Product Description:
These plate cylinder seal kits are precision-engineered replacement sets specifically created for the maintenance and overhaul of MU series compact plate cylinders and pin clamp cylinders. Suitable for bore sizes ranging from 25mm to 63mm, each kit includes all the essential sealing components necessary for a complete cylinder rebuild, such as the piston seal, rod seal, and bumper.
The seals are made from premium materials, with the piston and rod seals crafted from high-quality NBR (nitrile rubber) and the bumper manufactured from durable urethane. This combination ensures excellent resistance to wear, compression set, and the common pneumatic media encountered during operation. The MU series plate cylinders feature an oval piston design that inherently prevents rotation without the need for a rod with flats, thereby enhancing the longevity of both bearings and seals.
Regularly replacing seals using these kits helps restore optimal cylinder performance, prevents air leakage, and significantly prolongs the service life of existing actuators—all at a much lower cost compared to full replacements. Please note that the seal kit does not contain a grease pack, which must be purchased separately. The grease pack’s part number is GR-S-010 and comes in a 10g size.
Features:
This comprehensive seal kit contains everything needed for a complete cylinder rebuild, including a piston seal, rod seal, and bumper. It is specifically designed to restore the performance and reliability of your cylinder.
The kit is available in various bore sizes, including 25mm, 32mm, 40mm, 50mm, and 63mm, ensuring compatibility with a range of cylinders. Both the piston and rod seals are made from NBR material, which provides excellent resistance to wear and compression.
Additionally, the urethane bumper offers dependable cushioning at the end of the stroke, protecting the cylinder from impact damage. This kit is compatible with MUB and MDUB series compact plate cylinders, making it a versatile choice for many applications.
By effectively eliminating air leakage, the seal kit helps restore the cylinder’s force, speed, and sealing performance. It is a cost-effective solution that extends the lifespan of your actuator, serving as a practical alternative to replacing the entire cylinder.
Installation is quick and simple, requiring only standard tools. This makes it ideal for applications with limited space such as automated assembly lines, clamping devices, and indexing systems.
Each bore size corresponds to a single kit number, simplifying inventory management for maintenance teams. For added convenience, a separate grease pack (GR-S-010, 10g) is also available.
Technical Parameters:
| Product Type |
Seal Kit / Repair Kit |
| Kit Contents |
Piston Seal, Rod Seal, Bumper |
| Seal Material |
NBR |
| Series |
MUB / MDUB |
| Bumper Material |
Urethane |
| Bore Sizes |
25mm, 32mm, 40mm, 50mm, 63mm |
Applications:
Automated Assembly
Maintenance tasks related to plate cylinders within precision positioning systems are essential for ensuring smooth and accurate automated assembly operations. Regular servicing helps maintain optimal performance and prolongs the lifespan of these components.
Clamping and Indexing Systems
Repair services focused on cylinders used in clamping and indexing mechanisms address wear and tear, guaranteeing the reliability of these systems. Timely cylinder repairs are crucial for maintaining precise clamping and indexing functions.
Material Handling
In compact handling systems, replacing seals in cylinders is a vital maintenance activity. Proper seal replacement ensures efficient operation and prevents leaks, thereby enhancing the overall effectiveness of the material handling equipment.
Packaging Machinery
Regular maintenance of cylinders within packaging and filling equipment plays a key role in the smooth functioning of these machines. Well-maintained cylinders contribute to consistent packaging quality and minimize downtime.
Electronic Component Manufacturing
Cylinder repair services in precision assembly equipment are indispensable for the production of electronic components. These repairs help sustain the high accuracy and reliability required in electronic manufacturing processes.
General Industrial Pneumatics
Across various applications that demand dependable compact cylinder sealing, reliable maintenance and repair solutions are necessary. Ensuring proper sealing enhances the performance and durability of pneumatic systems in general industrial use.
