Product Description:
Modular Design
Utilizing the Excelon modular system, this product allows for flexible combination and installation with other Excelon components. This integration facilitates a streamlined layout for gas source processing systems, enhancing overall efficiency and organization.
High-Efficiency Filtration
The device offers filtration options with accuracies of 5 μm and 40 μm, effectively eliminating moisture and particulate contaminants from compressed air. This filtration ensures the proper functioning of downstream pneumatic equipment by maintaining clean airflow.
Convenient Maintenance
Featuring a quick-release bayonet cup design, the filter cup can be easily detached without the use of tools. This innovation simplifies routine cleaning and maintenance tasks, reducing downtime and effort.
Reliable Voltage Regulation
Equipped with a press-lock adjustment knob accompanied by a protective cover, this feature prevents accidental touches that could cause pressure fluctuations. As a result, it guarantees stable and dependable pressure settings.
Multiple Drainage Methods
To suit various maintenance scenarios, the device supports both manual and automatic drainage options. This flexibility ensures adaptability to different onsite requirements.
Filter Cup Material Options
Users can select between transparent polycarbonate cups, which allow easy monitoring of liquid levels, and metal cups, which are better suited for harsher environments demanding increased durability.
Wide Applicability
The outlet pressure can be regulated within a range of 0.3 to 10 bar, accommodating maximum inlet pressures from 10 to 17 bar. Additionally, the device operates effectively across a temperature span of -20°C to 80°C, making it suitable for diverse working conditions.
Sturdy and Durable Construction
The shell and valve cover are crafted from aluminum alloy for a balance of lightweight and strength, while the valve body components are made of brass to provide excellent corrosion resistance, ensuring long-lasting reliability.
Applications:
Industrial Automation
Air source treatment plays a crucial role in automated production lines, assembly equipment, and packaging machinery. It ensures the smooth and efficient operation of these systems by providing clean and reliable air supply.
Transportation
In transportation sectors demanding high reliability, such as locomotive air supply systems, rail transit, and automobile manufacturing, air source treatment is essential. It helps maintain consistent performance and safety standards.
Precision Fluid Control
Applications requiring stringent cleanliness of the gas source, including medical devices and analytical instruments, heavily rely on precision fluid control. Proper air source treatment ensures that these sensitive systems function accurately and hygienically.
General Pneumatic Systems
Pneumatic tools, spraying equipment, cleaning apparatus, and material conveying systems utilize general pneumatic systems. Effective air source treatment contributes to their durability and operational effectiveness.
Food Packaging and Beverages
The purification of gas sources is vital in food packaging machinery and filling lines. This process guarantees production hygiene and safety, meeting industry standards and consumer expectations.
Chemical and Pharmaceutical Industry
Within the chemical and pharmaceutical sectors, air source treatment is applied to pneumatic control systems, particularly in non-explosion proof environments. This enhances safety while maintaining system reliability.
Support and Services:
Our Pneumatic Filter Regulator Lubricator (FRL) units are designed to ensure optimal performance and longevity of your pneumatic systems by providing clean, regulated, and lubricated air. To achieve the best results, please follow the installation, maintenance, and troubleshooting guidelines outlined below.
Installation: Before installing the FRL unit, ensure that the air supply is clean and free from excessive moisture and contaminants. Mount the unit vertically with the air flow direction arrow matching the system’s airflow. Use appropriate fittings and avoid over-tightening to prevent damage. Connect the unit upstream of the equipment requiring filtered, regulated, and lubricated air.
Operation: Adjust the regulator knob to the desired pressure setting within the specified range. Monitor the pressure gauge to ensure stable output. The filter element should be checked regularly and replaced when necessary to maintain efficient filtration. The lubricator bowl should be filled with the recommended pneumatic oil, and the drip rate adjusted according to the manufacturer’s specifications to ensure proper lubrication of downstream components.
Maintenance: Periodically inspect the filter bowl for accumulated contaminants and drain as needed. Replace filter elements and lubricator oil at intervals based on operating conditions and manufacturer recommendations. Clean the unit with a soft cloth and mild detergent, avoiding harsh chemicals that may damage components. Check for air leaks and tighten fittings if necessary.
Troubleshooting: If you experience pressure fluctuations, insufficient lubrication, or air leaks, verify that the unit is installed correctly and that all connections are secure. Replace worn or damaged parts promptly. Consult the product manual for detailed troubleshooting steps and parts diagrams.
For further assistance, please refer to the product manual or technical documentation provided with your Pneumatic Filter Regulator Lubricator unit.
Packing and Shipping:
Product Packaging: The Pneumatic Filter Regulator Lubricator is securely packaged in a sturdy, high-quality cardboard box to prevent any damage during transit. Inside the box, the product is cushioned with protective foam inserts to ensure stability and protection against shocks and vibrations. The packaging includes clear labeling with product details, model number, and handling instructions to facilitate easy identification and safe handling.
Shipping: The product is shipped using reliable courier services that offer tracking and insurance options. Each package is carefully handled to maintain the integrity of the Pneumatic Filter Regulator Lubricator throughout the shipping process. For bulk orders, pallets are used with shrink wrap and corner protectors to enhance safety during transportation. Estimated delivery times and shipping methods are provided at the time of purchase, ensuring timely and secure delivery to the customer.
