Product Description:
The Festo ADVU-16 is a compact pneumatic cylinder designed with a 16 mm bore. It features a double-acting mechanism, which allows it to extend and retract using air pressure on both sides of the piston for smooth and efficient motion.
Equipped with an integrated magnetic piston, this cylinder supports precise position sensing, making it suitable for applications that demand accurate feedback. Additionally, it includes elastic cushioning rings on both ends, known as P-type cushioning, to absorb impact and reduce noise during operation.
Customers can choose from a range of standard stroke lengths, ranging from 5 mm up to 40 mm. The piston rod is available in two configurations: with an internal thread (-P-A) or with an external thread (-A-P-A), providing flexibility for various mounting requirements.
Operating within a pressure range of 1.0 to 10 bar, the ADVU-16 is an excellent choice for automation tasks where space is limited but reliable position feedback is critical. Its robust design and versatile options make it ideal for compact and precise automation systems.
Features:
The ultra-compact design of this cylinder saves up to 50% of installation space compared to the ISO 15552 standard cylinders. This makes it an excellent choice for applications where space is limited and machine layouts are tight.
Equipped with double-acting operation, the cylinder delivers driving force during both forward and return strokes. This ensures a consistent and controllable bidirectional motion, enhancing the precision and efficiency of the system.
Featuring an integrated magnetic piston, the cylinder supports non-contact position sensing through proximity switches. This allows sensors to be mounted or replaced easily without requiring any mechanical adjustments, simplifying maintenance and monitoring.
Designed with elastic cushioning (P-type) at both ends, flexible cushioning rings and plates effectively reduce impact energy. This minimizes vibration and noise at the cylinder’s end positions, contributing to a quieter and smoother operation.
The cylinder is constructed from robust and corrosion-resistant materials, including a wrought aluminium alloy barrel and end caps, a high-alloy stainless steel piston rod, and dynamic seals made from NBR and TPE-U (PU). It meets corrosion resistance class CRC 2, making it suitable for demanding industrial environments.
Flexible mounting options are available, featuring through-holes on the barrel and a wide range of mounting accessories. This versatility allows for installation in virtually any position to accommodate various application requirements.
To cater to different load attachments and application needs, two piston rod thread options are offered: an internal thread (‑P‑A) and an external thread (‑A‑P‑A). This flexibility ensures compatibility with a variety of setups.
Technical Parameters:
| Brand |
Festo |
| Operation |
Double-acting |
| Operating Pressure |
1.0 ... 10 Bar |
| Ambient Temperature |
-20 ... +80 °C |
| Bore |
16mm |
| Series |
ADVU |
Applications:
Automated assembly lines benefit from various compact production stations designed for tasks such as clamping, positioning, sorting, stopping, ejecting, and efficient handling of workpieces. These stations enhance the automation process by ensuring precise and reliable operations within a confined space.
In the realm of packaging and filling machinery, equipment must perform functions like carton pushing, activating sealing presses, controlling conveyor diverters, and managing valves within limited spatial constraints. These capabilities are critical for maintaining smooth production flow and consistent packaging quality.
The electronics and semiconductor manufacturing industry relies on highly accurate systems for tasks such as precise pick-and-place operations, PCB depaneling, component assembly, and the positioning of testing devices. This precision supports the complex requirements necessary for producing advanced electronic components.
Material handling and conveyor systems utilize rotary and clamping stopper cylinders to efficiently manage conveyor lines, diverters, and distribution mechanisms. These components contribute to the seamless transport and sorting of materials throughout various stages of production.
Within the automotive sector, compact and reliable actuators play a crucial role in component assembly, parts feeding, and the overall automation of production lines. Their dependability and compact size make them well-suited for the rigorous demands of automotive manufacturing.
Medical device manufacturing and laboratory automation require smooth and controlled linear motion solutions for diagnostic equipment, sample handling, and biotechnology applications. These operations demand high precision and gentle handling to ensure accuracy and safety.
Robot end effectors and grippers employ compact pneumatic drives to facilitate collaborative robots, efficient pick-and-place units, and automated gripping mechanisms. These pneumatic systems enhance the flexibility and responsiveness of robotic automation.
In printing and textile machinery, tasks such as paper positioning, cutting press actuation, yarn clamping, and tension control occur within challenging environments. Robust and precise machinery components ensure consistent performance under these demanding conditions.
Support and Services:
Our Piston Pneumatic Cylinder product is supported by a dedicated technical support team committed to ensuring optimal performance and customer satisfaction. We provide comprehensive installation guidance, troubleshooting assistance, and maintenance tips to help you get the most out of your pneumatic cylinder.
In addition to technical support, we offer a range of services including customization options to meet specific application requirements, repair and refurbishment services to extend the life of your cylinders, and training sessions to empower your team with in-depth product knowledge.
For any technical inquiries or service requests, our experts are ready to assist you with detailed product information, operational advice, and solutions tailored to your industrial needs. We strive to provide timely and effective support to minimize downtime and enhance productivity.
Explore our resources and services to ensure your Piston Pneumatic Cylinder operates efficiently and reliably in your applications.
Packing and Shipping:
Our Piston Pneumatic Cylinder is carefully packaged to ensure maximum protection during transit. Each cylinder is wrapped in anti-static bubble wrap and placed inside a sturdy cardboard box to prevent damage from impact and moisture. The packaging is clearly labeled with handling instructions to guarantee safe delivery.
For shipping, we use reliable carriers that provide tracking and timely delivery services. The Piston Pneumatic Cylinder is shipped with appropriate cushioning materials to avoid any movement inside the box. We offer various shipping options to meet your urgency and budget requirements, ensuring your product arrives securely and on time.
