| Medium |
Compressed air |
| Operating Temperature |
-34 ... 50 °C, -30 ... 122 °F |
| Port Size |
G1/2 |
| Drain Type |
Automatic |
| Gauge Port |
Rc1/8 |
| Filter Element |
40 μm |
| Adjustment |
Knob |
| Maximum Inlet Pressure |
10 bar, 145 psi |
| Outlet Pressure Adjustment |
0.3 ... 10 bar, 4 ... 145 psi |
Product Description:
Modular Design
Utilizing the Excelon modular system, this product offers flexible combinations and installations with other Excelon items. This enables the creation of a fully integrated gas source processing system tailored to various requirements.
High-Efficiency Filtration
Equipped with two filtration precision options of 5 μm and 40 μm, it effectively eliminates moisture and particulate contaminants from compressed air. This ensures the smooth and reliable operation of all downstream pneumatic components.
Convenient Maintenance
The filter cup features a quick-release bayonet design that allows it to be easily detached without the need for any tools. This simplification facilitates routine cleaning and maintenance tasks, saving time and effort.
Reliable Voltage Regulation
The pressure lock adjustment knob comes with a protective cover that prevents accidental contact. This design helps maintain stable pressure settings and avoids unexpected fluctuations, ensuring dependable performance.
Multiple Drainage Methods
Users can choose between manual or automatic drainage options, making it adaptable to various on-site maintenance scenarios and preferences.
Optional Filter Cup Materials
Transparent polycarbonate cups allow easy monitoring of liquid levels, while metal cups provide enhanced durability suited for more demanding environments.
Wide Applicability
The device supports an outlet pressure regulation range of 0.3 to 10 bar, with a maximum inlet pressure between 10 to 17 bar. It operates efficiently within a temperature range of -20°C to 80°C, fitting a broad spectrum of applications.
Sturdy and Durable
Constructed with an aluminum alloy shell and valve cover, along with brass valve body components, the product achieves an optimal balance of lightweight design and excellent corrosion resistance.
Applications:
Industrial Automation
Air source treatment plays a crucial role in automated production lines, assembly equipment, and packaging machinery. Ensuring clean and reliable air supply enhances the efficiency and longevity of these systems.
Transportation
In sectors requiring high reliability, such as locomotive air supply systems, rail transit, and automobile manufacturing, air source treatment is essential. It guarantees consistent performance and safety in these critical applications.
Precision Fluid Control
Medical equipment, analytical instruments, and similar fields demand stringent gas source cleanliness. Precision fluid control systems rely on purified air to maintain accuracy and ensure reliable operation.
General Pneumatic Systems
Pneumatic tools, spraying devices, cleaning equipment, and material conveying systems all benefit from effective air source treatment. Proper air quality improves their functionality and reduces maintenance requirements.
Food Packaging and Beverages
The purification of gas sources used in packaging machinery and filling lines is vital to uphold hygiene standards and safety in food and beverage production processes.
Chemical and Pharmaceutical Industry
For pneumatic control systems operating in non-explosion-proof environments, air source treatment ensures safe and efficient functioning within chemical and pharmaceutical applications.
Support and Services:
Our Pneumatic Filter Regulator Lubricator (FRL) units are designed to ensure optimal performance and longevity of your pneumatic systems by providing clean, regulated, and lubricated air supply. For technical support, please refer to the product manual for installation, operation, and maintenance guidelines to maximize efficiency and prevent equipment damage.
We offer comprehensive services including troubleshooting assistance, replacement parts provision, and routine maintenance advice to keep your FRL units functioning reliably. Our experts are available to guide you through system setup, calibration, and any adjustments needed to meet your specific application requirements.
Regular maintenance is recommended to ensure the filter element is clean, the regulator is correctly set to the desired pressure, and the lubricator is filled with the appropriate oil. This will help maintain consistent air quality and extend the lifespan of pneumatic components downstream.
Should you experience any issues with your Pneumatic Filter Regulator Lubricator, please consult the troubleshooting section of the manual. Common issues such as pressure fluctuations, air leaks, or insufficient lubrication can often be resolved by checking connections, replacing worn filters, or refilling the lubricator.
For ongoing support, we provide detailed documentation, FAQs, and technical bulletins to assist you in optimizing the use of your FRL products. Our commitment is to ensure your pneumatic systems operate smoothly and efficiently with minimal downtime.
