Double Acting DZF-12-160-A-P-A FESTO Flat Cylinder 150 Mm Stroke

Product Description:

This product utilizes a super-flat structural design, making it one of the most compact and streamlined options available within its cylinder category. Its flattened profile allows for installation in very tight and restricted spaces, where conventional cylinders might not fit.

The piston is uniquely shaped with an oval cross-section, which effectively prevents rotation during its linear movement. This built-in anti-rotation feature ensures precise and stable motion without requiring extra guiding components, enhancing overall operational accuracy.

Designed for direct mounting on valve manifolds or modular assemblies, this cylinder can be compactly connected to pneumatic valve groups and similar components. Its architecture supports a high density of integrated components, making it ideal for complex system configurations.

Typically operating in a double-acting mode, the cylinder includes elastic cushioning rings or plates at both ends to provide smooth and gentle damping at the stroke limits. The piston rod is configurable with either internal (female) or external threads, facilitating the mounting of various tools. Additionally, most models come equipped with grooves to accommodate inductive proximity sensors, enabling straightforward position detection.

Applications:

The DZF series is perfectly designed for applications that demand high-density modular equipment. This includes multi-station machining units, assembly modules, and integrated valve manifolds. In such setups, numerous actuators must be positioned closely together, making the DZF series an ideal solution.

Additionally, the DZF series excels in space-constrained precision mechanisms. It is commonly utilized within electronic assembly equipment, semiconductor machinery, small robotic end-effectors such as grippers, and precision measurement instruments. In these devices, the series serves as a reliable driving unit for pushing, lifting, or clamping operations.

Moreover, the DZF series is well-suited for light-duty linear drives. It meets the needs of applications where overall height is strictly limited but precise and dependable linear motion is essential. This combination of compactness and accuracy makes it a valuable choice for such demanding scenarios.
