Double Acting FESTO Cylinder DZF-12-40-A-P-A 161226

Technical Data

• Stroke40 mm
• Piston diameter12 mm Equivalent diameter
• Piston rod threadM6
• Max. angle of rotation of the piston rod +/-2.5 deg
• CushioningElastic cushioning rings/pads at both ends
• Mounting positionAny
• Mode of operationDouble-acting

Product Description:

This product utilizes a super-flat structural design, showcasing a highly compact and flattened form within its cylinder category. Such a design allows it to be installed efficiently in areas where space is extremely limited.

The piston is crafted with a unique oval shape that provides a built-in anti-rotation capability during its movement. This design guarantees precise linear motion without requiring any extra guide mechanisms.

The construction is optimized for direct installation on valve manifolds or for modular assembly. It enables a compact connection with components such as pneumatic valve groups, resulting in a high density of integrated parts.

Generally operating in a double-acting mode, the cylinder is equipped with elastic cushioning rings or plates at both ends to ensure smooth damping at the stroke's conclusion. The piston rod options include either internal (female) or external threading, facilitating the mounting of various tools. Additionally, most models come with grooves designed to accommodate inductive proximity sensors for effective position detection.

Applications:

The DZF series is perfectly designed for a variety of applications, making it highly versatile and efficient. One of its primary advantages is its suitability for high-density modular equipment. This includes setups such as multi-station machining units, assembly modules, and integrated valve manifolds, where numerous actuators must be installed closely together in tight spaces.

Additionally, the DZF series excels in space-constrained precision mechanisms. It is commonly utilized within electronic assembly machinery, semiconductor manufacturing equipment, compact robotic end-effectors like grippers, and precision measuring devices. In these applications, the DZF acts as the driving unit responsible for pushing, lifting, or clamping operations, ensuring precise and reliable performance.

Moreover, the DZF series is ideal for light-duty linear drive needs. It fits well in environments with strict height restrictions while still delivering dependable and accurate linear motion. This makes it an excellent choice for applications where space is limited but performance cannot be compromised.

Support and Services:

Our Piston Pneumatic Cylinder product is designed for reliable and efficient performance in various industrial applications. For technical support, please refer to the product manual for detailed installation, operation, and maintenance instructions to ensure optimal functionality and longevity.

If you encounter any issues or require assistance with troubleshooting, our technical support team is available to provide expert guidance. Common areas of support include diagnosing air leaks, ensuring proper alignment, checking for wear and tear, and verifying correct pressure settings.

We also offer a range of services including custom cylinder configurations, repair and refurbishment, and performance optimization to meet your specific application needs. Regular maintenance services are recommended to prevent downtime and extend the service life of your pneumatic cylinders.

For more detailed information on product specifications, replacement parts, and warranty terms, please consult the official product documentation or contact our support center.
