Product Description:
The Festo ADVU-16 is a compact pneumatic cylinder designed for double-acting functionality. It features a 16 mm bore size, making it suitable for applications where space is limited.
Equipped with an integrated magnetic piston, this cylinder allows for accurate position sensing. Additionally, it includes elastic cushioning rings on both ends, known as P-type cushioning, which helps to absorb shocks and extend the lifespan of the cylinder.
The ADVU-16 model is available in standard stroke lengths ranging from 5 mm to 40 mm. Customers can choose between piston rods with internal threads (-P-A) or external threads (-A-P-A), depending on their specific mounting requirements.
With an operating pressure range between 1.0 and 10 bar, this pneumatic cylinder is well-suited for automation tasks where reliable and consistent position feedback is essential. Its compact design and robust features make it an excellent choice for space-saving automation solutions.
Features:
The ultra-compact design of these cylinders requires up to 50% less installation space compared to the ISO 15552 standard cylinders. This makes them ideal for use in machines with limited space, allowing for tighter and more efficient layouts.
Featuring double-acting operation, these cylinders deliver driving force during both the forward and return strokes. This ensures smooth, controllable motion in both directions, enhancing the precision and reliability of your applications.
An integrated magnetic piston allows for non-contact position sensing through proximity switches. This design means sensors can be installed or replaced easily without the need for any mechanical adjustments, improving maintenance efficiency.
The elastic cushioning system (P-type) incorporates flexible cushioning rings and plates at both ends of the cylinder. This effectively reduces impact energy, minimizing vibrations and noise when the piston reaches the end positions, thus extending the component's operational life.
Constructed from robust and corrosion-resistant materials, the cylinders feature a wrought aluminium alloy barrel and end caps, a high-alloy stainless steel piston rod, as well as NBR/TPE-U (PU) dynamic seals. They comply with corrosion resistance class CRC 2, making them suitable for demanding industrial environments.
Installation is versatile thanks to through-holes on the barrel and a wide range of mounting accessories. This flexibility allows for mounting in virtually any position to suit your machinery setup.
Additionally, there are two piston rod thread options available: internal thread (‑P‑A) and external thread (‑A‑P‑A). This choice provides adaptability to different load attachments and application requirements.
Technical Parameters:
| Brand |
Festo |
| Ambient Temperature |
-20 ... +80 °C |
| Operating Pressure |
1.0 ... 10 Bar |
| Series |
ADVU |
| Operation |
Double-acting |
| Bore |
16mm |
Applications:
In automated assembly lines, compact actuators play a crucial role by performing tasks such as clamping, positioning, sorting, stopping, ejecting, and handling workpieces efficiently within confined production stations.
Packaging and filling machinery benefit greatly from these actuators through functions like carton pushing, sealing press activation, conveyor diverter control, and valve management, all within limited available space.
The electronics and semiconductor manufacturing industries utilize precise pick-and-place operations, PCB depaneling, component assembly, and accurate positioning of testing equipment, made possible by the reliability of these compact systems.
In material handling and conveyor systems, rotary and clamping stopper cylinders are implemented to manage conveyor lines, diverters, and distribution mechanisms effectively.
The automotive sector depends on these actuators for component assembly, parts feeding, and automation of production lines, where dependable and space-saving solutions are essential.
Medical devices and laboratory automation require smooth and controlled linear motion for diagnostic instruments, sample processing, and various biotechnology applications, which are efficiently supported by these advanced actuators.
Robot end effectors and grippers utilize compact pneumatic drives to enhance the functionality of collaborative robots, as well as pick-and-place units and automated gripping systems.
Lastly, printing and textile machinery rely on these actuators for tasks such as paper positioning, cutting press actuation, yarn clamping, and tension control, even in challenging and demanding work environments.
Support and Services:
Our Piston Pneumatic Cylinders are designed for reliable and efficient performance in a wide range of industrial applications. For technical support, please refer to the product manual for installation, operation, and maintenance guidelines to ensure optimal functionality and longevity of the cylinder.
If you encounter any issues, verify that the cylinder is installed correctly and that the pneumatic system pressure is within the recommended range. Regular inspection and maintenance, such as checking for air leaks and lubricating moving parts, are essential to prevent operational problems.
For troubleshooting, common issues such as air leakage, sticking piston, or unusual noises can often be resolved by inspecting seals, cleaning cylinder components, and ensuring proper alignment. Replacement parts are available for worn or damaged components to restore cylinder performance.
We offer comprehensive after-sales services including repair, maintenance, and technical consultation to support your pneumatic system needs. Our technical team is equipped to assist with custom configurations and integration advice to help you maximize the efficiency of your pneumatic applications.
Please ensure that all safety precautions are followed during installation and servicing to prevent injury and equipment damage. For detailed technical documentation and support resources, visit our official website or consult the product datasheet provided with your purchase.
