Product Description:
Component Materials and Construction
The cylinder tube is made from stainless steel seamless tubing, featuring mirror polishing to provide excellent resistance against rust and dust contamination. The piston rod is crafted from high carbon steel and enhanced with hard chrome plating, ensuring superior wear resistance.
End caps are manufactured using hard anodized aluminum alloy, providing strength and durability. The piston itself is composed of high-strength engineering plastic, equipped with a wear-resistant sliding ring to enhance performance and longevity. Sealing parts utilize a composite seal made of NBR nitrile rubber paired with a PU dust wiper, specifically designed to prevent dust ingress in cement workshop environments.
The guide bushing consists of a self-lubricating copper alloy bushing that offers low friction, facilitating smooth and efficient reciprocating motion.
Core Technical Parameters
- Working Medium: Filtered compressed air (both lubricated and non-lubricated options available)
- Working Pressure Range: 0.5 to 10 bar (0.05 to 1.0 MPa)
- Maximum Allowable Pressure: 10 bar
- Operating Temperature: From -10℃ to +60℃
- Piston Speed: 50 to 800 mm/s
- Cushion: Fixed rubber buffers located at both ends
- Magnetic Switch: Built-in magnetic ring compatible with ASCO proximity sensors
- Port Thread: G1/8"
- Mounting Types: Front nose mount, rear clevis mount, or optional bracket mount
Product Features
This cylinder features a full stainless steel body, providing exceptional dust resistance suitable for environments with cement powder. It includes an integrated thickened dust wiper that effectively prevents cement ash from entering, thereby extending the cylinder's service life.
The self-lubricating guide sleeve ensures smooth reciprocating movement while maintaining a low failure rate. It adheres to the standard ISO6432 installation dimensions, allowing a 1:1 interchangeability with the original ASCO NNS cylinder.
Designed with a compact and small form factor, it is ideal for limited installation spaces, especially within dust removal equipment. The sealing system provides stable sealing performance with no air leakage even during long-term, frequent reciprocation operations.
Application Industries
This cylinder is widely used across various industries including cement plants, aggregate plants, dust removal systems, packaging machinery, metallurgy auxiliary equipment, and mining small valve actuators.
Technical Parameters:
| Product Name |
ISO6432 Mini Round Pneumatic Cylinder |
| Brand |
ASCO Numatics |
| Series |
NNS Series |
| Action Type |
Double Acting Single Rod |
| Operating Temperature |
-10℃ ~ +60℃ |
| Standard |
ISO 6432 International Standard |
Applications:
The ASCO ISO6432 Mini Round Pneumatic Cylinder, part of the renowned NNS Series by ASCO Numatics, is an essential component in various industrial automation applications. As an industrial pneumatic actuator cylinder, it is designed to provide reliable and efficient motion control in environments that demand precision and durability. Certified with CE standards, the ASCO tie rod cylinder guarantees high quality and compliance with international safety and performance regulations.
This pneumatic cylinder adheres to the ISO 6432 international standard, ensuring compatibility and interchangeability with other pneumatic components worldwide. Its double acting single rod design offers versatile operation, making it suitable for both pushing and pulling actions in automated systems. The compact size and robust construction of the ASCO tie rod cylinder make it ideal for installation in confined spaces without compromising performance.
Application occasions for the ASCO ISO6432 Mini Round Pneumatic Cylinder span a wide range of industrial sectors. It is extensively used in manufacturing assembly lines, packaging machinery, and material handling systems where precise and repeatable linear motion is critical. Its role as an industrial pneumatic actuator cylinder is especially valuable in robotics, automation equipment, and conveyor systems, where it delivers smooth and controlled actuation to enhance productivity and operational efficiency.
The flexibility of the ASCO pneumatic cylinder also makes it suitable for use in automotive manufacturing, food processing, and pharmaceutical industries. Its CE certification ensures that it meets stringent hygiene and safety standards required in these fields, allowing it to perform reliably under various environmental conditions.
Customers benefit from a minimum order quantity of just one unit, allowing for easy procurement and testing before large-scale adoption. Pricing is negotiable to accommodate different project needs, and packaging is tailored to client requirements, typically shipped in durable cartons to ensure safe delivery. With a supply ability of 5000 pieces per month and a delivery time of 1-7 workdays after payment, ASCO provides a responsive and dependable supply chain.
Payment terms are flexible, accepting T/T, Western Union, and PayPal, facilitating smooth transactions globally. Overall, the ASCO ISO6432 Mini Round Pneumatic Cylinder is an excellent choice for engineers and procurement specialists seeking a high-quality, standard-compliant, and reliable pneumatic cylinder for diverse industrial automation scenarios.
Packing and Shipping:
The ASCO Solenoid Valve is carefully packaged to ensure safe delivery and optimal protection during transit. Each valve is individually wrapped with protective materials and placed in a sturdy, custom-designed box to prevent damage from shocks, vibrations, and moisture.
For shipping, the packaged valves are securely packed in outer cartons with appropriate cushioning materials. The cartons are clearly labeled with product information, handling instructions, and shipping details to facilitate smooth logistics.
We partner with reliable carriers to provide timely and secure delivery, ensuring that your ASCO Solenoid Valve arrives in perfect working condition and ready for installation.
