Product Description:
The SH Series is a 2/2-way normally closed high-pressure solenoid valve designed to provide dependable ON/OFF control for air, water, gas, liquids, and other neutral media. It is capable of handling pressures up to 300 bar (4,300 PSI), making it suitable for demanding industrial applications.
This versatile valve series offers two types of operation to meet varying flow requirements. For orifice sizes ranging from DN1 to DN5, the valve employs direct acting operation, which functions effectively from zero differential pressure. For larger orifice sizes from DN10 to DN25, it uses piston pilot operated operation, requiring a minimum differential pressure to ensure reliable switching performance.
Constructed with a robust Stainless Steel 304 body and equipped with PTFE sealing material, the SH Series valve is built for exceptional durability and corrosion resistance. These features enable it to maintain leak-tight performance even under extreme pressure conditions, ensuring long-lasting reliability.
With port sizes available from 1/4″ to 1″ and orifice sizes stretching from 1mm up to 25mm, the SH Series delivers flexible flow control options. The valve offers Cv values ranging between 0.04 and 11.0, making it adaptable to a wide range of system requirements.
Manufactured in Ningbo, China, the SH Series boasts a strong production capacity of 20,000 units per week. Its proven quality and reliability have made it a trusted choice in high-pressure systems worldwide.
Features:
The valve boasts a high-pressure capability, capable of handling maximum working pressures up to 300 bar (4,300 PSI). This makes it well-suited for demanding applications that require robust performance under high-pressure conditions.
It features dual operation modes to accommodate different orifice sizes. For small orifices ranging from DN1 to DN5, it operates in a direct acting mode starting from zero differential pressure. For larger orifices, from DN10 to DN25, it utilizes a piston pilot-operated mechanism to ensure efficient and reliable functioning.
Designed as a 2/2 way normally closed valve, it integrates a spring-return mechanism that keeps the valve closed when de-energized. This design provides fail-safe operation, enhancing system safety and reliability.
The valve body is constructed from stainless steel 304, a premium material that ensures exceptional corrosion resistance and structural strength. This makes it ideal for long-term use in harsh or corrosive environments without compromising durability.
Equipped with PTFE seal materials, the valve benefits from high-performance seals that deliver excellent leak-tightness. These seals also provide superior chemical resistance and thermal stability, contributing to the valve’s overall reliability.
Offering a wide range of orifice sizes from 1mm to 25mm, the valve supports Cv values between 0.04 and 11.0. This allows for precise flow control suitable for a diverse range of applications.
In addition, it comes in multiple port size options including 1/4″, 3/8″, 1/2″, 3/4″, and 1″, enabling flexible integration into various system configurations.
The valve supports multiple voltage options such as 12VDC, 24VDC, 24VAC, 110VAC, and 220VAC (50/60Hz), making it compatible with a variety of control systems across different regions and industries.
Backed by a high production capacity, the manufacturer can supply up to 20,000 pieces per week and 100,000 pieces per month, ensuring a reliable and steady availability for bulk orders.
Technical Parameters:
| Function |
2 Way Normally Closed |
| Body Material |
Stainless Steel 304 |
| Working Pressure |
0 To 300 Bar |
| Voltage |
12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Orifice Size |
1mm |
| Seal Material |
PTFE |
| Port Size |
1/4'' |
| Operation |
Direct Acting |
Applications:
Hydraulic Systems
Hydraulic systems play a crucial role in industrial machinery and equipment by enabling high-pressure hydraulic control. These systems ensure efficient and precise operation in various heavy-duty applications.
Pneumatic Systems
Pneumatic systems utilize high-pressure air and gas to manage control processes in automation and processing lines. They are widely used to enhance the performance and reliability of industrial automation.
Water Jet Cutting
Water jet cutting involves the ON/OFF control of high-pressure water, which is employed for cutting and cleaning purposes. This technology is known for its precision and environmental friendliness.
Oil & Gas Industry
In the oil and gas sector, controlling high-pressure fluids and gases is essential during extraction, processing, and distribution phases. Effective control systems contribute to safety and operational efficiency.
Chemical Processing
Chemical plants require specialized equipment to manage corrosive and high-pressure fluids. Proper fluid control is vital to maintain safety and prevent equipment degradation in these demanding environments.
Test & Measurement
High-pressure control is also critical in pressure testing rigs and calibration equipment. These applications demand accuracy and reliability to ensure proper system performance.
Industrial Equipment
Many types of industrial manufacturing and processing machinery depend on high-pressure fluid control. This capability allows for consistent operation and improved product quality.
Research Laboratories
In research settings, precision fluid control under high-pressure conditions is essential for conducting experimental setups. This precision supports innovation and scientific discovery.
