DZF-12-25-A-P-A FESTO Flat Cylinder Metric DZF

Product Description:

This product utilizes a super-flat structural design, making it one of the most compact and flattened cylinders available in its category. The slim profile allows for installation in very tight and restricted spaces where traditional cylinders might not fit.

Equipped with a uniquely shaped oval piston, this design effectively prevents rotation during operation. This built-in anti-rotation feature ensures highly precise linear motion, eliminating the necessity for additional guiding components.

The product’s construction is optimized for direct attachment to valve manifolds or for seamless modular assembly. It can be connected in a compact manner with elements such as pneumatic valve groups, enabling a dense and efficient component layout.

Typically, the device functions in a double-acting mode with elastic cushioning rings or plates installed at both ends to provide smooth damping at the stroke’s end. The piston rod offers options for internal (female) or external threading, facilitating straightforward mounting of tools. Additionally, most models include grooves designed for installing inductive proximity sensors to support accurate position detection.

Applications:

The DZF series offers features that make it particularly well-suited for a variety of specialized applications. One primary area of use is in high-density modular equipment. This includes devices such as multi-station machining units, assembly modules, and integrated valve manifolds, where it is necessary to place multiple actuators closely together in a compact arrangement.

Additionally, the DZF series is ideal for space-constrained precision mechanisms. These mechanisms are often found within electronic assembly equipment, semiconductor machinery, and small robotic end-effectors like grippers. They also play a key role in precision measuring instruments, serving as the driving force for actions such as pushing, lifting, or clamping with high accuracy.

Furthermore, the DZF series is effective for light-duty linear drive applications. It is particularly appropriate for scenarios where there are stringent restrictions on the overall height of the device but where dependable and precise linear motion remains essential.
