Product Description:

The Festo ADVU-16 is a compact pneumatic cylinder designed with a 16 mm bore and double-acting functionality. It features an integrated magnetic piston that allows for accurate position sensing, enhancing operational reliability.

This cylinder is equipped with elastic cushioning rings located at both ends, known as P-type cushioning, which help to reduce impact forces and extend the lifespan of the device. It is available in standard stroke lengths ranging from 5 mm up to 40 mm.

Customers can choose between piston rods with either internal thread (-P-A) or external thread (-A-P-A) options, depending on their specific installation requirements. The ADVU-16 operates efficiently within a pressure range of 1.0 to 10 bar.

Thanks to its compact size and integrated features, the Festo ADVU-16 is ideal for automation tasks where space is limited but reliable position feedback is essential.

Features:

The ultra-compact design of this cylinder offers up to 50% less installation space compared to standard ISO 15552 cylinders. This makes it an ideal solution for machines with limited space, allowing for efficient layouts without compromising functionality.

Featuring double-acting operation, the cylinder delivers driving force during both the forward and return strokes. This ensures smooth, consistent, and precisely controlled bidirectional movement, enhancing the performance of your machinery.

Equipped with an integrated magnetic piston, the device supports non-contact position sensing through proximity switches. This design allows sensors to be mounted or replaced easily without requiring any mechanical adjustments, simplifying maintenance and increasing reliability.

The elastic cushioning system (P-type) includes flexible cushioning rings and plates positioned at both ends of the cylinder. This setup effectively reduces impact energy, minimizing vibration and noise when the piston reaches the end positions, thus prolonging the cylinder’s lifespan and improving operational comfort.

Constructed from robust and corrosion-resistant materials, the cylinder features a wrought aluminium alloy barrel and end caps, a high-alloy stainless steel piston rod, and durable NBR/TPE-U (PU) dynamic seals. With a corrosion resistance class of CRC 2, it is well-suited for demanding industrial environments.

For installation versatility, the cylinder offers flexible mounting options. It includes through-holes on the barrel along with a wide variety of mounting accessories, allowing it to be installed securely in almost any position to meet diverse application requirements.

Additionally, there are two piston rod thread options available: an internal thread (‑P‑A) and an external thread (‑A‑P‑A). These options enable you to select the best fit for different load attachments and specific application needs.

Technical Parameters:

Applications:

Automated assembly lines involve various tasks such as clamping, positioning, sorting, stopping, ejecting, and handling workpieces within compact production stations. These processes require precise and efficient mechanisms to maintain productivity and quality.

In packaging and filling machinery, functions like carton pushing, sealing press actuation, conveyor diverters, and valve control are performed in confined spaces. This demands compact and reliable components to ensure smooth operation within limited areas.

The electronics and semiconductor manufacturing sector relies on highly accurate pick-and-place systems, PCB depaneling, component assembly, and testing equipment positioning. Precision and repeatability are critical to meet the stringent requirements of this industry.

Material handling and conveyor systems utilize rotary and clamping stopper cylinders for conveyor lines, as well as diverters and distribution systems. These components play a vital role in controlling material flow and ensuring efficient logistics.

In the automotive industry, activities such as component assembly, parts feeding, and production line automation demand dependable and compact actuators. These are essential for enhancing operational efficiency and reliability in vehicle manufacturing processes.

Medical devices and laboratory automation benefit from smooth and controlled linear motion solutions. Applications include diagnostic equipment, sample handling, and various biotechnology tasks where precision and gentle handling are paramount.

Robot end effectors and grippers employ compact pneumatic drives to support collaborative robots, pick-and-place units, and automated gripping mechanisms. These actuators contribute to versatility and flexibility in robotic applications.

Printing and textile machinery require accurate paper positioning, cutting press actuation, yarn clamping, and tension control even in challenging environments. Robust and precise components ensure consistent performance and high-quality outputs.
