Product Description:
The Product Series 1913BA is a 2/2-way normally closed solenoid valve, specifically designed for direct-acting operation and manifold mounting within fluid control systems. Its construction allows for seamless integration, providing dependable ON/OFF control suitable for a variety of neutral fluids including air, water, steam, and oil.
Crafted primarily from stainless steel, this solenoid valve ensures exceptional durability and resistance to corrosion, making it well-suited for demanding industrial environments. Additionally, options for brass and aluminum alloy bodies are available. The direct-acting mechanism guarantees consistent performance starting from zero differential pressure, which makes the valve particularly effective in low-pressure and compact system configurations.
The valve offers flexibility in sealing materials, with choices such as NBR, EPDM, and FKM to accommodate a broad range of media compatibility. It is capable of operating within a wide temperature spectrum, ranging from -30°C up to +150°C, thereby meeting diverse application needs.
Regarding specifications, the 1913BA series is available with port sizes of 1/8″ and 1/4″, and orifice sizes spanning from 1.6mm to 3.0mm. This range allows for precise flow control, achieving Cv values up to 0.30. Manufactured in Ningbo, China, and holding CE certification, this solenoid valve manifold is recognized for its quality and reliability across various industrial sectors.
Features:
The direct acting operation features a spring-return mechanism that enables functionality starting from zero pressure differential (0 MPa). This design guarantees consistent and reliable performance throughout the entire pressure range.
With its 2/2 way normally closed function, the spring-return mechanism ensures that the valve remains closed when not energized. This provides a fail-safe operation, enhancing safety and system reliability.
Constructed with a stainless steel body, the valve offers excellent corrosion resistance and robust structural integrity. This makes it ideal for long-term use in demanding environments. Additionally, brass and aluminum alloy options are available to suit different application needs.
Users can select from multiple seal materials including NBR (suitable for -10 to +80°C), EPDM (-30 to +120°C), or FKM (-30 to +150°C), allowing optimal compatibility with various media and temperature ranges.
Its compact manifold design, featuring 1/8″ and 1/4″ port sizes, facilitates space-saving integration in multi-station setups, enhancing installation flexibility.
The valve supports a wide operating pressure range of up to 1.6 MPa (16 Bar) for both AC and DC models, accommodating diverse system requirements with ease.
Available in multiple orifice sizes of 1.6mm, 2.5mm, and 3.0mm, the valve allows precise flow control, with Cv values ranging from 0.11 to 0.30 to suit specific application demands.
It supports a broad selection of voltage options including 12VDC, 24VDC, 24VAC, 110VAC, and 220VAC (50/60Hz), making it compatible with a variety of control systems.
The valve is CE certified, ensuring compliance with international safety and quality standards.
Backed by a high production capacity of 200,000 units per month and 40,000 units per week, the manufacturer is well-equipped to reliably fulfill bulk orders.
Technical Parameters:
| Diaphragm Material |
NBR, EPDM, FKM |
| Port Size |
1/8'', 1/4'' |
| Function |
2 Way Normally Closed |
| Media Compatibility |
Air, Water, Steam, Oil |
| Working Pressure |
0–16 Bar |
| Standard Voltages |
12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Orifice Size |
1.6mm, 2.5mm, 3.0mm |
| Operation |
Direct Acting |
Applications:
Industrial Automation
In the field of industrial automation, multi-station fluid control plays a crucial role, especially within pneumatic and hydraulic systems. These systems rely on precise management of fluids to ensure efficient and reliable operation across various manufacturing processes.
Water Treatment
Water distribution and treatment processes utilize ON/OFF control mechanisms to regulate the flow and processing stages effectively. This approach ensures that water is treated and delivered accurately to meet environmental and safety standards.
Compressed Air Systems
The regulation of air flow is essential in compressed air systems, particularly for powering pneumatic tools and automated production lines. Effective control contributes to optimal performance and energy efficiency in these applications.
Steam Systems
Steam control systems are commonly implemented in small-scale heating and sterilization equipment. Accurate management of steam flow is vital for maintaining the desired temperature and ensuring sterilization quality.
Oil Systems
Light oil control is fundamental in industrial lubrication and fuel systems. Proper regulation prevents equipment wear and enhances fuel efficiency by maintaining consistent fluid distribution.
HVAC Systems
Heating, ventilation, and air conditioning (HVAC) systems depend on precise heating and cooling fluid control to maintain comfortable indoor environments. These controls help optimize energy use and system performance in building services.
Packaging Machinery
Automated packaging equipment requires exact fluid control to ensure the accuracy and reliability of packaging operations. This precision is crucial for products’ quality and consistency during mass production.
Medical Equipment
In medical devices, sterile fluid and gas control is essential for diagnostic and treatment applications. This ensures patient safety and the effectiveness of medical procedures by preventing contamination.
Laboratory Instruments
Precision in fluid handling is indispensable in laboratory instruments used for analytical and testing purposes. Accurate fluid control enhances the reliability and reproducibility of experimental results.
Manifold Assemblies
Manifold assemblies integrate multiple valves into a centralized block, enabling streamlined fluid control across various channels. This integration simplifies complex fluid management tasks and improves system efficiency.
Customization:
The DKE 1913BA-5-S pneumatic solenoid valve offers exceptional product customization services to meet diverse industrial needs. As a pilot diaphragm solenoid valve, it features a direct acting operation mechanism and is compatible with various media including air, water, steam, and oil, making it ideal as an air valve or light oil valve.
Customers can choose from multiple diaphragm materials such as NBR, EPDM, and FKM to ensure optimal performance under different environmental conditions. The valve supports standard voltages including 12VDC, 24VDC, 24VAC, 110VAC, and 220VAC, allowing flexible integration into existing systems.
Available port sizes of 1/8'' and 1/4'' provide adaptability for various piping configurations. The product is CE certified and manufactured in China under the trusted DKE brand. We accommodate minimum order quantities starting from 1 piece, with pricing available upon negotiation to suit your budget.
Packaging is securely handled in cartons to prevent damage during transit. Delivery is prompt, typically within 1 to 7 working days after payment confirmation. Payment terms are flexible, accepting T/T, Western Union, and PayPal.
With a supply capacity of 5000 pieces per month, DKE ensures reliable availability of this pilot diaphragm solenoid valve to support your production demands and specialized applications in air valve and light oil valve roles.
Packing and Shipping:
Product Packaging and Shipping
The Pneumatic Solenoid Valve is carefully packaged to ensure safe delivery and optimal protection during transit. Each valve is individually wrapped in anti-static foam and placed inside a sturdy cardboard box to prevent damage from impacts and vibrations.
Multiple units are securely packed into larger cartons with adequate cushioning materials to avoid movement. The packaging is clearly labeled with product details, handling instructions, and shipping information.
We offer various shipping options including standard, expedited, and freight services to meet customer requirements. All shipments are tracked and insured to guarantee on-time and intact delivery.
For international orders, we comply with all customs regulations and provide necessary documentation to facilitate smooth clearance.
Your Pneumatic Solenoid Valve will arrive safely and ready to perform reliably in your applications.
