Product Description:
The IMI Norgren RA/802032/M Series represents a high-performance line of double-acting pneumatic cylinders that comply with the ISO 15552 standard. Part of the well-regarded ISOLine series, these cylinders feature a bore diameter of 32mm and are available in a wide range of stroke lengths, spanning from 20mm up to 1000mm. This versatility makes them an ideal choice for providing reliable and efficient linear motion in various industrial automation settings.
Central to the design of this cylinder is the cutting-edge Adaptive Cushioning System (ACS). This smart system dynamically adjusts the cushioning effect to suit different load conditions, removing the requirement for manual adjustments of cushion screws or specialized expertise. The benefits include smoother and safer cylinder operation, decreased maintenance expenses, and a longer overall service life.
Constructed with a sturdy round barrel and external tie rods, the RA/802032/M series delivers exceptional durability, making it well-suited for use in more demanding environments. Additionally, the cylinder is equipped with a magnetic piston as standard, facilitating straightforward position sensing through compatible reed or solid-state switches. Designed in accordance with ISO 15552, VDMA 24562, and NFE 49-003-1 standards, this series ensures global compliance and interchangeability.
Features:
Adaptive Cushioning System (ACS)
The Adaptive Cushioning System (ACS) automatically adjusts the cushioning to accommodate varying loads. This eliminates the need for manual adjustments and guarantees smooth and safe operation under different conditions.
ISO 15552 Compliance
This product adheres to the ISO 15552 standard along with VDMA 24562 and NFE 49-003-1, ensuring global interchangeability and compatibility across international markets.
Robust Construction
Featuring a round barrel design reinforced with external tie rods, the construction delivers exceptional durability, making it suitable for demanding and aggressive environments.
Magnetic Piston
The inclusion of a standard magnetic piston facilitates easy position sensing using reed or solid-state switches, enhancing operational efficiency.
Wide Operating Pressure Range
Capable of functioning within a broad pressure range from 1 to 16 bar, this system is adaptable to a variety of applications requiring different pressure levels.
Versatile Stroke Selection
Available in numerous standard and non-standard stroke lengths, it provides flexibility to meet specific operational requirements.
Low Maintenance
Equipped with polyurethane seals, the system ensures low-friction movement and prolonged service life, resulting in reduced maintenance needs.
Shock and Vibration Tested
The product has been rigorously tested to meet EN 61373 Category 1, Class A + B standards, confirming its reliability and performance for rail applications.
Multiple Variants Available
It supports a range of options including different piston rod materials, special wipers, low friction seals, and extended piston rods, allowing customization to specific application demands.
Technical Parameters:
| Operation |
Double Acting |
| Port Size |
G1/8 |
| Type |
Standard Cylinder |
| Cylinder Bore |
32 Mm |
| Standard |
ISO 15552 |
| Brand |
IMI Norgren |
Applications:
Industrial Automation
This sector encompasses general factory automation processes, including the operation of assembly lines and the handling of materials through specialized equipment. The focus is on enhancing production efficiency and accuracy.
Packaging Machinery
In packaging machinery, tasks such as product sorting, pushing, and precise positioning are critical. These operations ensure products are correctly arranged and prepared for shipment or further processing.
Automotive Industry
The automotive sector utilizes component assembly lines, testing fixtures, and automation systems to streamline manufacturing processes. These technologies contribute to higher quality and faster production times.
Railway Applications
Equipment designed for railway applications undergoes rigorous shock and vibration testing according to the EN 61373 standard, specifically Category 1, Classes A and B, to ensure durability and reliability under demanding conditions.
Food & Beverage
Components used in the food and beverage industry are compatible with compressed air systems that may be filtered, lubricated, or non-lubricated, ensuring hygienic and efficient operation within production environments.
Electronics Manufacturing
Precision is essential in electronics manufacturing, where equipment is used for accurate positioning and careful handling of delicate components to maintain product integrity and functionality.
Mechanical Engineering
In mechanical engineering, general linear actuation plays a vital role in machine construction and the development of specialized machinery, providing reliable movement and control across various applications.
