, such as using new chamber seals and rotating blades, achieving excellent synchronicity at pressures ranging from 1.5 to 10 bar.
Applications:
With its specific characteristics, the DSM series demonstrates excellent performance in various fields and devices:
General Factory Automation: The DSM series is extensively utilized in the realm of factory automation across a multitude of industries. Its compact structure and flexible installation method facilitate easy integration into devices with limited space.
Material Handling and Assembly: In the domain of grasping and assembly technology, DSM cylinders are employed for tasks such as rotating, flipping, positioning, and transferring workpieces.
Mining Machinery and Special Environments: The DSM series finds application in mining machinery and pneumatic tools as well. Certain models have acquired ATEX certification and can operate in potentially explosive environments. Its design, such as some models not primarily using copper zinc nickel metal, is well-suited for industries with specific material requirements like lithium battery production facilities.
High Precision Positioning System: By utilizing the DSM-I series integrated potentiometer alongside the CPX-CMAX axis controller and proportional directional control valve VPWP, a high-precision servo pneumatic positioning system can be created for achieving advanced motion control.
- Size16
- Cushioning angle12 deg
- Rotation angle adjustment range0 deg ... 246 deg
- Swivel angle0 deg ... 246 deg
- Permissible stop radius≥17 mm
- CushioningShock absorber at both ends
- Mounting positionoptional
- Fine adjustment-3 deg
- Mode of operationDouble-acting
