Product Description:
The MECAIR 200 Series represents a collection of diaphragm valves engineered specifically for dust collector systems. They are particularly well-suited for reverse pulse-jet cleaning applications involving filter bags, cartridges, ceramic filters, and sintered metal fiber filters. One of the key design features of these valves is the 90° angle between the inlet and outlet ports, which enables a compact installation while ensuring efficient operation.
This series comes in a variety of sizes, ranging from 3/4” to 2½”, and is equipped with female threaded Gas connections. The MECAIR 200 Series offers two primary versions to accommodate different operational requirements:
- VNP Type: Features an integrated solenoid pilot.
- VEM Type: Equipped with a remote pneumatic connection.
These valves are especially ideal for applications that demand rapid opening times, high flow rates, and dependable performance under harsh environmental conditions. Their robust design and versatile configurations make them a reliable choice in various industrial settings.
Features:
Fast Opening Time
The product features an optimized design that guarantees a rapid response, enabling efficient and effective cleaning operations.
High Flow Capacity
With elevated Kv values, this design enhances pulse efficiency while simultaneously lowering air consumption, making it highly efficient in performance.
Corrosion Resistance
Constructed from die-cast aluminum with anodized protection, the body offers robust durability. Additionally, stainless steel bolts and screws ensure long-lasting resistance to corrosion.
Flexible Diaphragm Options
The diaphragm is available in standard NBR, with optional varieties such as Viton or Nitrile. These options accommodate different temperature ranges and media types to meet diverse application needs.
Compact Design
Its compact structure facilitates straightforward installation, especially in confined or limited spaces.
ATEX Certified Options
For environments that involve explosive atmospheres, ATEX certified versions of this product are available to ensure safety and compliance.
Technical Parameters:
| Medium |
Filtered Compressed Air, Oil-free |
| Protection Class |
IP65 |
| Body Material |
Die-cast Aluminum, Anodized |
| Operating Pressure |
0.5 – 7.5 Bar |
| Diaphragm Material |
Standard NBR |
| Color |
Black |
Applications:
Pulse-Jet Baghouse Dust Collectors
Pulse-jet baghouse dust collectors are advanced filtration systems designed to efficiently capture and remove dust particles from industrial air streams. By using short bursts of compressed air, these collectors effectively clean the filter bags, ensuring continuous operation with minimal downtime.
Cartridge Filter Cleaning Systems
Cartridge filter cleaning systems provide reliable and effective solutions for maintaining filter performance. These systems utilize various cleaning techniques, such as reverse air or pulse-jet cleaning, to extend the life of cartridge filters and maintain optimal filtration efficiency.
Ceramic and Metal Fiber Filter Cleaning
The cleaning of ceramic or metal fiber filters plays a crucial role in industries where high-temperature or corrosive environments are involved. Specialized cleaning processes help preserve the structural integrity of these filters, ensuring their durability and consistent filtration performance.
Industrial Air Pollution Control Systems
Industrial air pollution control systems encompass a wide range of technologies and equipment aimed at minimizing pollutants released into the atmosphere. These systems are essential for complying with environmental regulations and protecting public health by reducing emissions from manufacturing and processing facilities.
Support and Services:
Our Pulse Jet Valves are designed for optimal performance and longevity in industrial applications. For technical support, ensure that the valve is installed according to the manufacturer’s guidelines and that all operating parameters such as pressure and temperature are within specified limits.
Regular maintenance is essential to ensure reliable operation. This includes periodic inspection of seals, diaphragms, and solenoids, as well as cleaning to prevent particulate buildup. Replacement parts should be genuine and compatible with the specific valve model.
If you experience any issues with your Pulse Jet Valve, verify electrical connections, air supply quality, and signal timing. Troubleshooting guides are available in the product manual to assist with common problems.
For service and repair, only qualified personnel should perform disassembly and reassembly to avoid damage and ensure safety. Detailed service manuals provide step-by-step instructions for these procedures.
We recommend keeping a log of maintenance activities and any operational anomalies to assist in diagnosing potential issues. Adhering to these guidelines will help maximize the efficiency and lifespan of your Pulse Jet Valves.
Packing and Shipping:
Our Pulse Jet Valves are carefully packaged to ensure maximum protection during transit. Each valve is securely placed in a custom-designed box with foam padding to prevent any damage from shocks or vibrations. The packaging materials are durable and environmentally friendly, providing both safety and sustainability.
For shipping, we partner with reliable logistics providers to guarantee timely and safe delivery. Each shipment is tracked from our warehouse to your specified location, with clear communication throughout the process. We offer various shipping options to meet your needs, including standard, expedited, and freight services.
Before dispatch, every Pulse Jet Valve undergoes a thorough quality inspection to ensure it meets our high standards. This commitment to quality and careful packaging ensures that you receive your product in perfect working condition, ready for immediate installation and use.
