Product Description:
Compact Design & Modularity
The valve features an ultra-thin body design, with each individual valve measuring only 18 millimeters in width. This dimension represents the medium size in its series, which includes options of 10, 14, 18, and 24 millimeters. Such a slim profile effectively conserves valuable installation space, making it ideal for applications where space is limited.
In addition, the modular valve terminal allows for the combination of multiple valve modules on a single manifold base. These modules are connected using a bayonet-style connection, eliminating the need for screws and enabling easy and secure assembly. The system supports configurations ranging from 2 to 10 valve positions, offering great flexibility. The terminal is constructed from high-strength glass-fiber reinforced polyamide combined with an aluminum rail, ensuring a durable and robust structure.
High Performance & Efficiency
This valve system delivers a high flow capacity, with a maximum flow rate reaching up to 3200 liters per minute. Despite this impressive performance, it maintains very low power consumption, typically around 1.5 watts for DC models. This combination results in excellent energy efficiency, making it a cost-effective choice for various industrial applications.
Furthermore, the valve's fast response time significantly contributes to operational efficiency. Switching times generally occur within tens of milliseconds, enabling faster machine cycle times and improving overall productivity.
Applications:
The CPE18 series solenoid valve stands out due to its compact design, high efficiency, and versatility. These characteristics make it a preferred option across a variety of applications.
In the field of general industrial automation, the CPE18 valve is extensively utilized. It plays a crucial role in controlling cylinders involved in operations such as pushing, pulling, clamping, and lifting. Typical applications include material handling systems, assembly lines, and packaging machinery.
For equipment where space is limited, this series is especially advantageous. Its small footprint allows it to be seamlessly integrated into compact workstations, robotic end-effectors, or confined enclosures where space optimization is critical.
Moreover, the CPE18 series excels in complex pneumatic systems that require centralized control. Thanks to its modular valve terminal design, it simplifies the management and wiring of multiple pneumatic circuits within multi-actuator workstations or machining centers.
Additionally, certain variants within the CPE18 series are designed for specialized uses. Notably, some models are well-suited for vacuum environments, making them ideal for applications like vacuum gripping or vacuum fixture systems.
Support and Services:
Our Pneumatic Solenoid Valve product is designed to provide reliable and efficient control of air flow in various pneumatic systems. To ensure optimal performance and longevity, it is important to follow proper installation, operation, and maintenance guidelines.
Installation should be carried out by qualified personnel, ensuring that the valve is mounted according to the specified orientation and connected to compatible pneumatic fittings. Use clean, dry compressed air to prevent contamination and damage to internal components.
During operation, the valve should be regularly inspected for signs of wear, damage, or leakage. It is recommended to perform routine maintenance checks, including cleaning the valve components and replacing seals or coils as necessary to maintain performance.
If the valve fails to operate correctly, verify the electrical connections and ensure that the coil voltage matches the product specifications. Also, check for any air supply issues such as pressure fluctuations or blockages in the pneumatic lines.
For troubleshooting, consult the product manual for detailed guidance on common issues and corrective actions. Replacement parts and repair services are available to minimize downtime and extend the service life of the valve.
We are committed to providing comprehensive technical support to assist with installation, maintenance, and troubleshooting of the Pneumatic Solenoid Valve. Please refer to the user manual for detailed instructions and safety information.
Packing and Shipping:
Product Packaging:
The Pneumatic Solenoid Valve is carefully packaged to ensure safety and integrity during transportation. Each valve is individually wrapped with protective foam and placed in a sturdy cardboard box to prevent any damage from impact or vibration. The packaging includes anti-static materials to protect sensitive electrical components. Additionally, the box is labeled with product information, handling instructions, and barcodes for easy identification.
Shipping:
We offer reliable shipping options to deliver the Pneumatic Solenoid Valve promptly and securely. Products are shipped via trusted carriers with tracking services available. Special care is taken to ensure the package is securely sealed and cushioned to avoid damage. Depending on the destination, shipping methods may include standard ground, expedited air freight, or express courier services. International shipments comply with all customs regulations and documentation requirements to ensure smooth delivery.
