Product Description:
The FESTO ADVUL Series represents a compact yet high-performance guided rod cylinder designed to deliver exceptional precision. By integrating the piston, guide rod, and yoke coupling plate into a single design, it effectively eliminates piston rod torsion. This integration ensures highly accurate and stable linear motion during operation.
Specifically engineered for automated systems where space is limited and reliability is crucial, the ADVUL Series caters to demanding industrial environments. It provides a versatile selection of bore sizes, ranging from 12mm up to 125mm, which allows users to choose the appropriate size based on their specific application requirements.
Additionally, with stroke lengths available up to 400mm, this series accommodates a variety of load capacities and spatial constraints. The combination of compact design, robust construction, and precise motion control makes the FESTO ADVUL Series an ideal choice for many automated processes.
Features:
Rigid Anti-Rotation Design
This product features a unique guide rod and yoke coupling construction that effectively resists lateral and eccentric loads.
This design ensures exceptional motion rigidity and enables consistent, repeatable positioning accuracy during operation.
Highly Integrated & Compact
Engineered with space-saving installation in mind, the compact design is perfect for applications in restricted spaces.
It helps to optimize machine layouts and improve overall efficiency without compromising performance.
Easy Installation & Sensing
A variety of mounting accessories are provided, allowing for flexible installation options tailored to different requirements.
Additionally, profile grooves on the cylinder body facilitate the straightforward attachment of proximity sensors, such as the SME series.
This enables non-contact position detection, ensuring smooth integration with control systems.
Reliable & Durable
Constructed with a precision aluminum alloy barrel and a high-alloy stainless steel piston rod, the product also includes standard elastomeric cushioning at both ends.
These features contribute to smooth and quiet operation, while significantly enhancing the service life and reliability of the unit.
Broad Operating Conditions
Designed to operate efficiently across a wide range of environments, this product supports a typical operating pressure from 1.5 to 10 bar.
It can function reliably within an ambient temperature range of -20°C to +80°C, making it suitable for most industrial applications.
Technical Parameters:
|
Ambient Temperature
|
-20 ... 80°C
|
|
Design
|
Piston, Piston Rod
|
|
Cushioning
|
Elastic Cushioning Rings/plates At Both Ends
|
|
Mounting Position
|
Optional
|
|
Working Medium
|
Filter Compressed Air, Lubricated Or Unlubricated
|
|
Type of Mounting
|
Either, With Through-hole, With Accessories
|
|
Product Type
|
Air Piston Cylinder, Compact Cylinder, Aluminium Body
|
Applications:
In the field of New Energy Vehicle Manufacturing, advanced technologies are extensively utilized to achieve precise positioning and secure clamping. These capabilities are essential during battery module assembly as well as in various processes such as part handling, welding, and painting lines, ensuring high-quality production and efficiency.
The Semiconductor and Electronics industry benefits greatly from specialized equipment designed for wafer handling, testing, and PCB assembly. In these applications, maintaining exceptional cleanliness and precision is paramount, making this technology an ideal fit for such sensitive and intricate operations.
When it comes to Food and Packaging Machinery, these systems are perfectly suited for driving actuation and pushing movements in high-speed filling, packaging, and sealing machines. Their reliability and performance help maintain consistent operation speeds and ensure product quality throughout the packaging process.
General Industrial Automation incorporates these technologies as dependable core drive components. They play a vital role in material handling tasks, machine tool loading and unloading, as well as various assembly workstation functions, contributing to streamlined workflows and enhanced manufacturing productivity.
Support and Services:
Our Piston Pneumatic Cylinder product is designed for reliable and efficient performance in various industrial applications. To ensure optimal operation, please follow the recommended installation, maintenance, and troubleshooting guidelines provided in the user manual.
For installation, make sure the cylinder is mounted securely and aligned properly to prevent undue wear and leakage. Use appropriate fittings and avoid exceeding the specified pressure limits.
Regular maintenance includes checking for air leaks, inspecting seals and piston rods for damage, and lubricating moving parts as necessary. Replace any worn or damaged components promptly to maintain performance and safety.
If you encounter any issues such as unusual noises, reduced speed, or loss of holding force, refer to the troubleshooting section of the manual. Common causes may include air supply problems, contamination, or mechanical wear.
We provide comprehensive technical support to assist you with installation, maintenance, and troubleshooting. Our services include on-site inspection, repair guidance, and replacement parts to minimize downtime and ensure your pneumatic cylinder operates at peak efficiency.
For detailed technical specifications, maintenance schedules, and operational tips, please refer to the product documentation provided with your purchase.
