Product Description:
These compact guide cylinder seal kits are precision-engineered replacement sets specifically designed for the maintenance and overhaul of MGP series guided pneumatic cylinders. They are available for bore sizes ranging from 12mm up to 100mm. Each kit includes all the essential sealing components necessary for a complete cylinder rebuild, such as the piston seal, rod seal, gasket A, and gasket B.
The seals are made from high-quality materials, including NBR (nitrile rubber) and urethane, which provide excellent resistance to wear, oil, and abrasion. This ensures reliable performance in various pneumatic applications. The MGP series compact guide cylinders themselves feature a slim and compact body with integrated guide rods, delivering high non-rotating precision and strong lateral load resistance. These characteristics make them particularly suitable for applications involving precision assembly, pick and place operations, and material handling.
By regularly replacing the seals using these kits, users can restore the cylinders’ performance, prevent air leaks, and significantly extend the service life of existing actuators. This maintenance method offers a cost-effective alternative compared to full cylinder replacement. Please note that the seal kit does not include a grease pack; this should be purchased separately (grease pack part number: GR-S-010, 10g). Additionally, for the MGP-Z series, it is important to verify the cylinder model before ordering, as old and new seal kits are not interchangeable.
Features:
This comprehensive seal kit includes all necessary components for a complete cylinder rebuild. Inside the kit, you will find the piston seal, rod seal, as well as two types of gaskets, gasket A and gasket B, ensuring a thorough restoration of your pneumatic cylinder.
The seal kits are available in a wide range of bore sizes to fit your specific needs. Sizes include 12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 80mm, and 100mm, providing compatibility with various cylinder dimensions.
Made from high-quality NBR and urethane materials, these seals deliver excellent resistance to oil and wear. This ensures durability and long-lasting performance, even in demanding operating environments.
The kit is specifically designed to be compatible with MGP series compact guide pneumatic cylinders that feature built-in guide rods. It effectively restores the cylinder’s force, speed, and non-rotating accuracy by eliminating any air leakage that may occur.
Opting for this seal kit is a cost-effective solution compared to replacing the entire cylinder. It helps extend the life of your actuator while maintaining optimal performance.
Installation is straightforward and can be completed quickly with standard tools, minimizing downtime and simplifying maintenance procedures.
This kit is particularly suited for precision assembly tasks, pick and place operations, as well as material handling applications, where reliability and accuracy are critical.
Inventory management is simplified by having one unique kit number for each bore size, making ordering and stock control easier.
Additionally, a separate grease pack (GR-S-010, 10g) is available to support proper lubrication during installation and maintenance.
Technical Parameters:
| Compatible Cylinder Series |
MGP Compact Guide Cylinders |
| Kit Contents |
Piston Seal, Rod Seal, Gasket A, Gasket B |
| Series |
MGP |
| Seal Material |
NBR |
| Product Type |
Seal Kit / Repair Kit |
| Bore Sizes |
12mm, 16mm, 20mm, 25mm, 32mm, 40mm, 50mm, 63mm, 80mm, 100mm |
Applications:
Pick and Place Units
Maintenance of guided cylinders plays a crucial role in ensuring precision positioning systems operate smoothly and accurately. Regular upkeep helps maintain the high performance required in these applications.
Factory Automation
In automated production lines, the repair of guided cylinders is essential to keep machinery running efficiently without unexpected downtime. Timely repairs contribute to sustained productivity.
Material Handling
Sealing components in cylinders used in conveyors and handling systems often require replacement to prevent leaks and maintain reliable operation. Proper seal replacement extends the life of the equipment.
Packaging Machinery
Regular maintenance of cylinders within packaging and filling machinery ensures consistent performance and reduces the risk of mechanical failure, supporting continuous production.
Electronic Component Manufacturing
Precision assembly equipment relies on well-maintained cylinders. Repairing guided cylinders in this sector is vital for achieving accurate and repeatable assembly processes.
General Industrial Pneumatics
Any industry application that demands dependable guided cylinder sealing benefits from proper maintenance and repair. Ensuring the integrity of seals enhances overall system reliability.
