Product Description:
The IMI Norgren RA/802032/M Series represents a high-performance pneumatic cylinder that adheres to the ISO 15552 standard. Part of the esteemed ISOLine product range, this double-acting cylinder features a bore diameter of 32mm. It is offered in a wide variety of stroke lengths, ranging from 20mm up to 1000mm, making it an ideal choice for delivering dependable and efficient linear motion in numerous industrial automation settings.
Central to this cylinder’s functionality is the state-of-the-art Adaptive Cushioning System (ACS). This smart technology automatically fine-tunes the cushioning to adapt to varying loads, removing the necessity for manual adjustment of cushion screws or specialized expertise. By doing so, it ensures smoother and safer operation, lowers maintenance expenses, and significantly extends the operational lifespan of the cylinder.
Constructed with a durable round barrel design and reinforced with external tie rods, the RA/802032/M series is built to withstand harsher operating conditions. Additionally, the cylinder includes a magnetic piston as a standard feature, which simplifies position detection when used with compatible reed or solid-state sensors. Compliant with ISO 15552, VDMA 24562, and NFE 49-003-1 standards, this cylinder guarantees interchangeability and adherence to international requirements.
Features:
Adaptive Cushioning System (ACS)
The Adaptive Cushioning System automatically adjusts the cushioning based on varying loads. This eliminates the need for manual adjustments and guarantees smooth and safe operation under different conditions.
ISO 15552 Compliance
This product is designed in accordance with ISO 15552 standards, as well as VDMA 24562 and NFE 49-003-1. Such compliance ensures global interchangeability, making it suitable for international applications.
Robust Construction
Featuring a round barrel design with external tie rods, the construction provides enhanced durability, especially suited for aggressive and challenging environments.
Magnetic Piston
Equipped with a standard magnetic piston, this system supports easy and reliable position sensing through the use of reed or solid-state switches.
Wide Operating Pressure Range
The system operates efficiently within a wide pressure range from 1 to 16 bar, making it adaptable for a diverse array of applications.
Versatile Stroke Selection
A broad selection of both standard and non-standard stroke lengths is available to meet various operational requirements.
Low Maintenance
Utilizing polyurethane seals, the design ensures low friction during operation and extends the service life, thereby minimizing maintenance efforts.
Shock and Vibration Tested
This product has been tested according to EN 61373 Category 1, Class A + B standards, which are crucial for railway applications requiring resistance to shock and vibration.
Multiple Variants Available
Various options are offered, including different piston rod materials, special wipers, low friction seals, and extended piston rods, providing flexibility to suit specific needs.
Technical Parameters:
| Cylinder Bore |
32 Mm |
| Type |
Standard Cylinder |
| Brand |
IMI Norgren |
| Operation |
Double Acting |
| Port Size |
G1/8 |
| Standard |
ISO 15552 |
Applications:
Industrial Automation
This sector includes general factory automation processes, encompassing assembly lines as well as material handling equipment. These systems work together to streamline production and enhance efficiency across manufacturing plants.
Packaging Machinery
Packaging machinery is designed for tasks such as product sorting, pushing, and accurate positioning. These operations ensure that products are packaged efficiently and correctly, maintaining consistency and quality.
Automotive Industry
In the automotive sector, these technologies are employed for assembling various components, conducting testing with specialized fixtures, and automating entire production lines to boost productivity and reliability.
Railway Applications
Devices used in railway environments undergo rigorous shock and vibration testing according to EN 61373 standards, specifically meeting Category 1, Class A and B requirements to ensure durability and safety.
Food & Beverage
Equipment designed for the food and beverage industry is compatible with filtered, lubricated, or non-lubricated compressed air, making it suitable for hygiene-sensitive applications and diverse operational needs.
Electronics Manufacturing
Precision positioning and handling of components are critical in electronics production, where meticulous accuracy ensures the quality and functionality of final products.
Mechanical Engineering
Mechanical engineering applications benefit from general linear actuation technologies in machine building and the creation of specialized machinery tailored for unique industrial purposes.
Support and Services:
Product Technical Support and Services for the Piston Pneumatic Cylinder include comprehensive assistance to ensure optimal performance and longevity of the product. Our support team provides detailed guidance on installation, operation, and maintenance to help you achieve efficient pneumatic system integration.
We offer troubleshooting services to quickly identify and resolve any issues that may arise during the cylinder's operation. Technical documentation, including datasheets, user manuals, and CAD models, are available to support your engineering and maintenance needs.
Our services also include customization options to tailor the piston pneumatic cylinder to your specific application requirements, ensuring maximum efficiency and effectiveness. Regular maintenance advice and replacement part information are provided to minimize downtime and extend the lifecycle of your equipment.
For any technical inquiries or service requests, our experienced support team is prepared to assist you with expert solutions and recommendations, helping you maintain peak performance of your pneumatic systems.
Packing and Shipping:
Product Packaging:
The Piston Pneumatic Cylinder is carefully packaged to ensure safe delivery and protection against damage during transit. Each cylinder is wrapped in anti-static foam and placed inside a sturdy cardboard box. The box is then sealed securely with industrial-grade tape. For added protection, bubble wrap or foam inserts are used to prevent movement within the box. Product specifications and handling instructions are included inside the package.
Shipping:
We offer reliable shipping options for the Piston Pneumatic Cylinder, including standard and expedited delivery services. Each package is labeled with a tracking number, allowing customers to monitor their shipment in real-time. Our logistics partners ensure timely delivery and provide careful handling throughout the shipping process. International shipping is also available, subject to applicable customs regulations and fees.
