Product Description:
Thin, Compact & Space-Saving Design
This cylinder boasts a slim-profile design that sets it apart from many traditional models. For the same bore size, its overall dimensions—particularly the width and height—are noticeably smaller, making it an excellent choice when space optimization is a priority.
Crafted primarily from aluminum alloy, the main components contribute to a lightweight structure. This reduction in weight enhances the overall efficiency of the equipment by supporting lightweighting initiatives.
Flexible Design & Easy Installation
The cylinder body includes specially designed grooves for mounting magnetic switches. Smaller bore sizes have grooves on two sides, while larger bores feature grooves on all four sides. These mounting grooves accommodate compact magnetic switches such as the D-M9 series. Once installed, the switches sit flush with the surface, effectively saving space and reducing the risk of collisions.
In addition to through-hole mounting as the basic option, the cylinder supports a range of optional accessories including foot mounts and flanges. This versatility allows users to adapt the installation to meet various requirements with ease.
Reliable Performance & Easy Maintenance
Designed to operate reliably within a pressure range from 0.07 MPa up to 1.0 MPa, this cylinder also withstands temperatures from -10°C to +70°C, making it suitable for a wide range of working environments.
The cylinder comes pre-lubricated from the factory, which eliminates the need for additional lubrication under standard air conditions and significantly reduces maintenance efforts over time.
Depending on the model, various cushioning options are available. These range from rubber cushions to adjustable air cushioning systems, providing smooth and controlled stopping tailored to different load and speed requirements.
Applications:
Introduction to the CDQ2B Series
The CDQ2B series is renowned for its compact size and dependable performance, making it an ideal choice in automation environments where space is limited. Its design emphasizes reliability and efficiency, enabling widespread use across various industries with stringent spatial requirements.
Applications Across Industries
In the field of electronics and semiconductor manufacturing, the CDQ2B series plays a crucial role in tasks such as part transfer, clamping, and precise positioning. These functions are essential in processes like circuit board assembly, chip packaging, and the operation of high-precision inspection equipment.
For small-scale automation equipment, these actuators serve vital functions in assembly lines, packaging machinery, and handling manipulators, providing reliable motion control in compact setups.
The medical device sector benefits from the CDQ2B series as well, especially in applications requiring clean and compact drives. Examples include laboratory automation systems and analytical instruments, where space-saving and sanitary design are paramount.
Guidance on Selection and Usage
When selecting a CDQ2B actuator, several key parameters must be taken into account. Primarily, the bore size is critical as it directly influences the output force; common bore sizes include Φ12, Φ16, and Φ20. Additionally, the stroke length determines the travel distance of the actuator and should align with the application's requirements.
It is also important to decide on the type of action. One can choose between double-acting actuators, which are pneumatically driven in both directions for more precise control, and single-acting actuators that utilize a spring return mechanism.
Furthermore, consideration should be given to optional features. For example, adjustable cushioning might be necessary depending on the load and operating speed to ensure smooth motion. In scenarios involving side loads, opting for a guided variant, such as the CDQ2B/W series, can significantly enhance durability and service life.
Support and Services:
Our Piston Pneumatic Cylinder product is designed to deliver reliable and efficient performance in a wide range of industrial applications. For technical support, please refer to the product manual for installation guidelines, operating instructions, and maintenance procedures to ensure optimal functionality and longevity.
If you encounter any issues with the piston pneumatic cylinder, verify that the cylinder is installed correctly, all connections are secure, and that the operating pressure is within the specified range. Regular inspection for wear and tear, lubrication, and cleaning of the cylinder and related components is recommended.
We offer comprehensive after-sales services including troubleshooting assistance, replacement parts, and repair services to minimize downtime. Our technical support team is equipped to assist with application guidance, customization requests, and performance optimization.
For detailed troubleshooting, common issues such as air leakage, reduced cylinder speed, or irregular movement can often be resolved by checking seals, cleaning or replacing filters, and ensuring proper air supply quality.
To maximize the lifespan of your Piston Pneumatic Cylinder, adhere to the recommended maintenance schedule and operate the equipment within the specified parameters. Always use compatible accessories and replacement parts to maintain product integrity.
We are committed to supporting your operations and ensuring your satisfaction with our products through continuous technical assistance and service excellence.
Packing and Shipping:
Our Piston Pneumatic Cylinder is carefully packaged to ensure maximum protection during transit. Each cylinder is wrapped in anti-static bubble wrap and placed inside a custom-fitted foam insert to prevent movement and damage. The packaged product is then enclosed in a sturdy corrugated cardboard box, which is sealed securely with reinforced tape. For added safety, desiccant packets are included to control moisture and prevent corrosion.
We offer reliable shipping options to meet your needs, including standard and expedited services. All shipments are tracked and insured to guarantee safe delivery. Our logistics partners handle your order with care, ensuring that your Piston Pneumatic Cylinder arrives promptly and in perfect condition.
