Automated Positioning – Festo ADNGF-16-15-P-A Double Acting Compact Guided Cylinder (16mm Bore X 15mm Stroke)

Technical Data

• Stroke20 mm
• Piston diameter12 mm
• Based on normISO 21287
• CushioningElastic cushioning rings/pads at both ends
• Mounting positionAny
• Structural designPiston Piston rod Profile barrel
• Position sensingVia proximity switch
• Protection against torsion/guideGuide rod with yoke

Product Description:

The FESTO ADNGF series is a double-acting compact cylinder designed to offer a slim profile, incorporating a built-in guide rod that enhances its positioning accuracy. This makes it an excellent choice for applications requiring precise control in limited spaces.

Constructed from high-quality aluminum alloy, the cylinder ensures smooth operation and durability over an extended service life. Its magnetic piston further facilitates easy position sensing, improving efficiency and reliability in automated processes.

Due to its compact size and reliable performance, the ADNGF series is ideal for use in automation equipment where space is constrained. It is extensively utilized in various industrial automatic machines for tasks such as clamping, positioning, pushing, and lifting.

Features:

The standard FESTO ADNGF double acting thin cylinder features a compact and slim design, which helps save valuable installation space. Its streamlined structure makes it an ideal choice for applications where space is limited.

Incorporating a built-in guide rod, this cylinder offers strong anti-torsion capabilities and ensures high positioning accuracy during operation. This design enhances reliability and performance in precision tasks.

The magnetic piston is designed to facilitate the easy installation of proximity sensors, allowing for efficient position detection. This feature simplifies integration with automation systems and improves monitoring accuracy.

Constructed from high-quality aluminum alloy, the cylinder body is both durable and wear-resistant. Together with its robust seals, it guarantees stable operation and a long service life even in demanding environments.

It operates effectively across a wide pressure range, providing consistent pushing and pulling forces with smooth movement. This versatility makes it suitable for various industrial applications.

Multiple mounting options are available, ensuring easy installation and adaptability to different automation equipment setups. Additionally, the cylinder is equipped with a buffer pad that significantly reduces impact and minimizes running noise, enhancing overall performance and longevity.

Technical Parameters:

Applications:

The FESTO ADNGF double acting compact cylinder is an ideal choice for a variety of industrial applications. Its design makes it highly suitable for automated positioning tasks, securely clamping workpieces, pushing materials, stop positioning, and performing short-stroke lifting operations efficiently.

This compact cylinder finds extensive use in fields such as electronic machinery, packaging equipment, and automotive production lines. Its versatility also extends to 3C precision automation and assembly jigs, where precise and reliable pneumatic motion is critical.

Additionally, the FESTO ADNGF cylinder is well-suited for food machinery and other pneumatic driving systems that operate in limited spaces. Its compact size combined with robust performance makes it a perfect fit for equipment requiring dependable and space-saving pneumatic solutions.

Support and Services:

Our Piston Pneumatic Cylinder product is designed to deliver reliable and efficient performance in a wide range of industrial applications. For technical support, we provide comprehensive assistance including installation guidance, troubleshooting, and maintenance tips to ensure optimal operation of your pneumatic cylinder.

We recommend regular inspection of the cylinder for any signs of wear or damage, and proper lubrication according to the manufacturer's specifications to extend the service life of the product. In case of any performance issues, please refer to the troubleshooting section of the user manual or our online resources for quick solutions.

Our technical support team is available to assist with product selection, customization options, and integration into your existing systems. We also offer repair services and replacement parts to minimize downtime and maintain productivity.

For detailed service procedures, warranty information, and to access user manuals and technical datasheets, please visit our website or consult the documentation provided with your product.
