Product Description:
Product Description
The IMI Norgren RA/802032/M Series represents a high-performance pneumatic cylinder that complies with ISO 15552 standards. As part of the acclaimed ISOLine product range, this double-acting cylinder features a 32mm bore diameter. It is offered with a wide variety of stroke lengths, ranging from 20mm up to 1000mm, making it a versatile solution for numerous industrial automation tasks requiring reliable and efficient linear motion.
Central to the design of this cylinder is the innovative Adaptive Cushioning System (ACS). This smart technology automatically modifies the cushioning effect based on varying load conditions, removing the need for manual adjustments or specialized expertise. This leads to smoother and safer operation, lowers maintenance expenses, and extends the overall service life of the cylinder.
Constructed with a sturdy round barrel and external tie rods, the RA/802032/M Series is built to endure demanding environments. It also comes equipped with a standard magnetic piston, which facilitates straightforward position sensing when paired with compatible reed or solid-state switches. The product adheres to ISO 15552, VDMA 24562, and NFE 49-003-1 standards, ensuring both interchangeability and global compliance.
Features:
Adaptive Cushioning System (ACS)
The Adaptive Cushioning System (ACS) automatically adjusts the cushioning based on varying loads. This feature eliminates the need for manual adjustments, ensuring smooth and safe operation across different working conditions.
ISO 15552 Compliance
This product complies with the ISO 15552 standard, as well as VDMA 24562 and NFE 49-003-1 standards. Such adherence guarantees global interchangeability and compatibility in various industrial environments.
Robust Construction
Featuring a round barrel design with external tie rods, the product offers exceptional durability. This construction is especially suited for aggressive and demanding environments, providing long-lasting reliability.
Magnetic Piston
The standard magnetic piston included allows for easy position sensing. It works seamlessly with reed switches or solid-state switches, facilitating precise control and monitoring.
Wide Operating Pressure Range
Designed to operate efficiently within a pressure range of 1 to 16 bar, this product meets the needs of a diverse array of applications, making it a versatile choice for many industries.
Versatile Stroke Selection
The product is available in a broad selection of stroke lengths, covering both standard and non-standard sizes. This flexibility ensures it can be tailored to specific operational requirements.
Low Maintenance
Equipped with polyurethane seals, the system achieves low-friction operation and prolonged service life. These features contribute to reduced maintenance efforts and overall operational efficiency.
Shock and Vibration Tested
It has been rigorously tested according to EN 61373 standards, Category 1, Class A + B, making it suitable for rail applications where shock and vibration resistance are critical.
Multiple Variants Available
Various options are available to customize the product, including different piston rod materials, special wipers, low friction seals, and extended piston rods. This wide range of variants ensures adaptability to specific customer needs.
Technical Parameters:
| Series |
RA/802000 - ISOLine |
| Type |
Standard Cylinder (Round Barrel) |
| Operation |
Double Acting |
| Brand |
IMI Norgren |
| Cylinder Bore |
32 Mm |
| Standard |
ISO 15552 |
Applications:
Industrial Automation
This sector encompasses general factory automation, including assembly lines and material handling equipment. These systems are designed to improve efficiency and precision in manufacturing processes.
Packaging Machinery
Packaging machinery involves operations such as product sorting, pushing, and positioning, which are critical for ensuring accuracy and speed in packaging workflows.
Automotive Industry
The automotive sector utilizes these technologies for component assembly, testing fixtures, and overall automation of production lines to enhance productivity and quality control.
Railway Applications
Railway-related equipment is rigorously tested for shock and vibration resistance in accordance with EN 61373 standards, specifically Category 1, Class A + B, ensuring durability in harsh environments.
Food & Beverage
This field benefits from systems compatible with filtered, lubricated, or non-lubricated compressed air, ensuring hygienic and efficient processing conditions.
Electronics Manufacturing
Precision positioning and handling of components are vital in electronics manufacturing, where compact and delicate parts require meticulous assembly processes.
Mechanical Engineering
In mechanical engineering, these technologies support general linear actuation within machine building and customized machinery designed for specific purposes.
Support and Services:
Our Piston Pneumatic Cylinder product is designed for high performance and durability in various industrial applications. For technical support, we provide comprehensive guidance on installation, operation, and maintenance to ensure optimal functionality and longevity of the cylinder.
If you encounter any issues with the Piston Pneumatic Cylinder, our technical support team can assist with troubleshooting, part replacement, and repair procedures. We recommend regular inspection and lubrication as part of the maintenance routine to prevent wear and extend the service life of the cylinder.
We also offer customized services including cylinder sizing, mounting options, and special material requirements to meet your specific application needs. Our experts are available to provide consultation and advice on system integration and performance optimization.
For detailed product manuals, CAD drawings, and technical datasheets, please refer to our online resources. We strive to provide prompt and effective support to ensure your operations run smoothly and efficiently with our Piston Pneumatic Cylinder.
