Product Description:
The Festo ADVU-12 is a compact pneumatic cylinder designed for double-acting functionality. It features a 12 mm bore and includes an integrated magnetic piston, which allows for precise position sensing.
This cylinder is equipped with elastic cushioning rings at both ends, known as P-type cushioning, to ensure smooth operation and reduce impact forces. The product is offered in standard stroke lengths ranging from 5 mm to 40 mm.
Customers can choose between piston rod options with either an internal thread (‑P‑A) or an external thread (‑A‑P‑A). The cylinder operates efficiently within a pressure range of 1.2 to 10 bar.
Its compact design and reliable position feedback make the Festo ADVU-12 an ideal solution for automation applications where space is limited and precise control is essential.
Features:
Ultra-Compact Design
The cylinder features an ultra-compact design, requiring up to 50% less installation space compared to standard ISO 15552 cylinders. This makes it an excellent choice for machines with limited space, allowing for more efficient layouts.
Double-Acting Operation
Equipped with double-acting functionality, this cylinder delivers force during both the forward and return strokes. This ensures a smooth and consistent motion that can be easily controlled throughout its operation.
Integrated Magnetic Piston
The integrated magnetic piston enables non-contact position sensing by using proximity sensors. An added benefit is that the sensors can be replaced or adjusted without needing any mechanical modifications, enhancing maintenance convenience.
Elastic Cushioning (P-Type)
Featuring elastic cushioning at the end positions, the P-type design effectively reduces impact energy. This minimizes vibrations and noise, contributing to a quieter and more durable operation.
Robust and Corrosion-Resistant Materials
Constructed from anodized aluminium for the barrel and end caps, combined with a stainless steel piston rod and NBR/TPE-U seals, the cylinder boasts a high level of corrosion resistance. It meets the CRC 2 standard, making it suitable for demanding industrial environments.
Flexible Mounting Options
The design includes through-holes on the barrel and supports a wide array of mounting accessories, allowing for versatile installation methods tailored to your specific needs.
Two Piston Rod Thread Options
Users can select between two piston rod thread types: an internal thread (-P-A) or an external thread (-A-P-A). This flexibility accommodates different load attachments and application requirements.
Technical Parameters:
| Operating Pressure |
1.2 - 10 Bar |
| Ambient Temperature |
-20 - +80 °C |
| Operation |
Double-acting |
| Series |
ADVU |
| Bore |
12 mm |
| Brand |
Festo |
Applications:
Automated assembly lines benefit greatly from compact stations designed for clamping, positioning, sorting, stopping, and ejecting various workpieces. These streamlined processes enhance efficiency and precision in manufacturing environments.
In the field of electronics and semiconductor manufacturing, there is a critical need for precise pick-and-place operations. Tasks such as integrated circuit handling, PCB depaneling, and the assembly of delicate components require meticulous control and accuracy.
Packaging and filling machinery utilize mechanisms for carton pushing, sealing presses, and valve actuation within confined spaces. These actions ensure that packaging processes are both reliable and effective, even in limited physical environments.
Medical devices and laboratory automation demand smooth and low-force movements. These are essential for diagnostic equipment operations, the transport of samples, and precise liquid handling to maintain the integrity of sensitive processes.
Printing and textile machines perform functions such as paper positioning, cutting press operations, and yarn clamping. These tasks often take place in challenging conditions characterized by oily or inky surroundings, requiring robust yet delicate handling.
Robot end effectors incorporate compact pneumatic gripper drives, enabling seamless integration with collaborative robots and pick-and-place units. This technology supports versatile automation solutions across various industries.
Support and Services:
Our Piston Pneumatic Cylinder product is designed to provide reliable and efficient linear motion for a wide range of industrial applications. To ensure optimal performance, it is important to follow proper installation, maintenance, and troubleshooting guidelines.
Installation:
Before installation, verify that the cylinder specifications match the application requirements. Ensure all mounting surfaces are clean and free from debris. Use appropriate mounting brackets and hardware to securely install the cylinder. Connect the pneumatic lines according to the specified ports and check for leaks.
Maintenance:
Regular maintenance is essential to extend the life of the piston pneumatic cylinder. Periodically inspect the cylinder for signs of wear, damage, or leaks. Lubricate the cylinder as recommended in the product manual to reduce friction and prevent corrosion. Replace seals and other wear components as needed to maintain performance.
Troubleshooting:
If the cylinder is not operating correctly, check for common issues such as air supply problems, improper installation, or damaged seals. Verify that the air pressure is within the recommended range and that all connections are secure. Inspect the piston rod for bending or scoring, and ensure the cylinder is properly aligned with the load.
For detailed technical support and service, please refer to the product manual or contact our support team. We are committed to providing comprehensive assistance to ensure your pneumatic cylinder operates efficiently and reliably.
Packing and Shipping:
Our Piston Pneumatic Cylinder is carefully packaged to ensure maximum protection during transit. Each cylinder is securely wrapped with anti-static bubble wrap and placed inside a sturdy, custom-fitted cardboard box to prevent any movement or damage. Additional cushioning materials are used to absorb shocks and vibrations, ensuring the product arrives in perfect condition.
For shipping, we partner with reliable carriers to provide timely and safe delivery worldwide. Each package is labeled clearly with handling instructions and tracking information. We also offer various shipping options to meet your urgency and budget requirements. Rest assured, your Piston Pneumatic Cylinder will be delivered efficiently and securely to your doorstep.
