Product Description:
The UNID US series solenoid valve is designed with a multiplex-drive piston guide mechanism, functioning as a normally closed valve. This means the valve remains closed when de-energized and opens upon being powered, ensuring reliable control in various applications.
Constructed from high-quality cast bronze, the valve body provides outstanding corrosion resistance, making it suitable for use in a wide range of industrial fluid control scenarios. Its robust material composition ensures longevity and durability even in harsh operating environments.
This series is compatible with multiple types of media, including water, air, steam, and heavy oil. It supports fluid temperatures ranging from -5°C to 185°C when equipped with PTFE seals, accommodating diverse process requirements with ease.
The valve comes with standard threaded connections such as BSPT, NPT, and BSP, conforming to international piping standards to facilitate easy installation across different regions. Additionally, coil voltage options include 110VAC, 220VAC, and 24VDC, while custom voltages can also be provided upon special request.
Owing to its versatile design and reliable performance, the US series solenoid valve is extensively applied in automation systems, HVAC units, steam lines, and fuel oil pipelines, serving as a critical component in controlling fluid flow efficiently.
Features:
The product features a reliable multiplex-drive piston structure designed specifically for high pressure handling. This design also provides excellent resistance to clogging, ensuring smooth and efficient operation even under demanding conditions.
Constructed with a cast bronze valve body, the valve offers outstanding corrosion resistance and enhanced durability. This robust material choice extends the lifespan of the valve, making it suitable for long-term use in various industrial applications.
Equipped with high-temperature seals made from PTFE combined with 15% glass fiber, the valve can withstand temperatures up to 185°C. This makes it ideal for handling hot fluids safely and reliably.
The valve demonstrates excellent multi-media compatibility, functioning efficiently with water, air, steam, and heavy oil. It supports a wide operating pressure differential range, details of which can be found in the technical data section.
Multiple port sizes are available, ranging from 1/2" to 2", with Cv values between 4.0 and 48. This variety ensures the valve can meet different flow requirements across diverse applications.
The maximum operating pressure differential varies by media: up to 15 kgf/cm² for water and air, and up to 10 kgf/cm² for steam and heavy oil. Different models accommodate these pressure ranges accordingly.
Optional high-pressure versions are offered, with ratings of 20, 30, and 40 kgf/cm² available upon request. When placing an order for these versions, please specify the type of fluid to ensure optimal configuration.
The coil voltage tolerance allows for stable operation, with an AC tolerance of ±10% and a DC tolerance of ±1%. This ensures reliable performance under varying electrical conditions.
Threaded connection options include BSPT, NPT, and BSP, providing flexibility for different installation requirements.
Designed to be compact and lightweight, the valve is easy to integrate into existing systems without requiring significant modifications or space.
Technical Parameters:
| Body |
Cast Bronze |
| Piston |
Brass |
| Bonnet/Nut |
PTFE |
| Tube |
Stainless Steel |
| Coil |
Special Copper Wire (H) |
| Plug |
PTFE + 15%GF |
| Spring |
Stainless Steel |
| Core Needle |
Stainless Steel |
Applications:
Industrial Systems Overview
Industrial process control plays a crucial role in ensuring efficiency and precision across various manufacturing and production sectors. By automating and regulating machinery and processes, it helps maintain optimal performance and safety standards.
Heating, Ventilation, and Air Conditioning (HVAC) systems are essential for maintaining comfortable and controlled environments in both industrial and commercial settings. These systems regulate temperature, humidity, and air quality to support operational requirements and worker safety.
Steam heating equipment is widely used in industries to provide consistent and reliable heat. This type of equipment utilizes steam to transfer thermal energy, supporting processes that require controlled heating, such as chemical reactions and material treatment.
Fuel burner and transfer systems are critical components in many industrial applications. These systems ensure the efficient combustion of fuels and the safe transfer of energy, contributing to effective heating and power generation processes.
Water treatment and supply systems ensure the availability of clean and safe water for industrial use. These systems are responsible for filtering, purifying, and distributing water to meet the stringent quality standards required in various production processes.
Industries such as petrochemical, power generation, and metallurgy heavily rely on these integrated systems to maintain their operations. The combination of precise control, efficient heating, and reliable resource management supports the complex demands of these sectors.
Support and Services:
Our Pneumatic Solenoid Valve product is designed to deliver reliable and efficient performance in various industrial applications. To ensure optimal operation and longevity, please follow the installation, maintenance, and troubleshooting guidelines provided in the user manual.
For technical support, our team of experts is available to assist with product selection, system integration, and operational queries. We recommend regular inspection and cleaning of the valve components to prevent contamination and ensure smooth functionality.
Replacement parts and accessories are available to maintain and upgrade your pneumatic solenoid valve. Please ensure that all parts used are compatible with your specific valve model to avoid malfunctions.
Our services include on-site support, system diagnostics, and customized solutions tailored to your application needs. We are committed to providing timely and effective assistance to minimize downtime and enhance system performance.
For detailed technical documentation, including datasheets, wiring diagrams, and software updates, please refer to our online resources or product literature.
We encourage users to register their products for warranty coverage and receive updates on product improvements and service notifications.
