For Automation Assembly Festo ADVU-16-5-P-A 156507 Compact Double-Acting Cylinder 16mm Bore 5mm Stroke Internal Thread M5 Port Magnetic Piston ISO 6432

The ultra-compact design of this product requires up to 50% less installation space compared to standard ISO 15552 cylinders. This makes it an ideal solution for applications where space is limited and machine layouts are tight.

Featuring double-acting operation, the cylinder delivers driving force during both forward and return strokes. This ensures smooth, consistent, and controllable bidirectional motion for various industrial tasks.

An integrated magnetic piston allows for non-contact position detection through the use of proximity switches. These sensors can be mounted or replaced easily without the need for any mechanical adjustments, enhancing convenience and reliability.

The elastic cushioning system, specifically the P-type, incorporates flexible cushioning rings and plates at both ends. This design effectively reduces impact energy, minimises vibration, and lowers noise levels when the piston reaches the end positions.

Constructed from robust and corrosion-resistant materials, the cylinder features a wrought aluminium alloy barrel and end caps, a high-alloy stainless steel piston rod, and dynamic seals made of NBR, TPE-U, or PU. It meets corrosion resistance class CRC 2 standards, making it suitable for demanding industrial environments.

To accommodate various installation requirements, the barrel includes through-holes and there is a wide selection of mounting accessories available. This flexibility allows for versatile mounting options in virtually any position.

Additionally, two piston rod thread options are offered: an internal thread (‑P‑A) and an external thread (‑A‑P‑A). These options provide compatibility with different load attachments and meet diverse application needs.

Automated assembly lines utilize compact production stations for various tasks such as clamping, positioning, sorting, stopping, ejecting, and handling workpieces efficiently. These integrated systems streamline manufacturing by ensuring precise and reliable operations within a confined space.

In the realm of packaging and filling machinery, applications include carton pushing, activating sealing presses, controlling conveyor diverters, and managing valve operations. These functions are designed to operate effectively even within limited installation areas, optimizing space utilization.

The electronics and semiconductor manufacturing sector demands high precision in processes like pick-and-place, PCB depaneling, component assembly, and positioning of testing equipment. Advanced technologies facilitate meticulous handling that upholds the strict quality standards required in this field.

Material handling and conveyor systems benefit from the use of rotary and clamping stopper cylinders which support conveyor lines, diverters, and distribution mechanisms. These components contribute to smooth transportation and accurate sorting of goods throughout the production cycle.

The automotive industry relies on compact and dependable actuators for tasks including component assembly, parts feeding, and overall production line automation. These actuators ensure consistent performance and durability in demanding manufacturing environments.

Within medical devices and laboratory automation, smooth and controlled linear motion is essential for diagnostic equipment, sample handling, and various biotechnology applications. Precision motion control enhances the efficiency and reliability of these sensitive and critical operations.

Robot end effectors and grippers are equipped with compact pneumatic drives tailored for collaborative robots, pick-and-place units, and automated gripping systems. These drives enable flexible and precise manipulation of objects in industrial automation settings.

Printing and textile machinery incorporate technologies for accurate paper positioning, cutting press actuation, yarn clamping, and tension control. These functions are designed to perform reliably even under the challenging conditions typical of these industries.
