Product Description:
The FESTO D-series MAXI oil mist filter features an integrated die-cast zinc alloy housing, making it a robust component for heavy-duty metal air source purification. This durable construction ensures long-lasting performance in demanding industrial environments.
Equipped with multi-precision replaceable filter cartridges, the filter effectively removes dust, condensate, oil mist, and microscopic aerosols from compressed air. This advanced filtration capability helps maintain high air quality and protects downstream equipment from contamination.
The MAXI series offers large flow sizes and is available with standard thread options including G1/2, G3/4, and G1. It fully complies with the ISO 8573-1 air purity standards and supports both manual and automatic condensate drainage, providing flexible operation to suit various applications.
These filters are widely compatible with FESTO FRL combination units and are ideal for use in centralized factory compressed air pipeline systems, ensuring efficient and reliable air source purification across industrial facilities.
Features:
The MAXI model features a substantial airflow capacity, delivering up to 5300 liters per minute at 6 bar. It is equipped with a generously sized 80ml condensate storage bowl, which is protected by a sturdy metal cover for enhanced durability and safety.
Users can choose between two convenient drain options: a manual rotary drain and a fully automatic drain, the latter being ideal for unattended production environments where continuous operation is essential.
This product supports a broad range of operating conditions, accommodating pressures from 1 to 16 bar and temperatures ranging from -10℃ to 60℃. Additionally, it allows for installation with a vertical tilt of up to ±5°, offering flexibility in setup.
The filter insert is independently replaceable, which helps minimize long-term maintenance costs by simplifying upkeep and part replacement.
Technical Parameters:
| Design |
Proportional Standard Mist Lubricator |
| Mounting position |
Vertical ±5° |
| Temperature |
-10 °C ... 60 °C |
| Series |
D |
| Size |
Maxi |
| Operating pressure |
0 MPa ... 1.6 MPa |
Applications:
In the automotive manufacturing industry, advanced welding lines and painting workshops utilize robotic pneumatic systems to effectively prevent defects such as paint bubbling. These technologies ensure a higher quality finish and improved production efficiency.
The CNC and machinery sector incorporates machining centers, stamping presses, and injection molding machines designed to safeguard precision components like valves and cylinders. This careful protection maintains the accuracy and performance of critical parts.
Within the electronics and semiconductor fields, equipment for PCB and chip packaging operates in ultra-clean environments. This cleanliness is crucial for preventing circuit short circuits and ensuring the reliability of electronic devices.
For the printing and packaging industry, high-speed printers alongside film blowing machines work together to deliver consistent and stable printing quality. These machines help maintain product standards during high-volume production.
Support and Services:
Our Pneumatic Filter Regulator Lubricator (FRL) units are designed to ensure optimal performance and longevity of your pneumatic systems by providing clean, regulated, and lubricated air supply. To maintain peak functionality, regular inspection and maintenance are recommended.
For technical support, ensure the FRL is installed according to the manufacturer's guidelines, with appropriate pressure settings and compatible lubricants. Check for any air leaks, blockages, or contamination in the filter element, and replace filter cartridges as needed.
Lubricator adjustment should be calibrated to deliver the correct amount of lubricant to pneumatic tools, preventing excessive or insufficient lubrication. Use only manufacturer-recommended lubricants to avoid damage or reduced efficiency.
If you experience issues such as pressure fluctuations, air contamination, or lubrication failure, consult the troubleshooting section of the user manual for step-by-step guidance. Regular maintenance intervals and proper usage will extend the service life of the FRL unit.
For advanced technical support, product upgrades, or service inquiries, please refer to the detailed documentation provided with the product or visit the official product website for the latest resources and updates.
Packing and Shipping:
Product Packaging:
The Pneumatic Filter Regulator Lubricator is securely packaged in a sturdy, durable box to prevent any damage during transit. Each unit is individually wrapped with protective foam and sealed to ensure cleanliness and integrity. The packaging includes clear labeling with product specifications, model number, and handling instructions for easy identification and safe handling.
Shipping:
We offer reliable shipping options to ensure timely delivery of the Pneumatic Filter Regulator Lubricator. Products are shipped via trusted carriers with tracking available for all orders. Shipping methods include standard ground, expedited, and international shipping, depending on customer requirements. All shipments are carefully inspected before dispatch to guarantee quality and customer satisfaction.
