FESTO Round Mini Cylinder DSNU-12-10-P-A 19189

Technical Data

• Stroke10 mm
• Piston diameter12 mm
• Piston rod threadM6
• CushioningElastic cushioning rings/pads at both ends
• Mounting positionAny
• Conforms to standardISO 6432
• Piston rod endExternal thread
• Structural designPiston Piston rod Cylinder barrel

Product Description:

The DSNU series is recognized for its exceptional efficiency and versatility. One of its standout features is the self-adjusting pneumatic end-position cushioning system, known as PPV. This innovative system automatically tailors the cushioning effect according to the load and speed, which not only minimizes impact but also significantly reduces setup time.

Designed with a compact, round shape, the DSNU series is ideal for installations where space is limited. It offers a variety of mounting options to accommodate different requirements, including basic types, flange mounts, and foot mounts, allowing for flexible and convenient integration.

To cater to a wide range of applications, the series includes several variants. These consist of the standard DSNU model, the DSNU-S variant that is shorter and better suited for even more confined spaces, and the CRDSNU model, which is specifically engineered to withstand corrosive environments.

Durability is a key characteristic of the DSNU cylinders. They are typically constructed from high-quality aluminum alloy or steel, with the option of stainless steel piston rods for enhanced corrosion resistance. The cylinders operate reliably within a temperature range of -20°C to +80°C, making them well-suited for most industrial settings.

Applications:

The Festo DSNU series of compact cylinders are engineered specifically for linear motion tasks within the automation sector. These cylinders offer reliable performance and versatility, making them ideal for a range of industrial applications.

In the realm of general industrial automation, the DSNU series is extensively utilized for fundamental operations. These include material handling, precise positioning, pushing, clamping, and sorting processes, all of which benefit from the cylinders' compact design and efficiency.

When it comes to key industry equipment, the DSNU compact cylinders are the preferred option for actuation tasks across various sectors. Industries such as packaging, automotive assembly, food and beverage production, electronic manufacturing, and medical device fabrication rely on these cylinders for their high performance and dependable operation.

Furthermore, the DSNU series excels in applications requiring precision and integration. They are perfectly suited as end effectors on industrial robots—for example, as grippers—and can be seamlessly incorporated into inspection, measurement, and light assembly machinery. These applications demand rapid response times and a compact footprint, both of which are core strengths of the DSNU cylinders.

Support and Services:

Our Piston Pneumatic Cylinder product is designed to deliver reliable and efficient performance in a wide range of industrial applications. To ensure optimal operation and longevity, we provide comprehensive technical support and services.

Technical Support includes assistance with product selection, installation guidance, troubleshooting, and maintenance tips. Our team of experienced engineers is available to help you understand the specifications and capabilities of the piston pneumatic cylinders to match your application requirements.

We also offer detailed product documentation, including user manuals, installation instructions, and maintenance guidelines to help you get the most out of your pneumatic cylinder.

In addition, we provide repair and maintenance services to keep your pneumatic cylinders functioning smoothly. Our service includes inspection, refurbishment, and replacement of worn components to minimize downtime and extend the service life of your equipment.

For custom requirements, we offer tailored solutions and modifications to meet specific operational needs. Our experts work closely with you to design and deliver pneumatic cylinders that fit your unique applications.

Regular training sessions and workshops are also available to ensure your team is well-versed in the proper handling and maintenance of piston pneumatic cylinders, promoting safe and efficient use.

By choosing our Piston Pneumatic Cylinder, you gain access to a dedicated support network committed to helping you achieve maximum productivity and reliability in your pneumatic systems.

Packing and Shipping:

Our Piston Pneumatic Cylinder is carefully packaged to ensure maximum protection during transit. Each cylinder is wrapped in anti-static bubble wrap and placed inside a custom-fitted foam insert to prevent movement and damage. The wrapped product is then placed in a sturdy, double-walled cardboard box designed to withstand rough handling.

For shipping, we use reliable carriers with tracking options to ensure timely and safe delivery. All packages are labeled clearly with handling instructions such as "Fragile" and "This Side Up" to minimize the risk of damage. Additionally, we offer expedited shipping options and international delivery to meet our customers’ needs worldwide.
