Product Description:
Thin, Compact & Space-Saving
This cylinder boasts a slim-profile design that significantly reduces its overall dimensions, especially in width and height, when compared to many traditional cylinders of the same bore size. Its compact form factor makes it an ideal choice for applications where space is limited.
Constructed primarily from aluminum alloy, the main components are lightweight, which not only decreases the total weight but also contributes to the overall lightweighting of the equipment in which it is installed.
Flexible Design & Easy Installation
The cylinder body is engineered with precise mounting grooves—two on either side for smaller bore sizes and four sides for larger bores—allowing the integration of compact magnetic switches like the D-M9 series. These switches fit flush with the body once installed, conserving space and minimizing the risk of accidental collisions.
Moreover, the product supports a basic through-hole mounting type and offers a variety of optional accessories, including foot mounts and flanges, enabling versatile installation options tailored to diverse application requirements.
Reliable Performance & Easy Maintenance
Designed to operate within a standard pressure range of 0.07 MPa to 1.0 MPa, this cylinder can reliably function across temperatures ranging from -10°C to +70°C, ensuring stable performance under various conditions.
Thanks to factory pre-lubrication, the cylinder is maintenance-free in terms of lubrication under normal air conditions. This feature significantly reduces maintenance efforts and extends the service life of the component.
Additionally, depending on the model, a variety of cushioning options are available. Users can select from rubber cushioning to adjustable air cushioning, providing smooth and controlled stopping that can accommodate different loads and speeds.
Applications:
Overview of the CDQ2B Series
The CDQ2B series is known for its compact size and reliable performance, making it an ideal choice for automation applications where space is limited. Its design caters to various industries that demand precision and efficiency in confined environments.
Applications in Various Fields
Electronics & Semiconductor Manufacturing: The CDQ2B series plays a crucial role in processes such as part transfer, clamping, and positioning within circuit board assembly, chip packaging, and precision inspection machinery. Its compactness ensures seamless integration in highly intricate setups.
Small Automation Equipment: These actuators are commonly employed in assembly line machines, packaging equipment, and handling manipulators, providing smooth and accurate motion control in small-scale automation systems.
Medical Devices & Instruments: Due to their clean and space-saving features, CDQ2B actuators are also suitable for medical laboratory automation tools and analyzers, where sterility and minimal footprint are essential.
Guidelines for Selection and Usage
When selecting a CDQ2B actuator, key parameters to consider include the bore size, which affects the output force (common sizes are Φ12, Φ16, Φ20), and the stroke length, which determines the travel distance of the actuator.
Additionally, it is important to decide on the type of action required. Double-acting actuators are powered pneumatically in both directions, while single-acting versions include a spring return mechanism to reset the position.
Furthermore, assess whether adjustable cushioning is needed depending on the load and operating speed. In situations where side loads occur, selecting a guided variant, such as the CDQ2B/W series, can significantly enhance the durability and service life of the actuator.
Support and Services:
Our Piston Pneumatic Cylinder product is designed to offer reliable and efficient performance in various industrial applications. For technical support, we provide comprehensive assistance including troubleshooting guidance, maintenance tips, and installation instructions to ensure optimal operation of your pneumatic cylinder.
We recommend regular inspection of the cylinder for wear and tear, and timely replacement of seals to maintain performance. Our support team is equipped to help you identify the correct specifications and compatible accessories for your specific application needs.
In addition to technical support, we offer a range of services including customization options, repair services, and extended warranty programs to enhance the longevity and functionality of your pneumatic cylinders.
For detailed product manuals, operation guidelines, and safety instructions, please refer to the documentation provided with your purchase or available through our online resources.
Packing and Shipping:
Each Piston Pneumatic Cylinder is carefully packaged to ensure maximum protection during transit. The cylinder is first wrapped in a protective plastic film to prevent dust and moisture exposure. It is then securely placed in a custom-fitted foam insert within a sturdy corrugated cardboard box to absorb shocks and prevent movement.
For added safety, multiple layers of packaging materials are used depending on the size and quantity of the cylinders ordered. All packages are clearly labeled with handling instructions and product information to facilitate smooth processing and delivery.
Shipping is handled through reliable carriers with options for standard or expedited delivery. We provide tracking information for all shipments to keep customers informed of their order status. Special care is taken to comply with international shipping regulations when dispatching orders overseas.
Bulk orders may be palletized and shrink-wrapped to ensure stability and ease of handling during transportation. Our packaging and shipping processes are designed to deliver the Piston Pneumatic Cylinder in perfect condition, ready for immediate use upon arrival.
