Textile Machinery ADVU-16-20-A-P-A 156596 Festo External Thread Double-Acting Cylinder 16mm Bore 20mm Stroke M5 Port Magnetic Piston Compact ISO 6432

Product Description:

The Festo ADVU-16 is a compact pneumatic cylinder designed with double-acting functionality. It features a 16 mm bore size and an integrated magnetic piston, which allows for precise position sensing during operation.

Equipped with elastic cushioning rings at both ends, referred to as P-type cushioning, this cylinder ensures smooth and controlled motion. The product is available in standard stroke lengths ranging from 5 mm up to 40 mm, catering to various application needs.

Customers can choose between different piston rod thread options, including internal thread (-P-A) and external thread (-A-P-A), to best suit their mounting requirements. The ADVU-16 operates efficiently within a pressure range of 1.0 to 10 bar.

This compact design is particularly suitable for automation tasks where space savings are crucial, while also providing reliable position feedback through its integrated magnetic piston.

Features:

This cylinder boasts an ultra-compact design, occupying up to 50% less installation space compared to standard ISO 15552 cylinders. This makes it an ideal choice for machines with limited layout space, allowing for more efficient use of available area.

Featuring double-acting functionality, the cylinder generates driving force during both the forward and return strokes. This ensures consistent and controllable motion in both directions, enhancing operational reliability.

The piston is equipped with an integrated magnetic feature that supports non-contact position detection through proximity switches. These sensors can be installed or replaced effortlessly without the need for mechanical adjustments, simplifying maintenance.

Elastic cushioning rings and plates are positioned at both ends of the cylinder, effectively reducing impact energy. This design minimizes vibration and noise when the piston reaches end positions, contributing to smoother and quieter operation.

Constructed from high-quality materials such as wrought aluminium alloy for the barrel and end caps, and high-alloy stainless steel for the piston rod, this cylinder ensures durability. Additionally, the dynamic seals are made from NBR and TPE-U (PU), with a corrosion resistance class of CRC 2 tailored for industrial environments.

The cylinder is designed with through-holes on the barrel and accommodates a broad range of mounting accessories. This versatile configuration allows it to be installed in virtually any position to suit various application requirements.

Users can select between two piston rod thread options: internal thread (‑P‑A) or external thread (‑A‑P‑A). This flexibility enables compatibility with different load attachments and meets diverse application needs.

Technical Parameters:

Applications:

In automated assembly lines, compact production stations benefit greatly from various functions such as clamping, positioning, sorting, stopping, ejecting, and efficient workpiece handling. These processes ensure smooth and precise manufacturing operations.

Packaging and filling machinery often operate within limited spaces, where carton pushing, sealing press actuation, conveyor diverters, and valve control are essential tasks. Compact actuators help optimize these functions without compromising performance.

The electronics and semiconductor manufacturing sectors demand high precision in processes such as pick-and-place operations, PCB depaneling, component assembly, and the positioning of testing equipment. The implementation of precise actuators enhances the accuracy and reliability of production.

Material handling and conveyor systems utilize rotary and clamping stopper cylinders to manage conveyor lines, diverters, and distribution systems. These actuators contribute to streamlined movement and effective control within logistics and production flows.

In the automotive industry, the assembly of components, feeding of parts, and overall production line automation require actuators that are both reliable and compact. Their integration supports the high standards necessary for automotive manufacturing.

Medical devices and laboratory automation benefit from smooth and controlled linear motion, crucial for diagnostic equipment, sample handling, and various biotechnology applications. Compact actuators ensure precision and delicate operation in these sensitive environments.

Robot end effectors and grippers rely on compact pneumatic drives to enable collaborative robots, pick-and-place units, and automated gripping systems. These actuators facilitate efficient and safe robotic operations in diverse industrial settings.

Printing and textile machinery involve demanding environments where tasks like paper positioning, cutting press actuation, yarn clamping, and tension control must be performed accurately. Compact actuators provide the necessary control and durability for such applications.

Support and Services:

Our Piston Pneumatic Cylinders are engineered for reliable and efficient performance in a wide range of industrial applications. To ensure optimal operation and longevity of your pneumatic cylinder, please follow the recommended maintenance and service guidelines.

Installation: Prior to installation, verify that the cylinder specifications match your application requirements. Ensure all mounting surfaces are clean and free from debris. Use appropriate fittings and connectors to prevent air leaks.

Operation: Operate the cylinder within the specified pressure and temperature ranges. Avoid exceeding the maximum stroke length and load capacity to prevent damage. Use clean, dry, and lubricated compressed air to enhance performance and reduce wear.

Maintenance: Regularly inspect the cylinder for signs of wear, corrosion, or damage. Check seals and replace them if leakage is detected. Lubricate moving parts as per the manufacturer’s recommendations to maintain smooth operation.

Troubleshooting: Common issues include air leaks, reduced speed, and erratic movement. Inspect connections for tightness, ensure air supply quality, and verify that the cylinder is not subjected to side loads or misalignment. Replace damaged components promptly to avoid further issues.

Spare Parts and Repairs: Use only genuine replacement parts to maintain product integrity and warranty coverage. For repairs beyond routine maintenance, consult authorized service centers or technical support resources.

Technical Support: For additional assistance with installation, troubleshooting, or maintenance, refer to the product manual or technical datasheets. Our support team is available to provide expert guidance to ensure your pneumatic cylinder operates at peak efficiency.

Packing and Shipping:

Product Packaging and Shipping for Piston Pneumatic Cylinder

Each piston pneumatic cylinder is carefully packaged to ensure safety and protection during transit. The cylinder is first wrapped in anti-static bubble wrap to prevent any damage from shocks or vibrations. It is then placed inside a sturdy, custom-fitted cardboard box that provides additional cushioning and support.

For bulk orders, multiple units are securely arranged in larger cartons with appropriate padding materials such as foam inserts or air pillows to avoid movement and impact. All packages are sealed with high-quality packing tape and labeled clearly with product information and handling instructions.

Shipping options include standard ground, expedited air freight, and international delivery. We collaborate with trusted courier services to ensure timely and reliable delivery. Tracking information is provided to customers once the shipment is dispatched, allowing full visibility throughout the shipping process.

Special care is taken to comply with all safety and regulatory requirements for pneumatic components during packaging and shipping, guaranteeing that the piston pneumatic cylinders arrive in perfect working condition, ready for immediate installation and use.
