Product Description:
The H4S Series represents a 2/2-way normally closed direct-acting solenoid valve, specifically designed for ultra-high pressure fluid control tasks reaching up to 700 bar (10,000 PSI). It is engineered to provide reliable ON/OFF switching capabilities for various media including air, water, gas, and other neutral fluids.
This valve excels in delivering outstanding performance even in the most demanding high-pressure environments. Its direct-acting mechanism guarantees dependable operation starting from zero differential pressure, making it particularly suitable for applications that require precise control across the entire pressure range.
Constructed with a robust Stainless Steel 316 body, the H4S Series valve incorporates advanced sealing materials such as PEEK and PCTFE. These features ensure exceptional durability, resistance to corrosion, and leak-tight performance under extreme pressure conditions.
Available with port sizes of 1/8″ and 1/4″ and equipped with a 0.5mm orifice, this valve allows for accurate flow control highlighted by a Cv value of 0.02. Manufactured in Ningbo, China, the H4S Series is recognized worldwide for its high quality and reliability in ultra-high pressure systems.
Features:
The valve boasts an ultra-high pressure capability, with a maximum working pressure reaching up to 700 bar (10,000 PSI). This makes it ideal for use in demanding high-pressure applications where reliability and durability are critical.
Featuring a direct acting operation, the valve utilizes a spring-return mechanism that enables functionality even at zero differential pressure (0 bar). This design ensures consistent and dependable performance throughout the entire pressure range.
Its 2/2 way normally closed function is maintained by the spring-return system, which keeps the valve securely closed when de-energized. This fail-safe operation enhances safety and prevents unintended fluid flow.
Constructed from premium stainless steel 316, the valve body delivers exceptional corrosion resistance and structural strength. This robust material choice supports long-term service in harsh and corrosive environments.
The incorporation of advanced seal materials such as PEEK and PCTFE ensures superior leak-tightness and excellent chemical resistance. These seals perform reliably under extreme pressure and temperature conditions.
With a precise flow control capability, the valve features a 0.5mm orifice size and a Cv value of 0.02, enabling accurate and repeatable regulation of fluid flow.
Designed with compactness in mind, the valve is available in 1/8″ and 1/4″ port sizes, making it suitable for installations where space is limited.
The valve supports a wide range of voltage options, including 12VDC, 24VDC, 24VAC, 110VAC, and 220VAC (50/60Hz), allowing compatibility with various control systems.
Backed by a high production capacity of 500,000 units annually and 20,000 units monthly, the manufacturer ensures a reliable supply to meet bulk order demands.
Technical Parameters:
| Function |
2 Way Normally Closed |
| Operation |
Direct Operated |
| Body Material |
Stainless Steel 316 |
| Working Pressure |
700 Bar |
| Port Size |
1/8'', 1/4'' |
| Working Media |
Air, Water, Gas, Liquid, Etc |
| Seal Material |
PEEK, PTCFE |
| Orifice Size |
0.5mm |
Applications:
Hydraulic Systems
These systems involve ultra-high pressure hydraulic control used extensively in industrial machinery and equipment. They ensure precise and reliable performance in demanding environments.
Pneumatic Systems
High-pressure air and gas control are critical in pneumatic systems, especially within automation and processing lines. This technology enhances efficiency and accuracy in various manufacturing processes.
Water Jet Cutting
Water jet cutting utilizes ON/OFF control of ultra-high pressure water, which is essential for cutting and cleaning applications. This method offers a clean and precise alternative to conventional cutting techniques.
Oil & Gas Industry
The oil and gas sector relies on high-pressure fluid and gas control for the extraction, processing, and distribution of resources. Robust control systems are vital to maintaining safety and operational integrity.
Chemical Processing
Chemical plants require effective management of corrosive and high-pressure fluids. Specialized fluid control systems help ensure safe and efficient chemical processing operations.
Test & Measurement
Pressure testing rigs and calibration equipment are fundamental in test and measurement applications. These devices support the accuracy and reliability of pressure-sensitive instruments.
Research Laboratories
In research laboratories, precision fluid control is necessary for high-pressure experimental setups. This allows scientists to conduct experiments under controlled and repeatable conditions.
Medical Equipment
Medical devices often involve high-pressure gas and liquid control mechanisms. These are crucial for diagnostic and treatment equipment to function safely and effectively.
Support and Services:
Our Pneumatic Solenoid Valve product is designed to deliver reliable and efficient control of air flow in various industrial applications. To ensure optimal performance, we provide comprehensive technical support and services.
Technical support includes assistance with installation, operation, troubleshooting, and maintenance of the solenoid valve. Our experts are available to guide you through system integration, help optimize valve settings, and resolve any technical issues that may arise.
We also offer detailed product documentation, including user manuals, wiring diagrams, and specification sheets to facilitate proper use and maintenance of the valve.
In addition, we provide repair and replacement services to minimize downtime. Our team can help diagnose problems and recommend the best solutions to maintain your system’s efficiency.
For customized solutions, we offer consulting services to tailor pneumatic solenoid valve configurations that meet your specific application requirements.
Regular maintenance programs are available to ensure long-term reliability and performance of your pneumatic solenoid valves.
Our commitment is to support you throughout the product lifecycle, ensuring that your pneumatic control systems operate smoothly and effectively.
Packing and Shipping:
Product Packaging: Each Pneumatic Solenoid Valve is carefully packed in a protective plastic bag to prevent moisture and dust ingress. The valve is then placed in a custom-fitted foam insert to avoid movement and damage during transit. Multiple units are packed in a sturdy corrugated cardboard box with clear labeling including product model, specifications, quantity, and handling instructions.
Shipping: Our Pneumatic Solenoid Valves are shipped via reliable courier services ensuring timely delivery. We offer various shipping options including standard, expedited, and freight shipping depending on order size and customer requirements. All shipments include tracking information and are securely packaged to withstand handling and transport conditions. Special care is taken for international shipments to comply with customs regulations and to ensure safe arrival at the destination.
