UNID Pneumatic Solenoid Valve SUW-15 SS316 Pipe Size 1/2" Orifice 15

Product Description:

The UNID SUW series solenoid valve is designed with a pilot diaphragm-driven mechanism and is classified as a normally closed type. This means the valve remains closed when de-energized and opens upon energization, providing reliable control in various applications.

Constructed from investment cast SUS 316 stainless steel (CF8M), the valve body delivers outstanding corrosion resistance, making it suitable for handling aggressive media and performing reliably in harsh environments. This robust material choice ensures durability and extended service life.

One notable feature of the SUW series is its ability to operate directly even with zero pressure differential, enhancing its versatility across a wide range of systems. The valve comes equipped with standard NBR seals rated for temperatures up to 80°C. For applications requiring higher temperature tolerance, optional seals made from Viton or Silicon materials are available, rated up to 130°C.

To accommodate international piping standards, the valve offers threaded connection options including BSPT, NPT, and BSP. Standard coil voltages available are 110VAC, 220VAC, and 24VDC, with custom voltages also offered upon request to suit specific operational needs.

Due to its reliable performance and adaptability, the SUW series solenoid valve is commonly utilized in industries such as water treatment, chemical processing, pharmaceuticals, food processing, and vacuum systems.

Features:

The pilot diaphragm is engineered with a sensitive structure that ensures precise opening and closing actions while providing excellent resistance to clogging. This design enhances the overall reliability and efficiency of the system.

It operates effectively without requiring any minimum pressure, thanks to its zero pressure differential functionality. This feature allows for smooth performance even under very low pressure conditions.

Constructed from SUS 316 stainless steel (CF8M) through investment casting, the body offers superior corrosion resistance. This makes it highly suitable for handling corrosive fluids, extending the service life of the valve.

The diaphragm is compatible with multiple sealing materials. While the standard seal is made from NBR, rated for temperatures up to 80°C, there are optional seals available in Viton or Silicon that can withstand higher temperatures up to 130°C. This flexibility allows adaptation to various fluid temperature requirements.

Designed for multi-media compatibility, the diaphragm valve works efficiently with water, air, light oil, and vacuum applications. It supports a wide range of operating pressure differentials, which can be referenced in the technical data for specific values.

Available in multiple port sizes ranging from 1/2 inch to 2 inches, with Cv values between 4.5 and 48, the valve can accommodate diverse flow demands. This range ensures it meets various installation and process requirements.

The maximum operating pressure differentials are up to 7 kgf/cm² for air, up to 5 kgf/cm² for water and light oil, and it is also compatible with vacuum conditions, ensuring versatile usage across different environments.

For installation flexibility, the valve features threaded connections with BSPT, NPT, and BSP options, allowing it to fit seamlessly into existing piping systems.

The coil voltage is designed with tolerance for variations, supporting AC voltages with a ±10% margin and DC voltages with a ±1% margin. This ensures stable and reliable operation under fluctuating power supply conditions.

Finally, the compact and lightweight design facilitates easy integration into various systems, saving space and reducing installation complexity.

Technical Parameters:

Applications:

These systems are designed to purify and distribute water for various applications. They ensure that water quality meets required standards through filtration, chemical treatment, and proper delivery methods.

Equipment in this category handles the management and control of aggressive chemicals and fluids. Specialized materials and engineering solutions are used to resist corrosion and maintain safety in chemical processing environments.

This segment includes sophisticated machinery and devices used to manufacture pharmaceuticals and biotech products. Precision and compliance with strict regulatory standards are essential in these systems.

Machinery designed for the preparation and production of food and beverages falls under this category. The equipment focuses on hygiene, efficiency, and preserving the quality and safety of consumable goods.

Vacuum systems create controlled low-pressure environments used across multiple industries. They are vital in applications such as material handling, packaging, and scientific research.

These systems facilitate the movement and combustion of light oils. They are commonly used in heating, power generation, and industrial processes requiring fuel transfer and controlled burning.

Air compression units and pneumatic controls provide energy and automation solutions for various operations. These systems convert compressed air into power for tools, machinery, and control mechanisms.
