RM/28020/M/25 RM/28020/M/25/50/75/100/125/150/175/200/225/250.275.300. Pneumatic Cylinder

Product Description:

The Piston Pneumatic Cylinder is a high-quality pneumatic actuator designed to deliver reliable and efficient performance across a variety of industrial applications. Engineered with precision, this Air Piston Cylinder operates within an optimal pressure range of 2 to 10 Bar (29 to 145 Psi), making it suitable for tasks requiring moderate to high force output. Its versatility and robust construction ensure consistent operation even in demanding environments.

One of the standout features of this Pneumatic Cylinder is its bore size options, available in 10 mm, 12 mm, 16 mm, 20 mm, and 25 mm. This range of bore diameters allows users to select the most appropriate cylinder size to meet their specific application requirements, ensuring optimal force and speed control. Whether you need a compact cylinder for lightweight operations or a larger bore for more heavy-duty tasks, this product provides the flexibility to accommodate diverse industrial needs.

Constructed with a stainless steel barrel, the Piston Pneumatic Cylinder boasts excellent resistance to corrosion and wear. This material choice not only enhances the durability and longevity of the cylinder but also makes it ideal for use in environments where exposure to moisture, chemicals, or abrasive substances is common. The stainless steel barrel ensures that the cylinder maintains its structural integrity and smooth operation over extended periods, reducing maintenance costs and downtime.

The cylinder features buffer cushioning, an essential attribute that helps absorb shock and reduce impact forces at the end of the piston stroke. This cushioning mechanism significantly enhances the operational smoothness and protects both the cylinder and the connected machinery from potential damage caused by abrupt stops. As a result, the buffer cushioning contributes to safer and more reliable system performance while extending the service life of the pneumatic components.

Designed as a single-acting, spring return cylinder, this Air Piston Cylinder simplifies control and installation. The single-acting operation means that compressed air is applied to one side of the piston to create motion, while a spring mechanism returns the piston to its original position when the air pressure is released. This design is particularly useful in applications where a fail-safe return is necessary or when the cylinder needs to retract automatically without additional control inputs.

Another notable feature is the inclusion of a magnetic piston. The magnetic piston cylinder design allows for non-contact position sensing using external sensors, enabling precise monitoring of the piston’s position throughout its stroke. This magnetic functionality is crucial for automation systems that require accurate feedback for process control and safety interlocks. By integrating a magnetic piston, this Pneumatic Cylinder enhances operational efficiency and facilitates seamless integration into advanced control systems.

In summary, the Piston Pneumatic Cylinder combines a robust stainless steel barrel, versatile bore sizes, buffer cushioning, and a magnetic piston in a single-acting, spring return configuration to deliver a dependable and efficient solution for pneumatic actuation needs. Its operating pressure range of 2 to 10 Bar (29 to 145 Psi) ensures adaptability across numerous applications, from manufacturing and assembly lines to automation and robotics. Whether you are seeking a magnetic piston cylinder for precise control or a durable air piston cylinder for heavy-duty operations, this product offers the performance, reliability, and flexibility required to meet your industrial challenges.

Technical Parameters:

Applications:

The NORGREN Piston Pneumatic Cylinder, model number RM/28012/20, is a versatile and reliable component widely used in various industrial and automation applications. Certified with CE standards, this ISO 6432 cylinder is designed to meet stringent quality and safety requirements, ensuring optimal performance in demanding environments. Its compact size and availability in bore sizes ranging from 10mm to 25mm make it an ideal mini cylinder solution for precision tasks where space constraints are critical.

This pneumatic cylinder is perfect for applications requiring single-acting operation with a spring return mechanism and a magnetic piston for position sensing. Its operating pressure range of 2 to 10 bar (29 to 145 Psi) allows it to function efficiently in a wide array of pneumatic systems. Additionally, the buffer cushioning feature enhances the cylinder’s durability and smoothness by minimizing impact at the end of the stroke, which is essential for prolonging the lifespan of equipment and reducing noise during operation.

Operating reliably in temperatures from -10°C to +80°C (14°F to 176°F), the NORGREN RM/28012/20 mini cylinder is suitable for environments with moderate temperature variations, including manufacturing lines, packaging machinery, and automated assembly systems. Its adaptability makes it invaluable in industries such as automotive manufacturing, food processing, electronics assembly, and material handling, where precision and consistent performance are paramount.

With a minimum order quantity of just one piece and a supply ability of 5000 pieces per month, this ISO 6432 cylinder provides flexibility for both small-scale projects and large production runs. Customers can negotiate pricing to best fit their budget, and the product is carefully packaged in cartons or according to client requirements to ensure safe delivery. The delivery time ranges from 1 to 7 workdays after payment, supporting quick turnaround for urgent needs.

Payment terms are convenient and diverse, including T/T, Western Union, and Paypal, facilitating smooth transactions worldwide. Whether you require a mini cylinder for a prototype or a full-scale industrial application, the NORGREN RM/28012/20 piston pneumatic cylinder stands out as a high-quality, efficient, and dependable choice for pneumatic actuation tasks across numerous scenarios.

Packing and Shipping:

Our Piston Pneumatic Cylinder is carefully packaged to ensure maximum protection during transit. Each cylinder is wrapped in anti-static bubble wrap and placed inside a custom-fitted foam insert to prevent movement and absorb shocks. The wrapped product is then placed in a sturdy corrugated cardboard box with reinforced edges to safeguard against external impacts.

For shipping, we use reliable courier services that provide tracking and insurance options, ensuring your order arrives safely and on time. All packages are clearly labeled with handling instructions and product details to facilitate smooth processing through shipping channels.

We also offer customized packaging solutions upon request to meet specific requirements. Whether you need bulk packaging or individual boxes, we can accommodate your needs to ensure the Piston Pneumatic Cylinder reaches you in perfect condition.
