G435AG1N20A00 G435AHSN20A00 ASCO Solenoid Valve Double Acting Single Rod ISO 6432 International Standard Designed for and Precise Operation

Product Description:

Cylinder Tube: Constructed from stainless steel seamless tubing, featuring a mirror-polished surface that resists rust and dust intrusion.

Piston Rod: Made of high carbon steel, enhanced with hard chrome plating to improve wear resistance.

End Caps: Manufactured using hard anodized aluminum alloy for durability.

Piston: Crafted from high-strength engineering plastic and equipped with a wear-resistant sliding ring to ensure longevity.

Sealing Parts: Utilize NBR (nitrile rubber) composite seals combined with PU dust wipers designed specifically to protect against cement dust.

Guide Bushing: Composed of self-lubricating copper alloy, providing low friction operation.

• Working Medium: Filtered compressed air, compatible with both lubricated and non-lubricated types.
• Working Pressure Range: 0.5 to 10 bar (0.05 to 1.0 MPa).
• Maximum Allowable Pressure: 10 bar.
• Operating Temperature: From -10°C up to +60°C.
• Piston Speed: Between 50 and 800 millimeters per second.
• Cushion: Equipped with fixed rubber buffers located at both ends.
• Magnetic Switch: Features a built-in magnetic ring compatible with ASCO proximity sensors.
• Port Thread: G1/8".
• Mounting Type: Options include front nose mount, rear clevis mount, and bracket mount.

The cylinder body is made entirely of stainless steel, providing outstanding resistance to dust, especially in cement powder environments. It integrates a thickened dust wiper that effectively prevents cement ash from entering, significantly extending the product's service life.

The self-lubricating guide sleeve ensures smooth, low-friction reciprocating movement and lowers the failure rate. With standard ISO6432 installation dimensions, this product is fully interchangeable on a one-to-one basis with original ASCO NNS cylinders.

Thanks to its compact and small size, it is ideal for installation in tight spaces commonly found in dust removal equipment. Additionally, its stable sealing guarantees no air leakage even during long-term, frequent reciprocating operations.

This cylinder is suitable for a range of industries, including:

• Cement plants
• Aggregate plants
• Dust removal systems
• Packaging machinery
• Metallurgy auxiliary equipment
• Mining small valve actuators

Technical Parameters:

Applications:

The ASCO Solenoid Valve, specifically designed for the ISO6432 Mini Round Pneumatic Cylinder from the NNS Series, is an essential component in various industrial and automation applications. Renowned for its superior quality and adherence to the ISO 6432 International Standard, this dust-proof air cylinder is ideal for environments where cleanliness and reliability are paramount. ASCO Numatics air cylinders are widely used in manufacturing plants, assembly lines, packaging machinery, and robotic systems, where precise control of pneumatic motion is required.

One of the primary application occasions for the ASCO tie rod cylinder is in automated production lines that demand consistent double acting single rod action. Its compact design and robust construction make it suitable for use in confined spaces without compromising performance. Industries such as automotive, electronics,and food processing rely heavily on ASCO Numatics air cylinders to ensure smooth, efficient, and contamination-free operations.

In scenarios where dust and particulate matter are present, the dust-proof air cylinder feature of the ASCO solenoid valve plays a critical role in maintaining the integrity and longevity of the pneumatic system. This makes it particularly useful in dusty factory floors, woodworking shops, and material handling systems where airborne particles might otherwise impair valve function. The ASCO brand, with CE certification, guarantees that these products meet rigorous safety and quality standards, providing peace of mind to users.

With a supply ability of 5000 pieces per month and a minimum order quantity of just one unit, customers benefit from flexible purchasing options. Pricing is negotiable to accommodate various project scales and budgets. The ASCO Solenoid Valve and its associated ISO6432 Mini Round Pneumatic Cylinder are packaged carefully in cartons or as per clients’ specific requirements, ensuring safe delivery within 1-7 work days after payment. Payment terms such as T/T, Western Union, and Paypal further facilitate convenient and secure transactions.

Overall, the versatility and reliability of the ASCO Numatics air cylinder, combined with the precision control offered by the ASCO tie rod cylinder, make this product an excellent choice for a wide range of pneumatic applications. Whether used in cleanroom environments or dusty industrial settings, these cylinders deliver consistent performance, contributing to enhanced operational efficiency and reduced downtime.

Packing and Shipping:

The ASCO Solenoid Valve is carefully packaged to ensure safe delivery and optimal protection during transit. Each valve is individually wrapped with protective materials and placed in a sturdy, custom-designed box that prevents movement and damage.

Packaging includes anti-static bags for electronic components and cushioning materials such as foam inserts or bubble wrap to absorb shocks. The outer carton is clearly labeled with product information, handling instructions, and shipping details to facilitate easy identification and careful handling.

For shipping, ASCO Solenoid Valves are dispatched using reliable carriers that offer tracking and insurance options. We ensure timely delivery by selecting shipping methods based on customer requirements and destination to maintain product integrity and customer satisfaction.
